Linear Technology 1602A Demo Manual page 3

parts List
ITEM QTY REFERENCE
Required Circuit Components
1 1 C1
2 4 C2, C3, C4, C5
3 2 C8, C10
4 1 C6
5 1 C7
6 2 C9, C11
7 1 C12
8 1 C13
9 1 C14
10 1 C15
11 1 C17
12 1 D1
13 1 D2
14 1 L1
15 2 Q1, Q2
16 1 Q3
17 1 R1
18 1 R2
19 3 R3, R5, R8
20 1 R4
21 1 R7
22 2 R10, R13
23 1 R11
24 1 R12
25 1 R14
26 1 R15
27 1 U1
PART DESCRIPTION
CAP ., ALUM., ELECT., 100µF, 50V
CAP ., X7R, 4.7µF, 50V, 10%, 1210
CAP ., POSCAP , 150µF, 10V
CAP ., X7R, 1µF, 50V, 10%, 0805
CAP ., X7R, 0.22µF, 10V, 10%, 0603
CAP ., X5R, 47µF, 16V, 10%, 1210
CAP ., X5R, 22µF, 6.3V, 20%, 0805
CAP ., COG, 2nF, 50V, 0603
CAP ., NPO, 33nF, 16V, 0603
CAP ., X7R, 10000pF, 16V, 0603
CAP ., U2J, 5100pF, 50V, 0603
1.0A LOW VF SCHOTTKY RECTIFIER
2.0A LOW VF SCHOTTKY RECTIFIER
INDUCTOR, 1.3µH
MOSFET, N-CHANNEL, PG-TDSON-8
MOSFET, N-CHANNEL, PG-TDSON-8
RES., CHIP , 374k, 1%, 0603
RES., CHIP , 124k, 1%, 0603
RES., CHIP , 100k, 1%, 0603
RES., CHIP , 0.0025, 1W, 1%, 2512
RES., CHIP , 45.3k, 1%, 0603
RES., CHIP , 10Ω, 1%, 0603
RES., CHIP , 40.2k, 1%, 0603
RES., CHIP , 680k, 1%, 0603
RES., CHIP , 10k, 1%, 0603
RES., CHIP , 66.5k, 1%, 0603
I.C. LT3741EFE, 20-PIN TSSOP
DEMO MANUAL DC1602A
MANUFACTURER/PART NUMBER
SUN ELECT., 50CE100LX
MURATA, GRM32ER71H475KA88L
SANYO, 10TPF150ML
MURATA, GRM21BR71H105KA12L
MURATA, GRM188R71A224KA01D
MURATA, GRM32ER61C476KE15L
MURATA, GRM21BR60J226ME39L
MURATA, GRM1885C1H202JA01D
MURATA, GRM188R71C333KA01D
MURATA, GRM188R71C103KA01D
MURATA, GRM1887U1H512JA01D
DIODES INC., DFLS140
DIODES INC., DFLS240L
WE., 7443551130
INFINEON, BSC080N03LS G
INFINEON, BSC011N03LSI
VISHAY, CRCW0603374KFKEA
VISHAY, CRCW0603124KFKEA
VISHAY, CRCW0603100KFKEA
VISHAY, WSL25122L500FEA
VISHAY, CRCW060345K3FKEA
VISHAY, CRCW060310R0FKEA
VISHAY, CRCW060340K2FKEA
VISHAY, CRCW0603680KFKEA
VISHAY, CRCW060310K0JNEA
VISHAY, CRCW060366K5FKEA
LINEAR TECH., LT3741EFE#PBF
dc1602af
3
