Section 1
Technical Information
This section provides technical information about the PowerMate
PowerMate Pro2180 Series computers (Models MT-1790-XXXXX and MT-1780-
XXXXX). The PowerMate Pro2200 and PowerMate Pro2180 have different CPUs
mounted on the system board. The PowerMate Pro2200 is a 200-MHz Intel
Pro-based system. The PowerMate Pro180 is 180-MHz Pentium Pro-based system. With
the exception of the CPU type, all other features of the computer are the same.
All configurations come standard with an Intel Pentium Pro™ 200- or 180-MHz processor
(depending the computer model), a 3 1/2-inch diskette drive, a 2.1-GB IDE hard disk (2.0
GB in SCSI configurations), 256-kilobyte (KB) asynchronous secondary cache, and 16-
megabyte (MB) random access memory (RAM). In addition, all systems come with 2 MB
(4 MB in SCSI configurations) of video Windows random access memory (WRAM)
installed on a Matrox video board.
Multimedia configurations come with the above features and an eight-speed CD-ROM
reader, 20 watt (W) external speakers, and a microphone. The SCSI multimedia
configurations come with 32 MB of system memory, a 2.0-GB SCSI hard disk, an Adaptec
SCSI controller board, and a 4-MB Matrox video board.
All systems ship with the following software.
T
®
Microsoft
T
Matrox Windows NT video drivers
T
Crystal audio drivers/business audio mixer and input (diskette for multimedia
configurations only)
T
®
LANDesk
T
Microsoft Internet Explorer for Windows NT
T
McAfee VirusScan for Windows NT (diskette)
T
Adaptec 7800 Family Manager Set drivers (for SCSI configuration only)
T
Puma TranXit™ for Windows NT (orderable by coupon when available)
Windows NT™ 4.0 and Healthy Environment Help file
Client Manager
®
Pro2200 and
®
Pentium™
