Installation and Programming Instructions
Take the time to read through this guide to familiarize yourself with the features and
operation of the lock, and its quick and easy programming procedures.
Save this PROGRAMMING INSTRUCTIONS for future reference.
Note: Improper installations may result in damage to the lock and void the factory warranty.
Ver.2023
Installation and Programming Instructions for Electronic Stand-Alone Cylindrical Locks
CR6100 / CR6501
Stand-alone Touch Screen Access Lock
ANSI/BHMA Grade 1
DWG # ELG8032-10/24-1of31
Advertisement
Chapters
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Related Manuals for Cal-Royal CR6100
Summary of Contents for Cal-Royal CR6100
- Page 1 Installation and Programming Instructions for Electronic Stand-Alone Cylindrical Locks CR6100 / CR6501 Stand-alone Touch Screen Access Lock ANSI/BHMA Grade 1 Installation and Programming Instructions Take the time to read through this guide to familiarize yourself with the features and operation of the lock, and its quick and easy programming procedures.
- Page 2 DWG # ELG8032-10/24-2of31...
-
Page 3: Table Of Contents
Installation and Programming Instruction for Electronic Stand-Alone Cylindrical Locks INSTALLATION GUIDE TABLE OF CONTENTS Warnings ····················································································································································· 3 Introduction ••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• 3 S pecifications • • • • • • • • • • • • • • • • • • • • • • •• • • • • • • • • • • • • • • • • • • ••• •• • • • • • • • • • • • • • • • • • • •• •• • • • • • • • • • • • • • • • • • • • •• •• • • • • • • • • • • • • • • • • • • •• • • • • • • • • • • • • • • • • • • • • • •• • • • • • • 4 P arts B reakdown ••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••... -
Page 4: Specifications
Installation and Programming Instructions for Electronic Stand-Alone Cylindrical Locks SPECIFICATIONS Latch brass - 1/2"(13mm) throw Inside lever retracts latch standard Locks furnished for 1-3/8"(35mm) to Deadlocking latch 1-3/4"(45mm) doors. Outside lever controlled by touchpad, U.L. Listed or key retracts latch PARTS BREAKDOWN Confirming the Box Contents... -
Page 5: Tools For Installation
Installation and Programming Instruction for Electronic Stand-Alone Cylindrical Locks PARTS BREAKDOWN (Continued) ITEM DESCRIPTION QTY. Latch (2-3/4"(70mm) Backset (Standard)) Outside Assembly Inside Escutcheon Inside Lever Spacer Bushing Battery Cover Mounting Plate Assembly Outside Lever Key (Provided with Cylinder) Cylinder Cylinder Retainer Lock Body Strike Screw Pack... -
Page 6: Installation Instructions
Installation and Programming Instructions for Electronic Stand-Alone Cylindrical Locks INSTALLATION INSTRUCTIONS Step #1 Verify Hand and Bevel of Door Stand on outside/locked side of the door when determining the door hand. This lock is non-handed and the lever can be flipped around to the desirable hand. Note: Left Hand Left Hand... - Page 7 Installation and Programming Instructions for Electronic Stand-Alone Cylindrical Locks Position Template and Mark Drill Points sure to verify backset before marking and drilling door. 1. Fold and Place template on high edge of door at the horizontal centerline. 2. Mark centers of holes at proper backset. For beveled and square edge doors, mark both sides of the door.
-
Page 8: P Repare L Ock Fo R Installation
Installation and Programming Instructions for Electronic Stand-Alone Cylindrical Locks Step #3 Prepare Lock for Installation A. Unpack the Lock The lock is packed in such a way to represent how it will install on the door. Before installation: 1. Disassemble the inside escutcheon. 1) Remove the inside lever and spacer bushing with the lever removal tool provided. - Page 9 Installation and Programming Instructions for Electronic Stand-Alone Cylindrical Locks Adjustment for different door thickness: 1. Remove outside lever, spacer bushing and outside assembly (See C below). 2. Rotate outside mounting rose plate for proper door thickness as shown below. 3. Position of bent taps as shown below must match (ensure the bent taps are horizontally crossed).
- Page 10 Installation and Programming Instructions for Electronic Stand-Alone Cylindrical Locks D. How to change hands (If Required) 1. Remove the Lever Handle & Lock Chassis. 3. Assemble the Lock Chassis with 1) Insert key, rotate the key 45 degrees Escutcheon. clockwise. 1) Insert the lock Chassis into the 2) Depress retainer with tool provided.
-
Page 11: L Ock Installation
Installation and Programming Instruction for Electronic Stand-Alone Cylindrical Locks Step #4 Lock Installation ( Outside Assembly ) ( Inside Assembly Designation (4) 10-32 x 1-1/5"(30.Smm) (1) 10-32 x 1-13/32"(36mm) Spacer Bushing (2) M4 x P0.7-15/32"(12mm) Bluetooth Receiver (Optional) � ----- 7 (Optional) Designation Spindle... - Page 12 Installation and Programming Instructions for Electronic Stand-Alone Cylindrical Locks PROCEDURES 1. Install latch in door. Be sure that curved edge of latchbolt faces direction door closes. Attach with two screws supplied. 2. Install strike on the door frame. 3. Insert outside assembly through door, making sure that the lock body frame hooks latch case and retractor engages bolt tail(s).
-
Page 13: Step #5 Installation Option
Installation and Programming Instructions for Electronic Stand-Alone Cylindrical Locks Step #5 Installation Option Adding the Bluetooth Receiver to your lock(optional) 1. Install the Bluetooth Receiver into the slot above the battery compartment ⚠ IMPORTANT: The batteries must be removed prior to removing and/or inserting the Key Module: ... -
Page 14: Hardware Troubleshooting
Installation and Programming Instructions for Electronic Stand-Alone Cylindrical Locks HARDWARE TROUBLESHOOTING Test the Operation of the Mechanical Lockset Cycle the lock in both the locked and the unlocked positions. If problems are found: Symptom Suggested Action Check that door and frame are properly aligned and door is Door is binding free swinging. -
Page 15: Programming Guide
Installation and Programming Instructions for Electronic Stand-Alone Cylindrical Locks PROGRAMMING GUIDE Take the time to read through this guide to familiarize yourself with the features and oper ation of the lock, and its quick and easy programming procedures. TABLE OF CONTENTS Overview ···················································································································································... -
Page 16: Operation Of Lock
Installation and Programming Instructions for Electronic Stand-Alone Cylindrical Locks OPERATION OF LOCK Opening the door with a PIN Code Touch the screen with Enter a registered PIN Code and Turn lever to open door. palm of hand or fingers press [ ] button. ✱... -
Page 17: Factory Defaults
Installation and Programming Instructions for Electronic Stand-Alone Cylindrical Locks Factory Defaults Settings Factory Defaults Master PIN Code 123456 Lockout Mode Unprogrammed Passage Mode Unprogrammed Re-lock Time 5 seconds 5 times Wrong Code Entry Limit Shut Down Time 60 seconds Beep Volume 2 levels Scope of Master, User Settings Settings... -
Page 18: Programming Features
Installation and Programming Instructions for Electronic Stand-Alone Cylindrical Locks PROGRAMMING FEATURES Outside Inside Menu and Icons Symbols Description Touch the screen with palm of hand or fingers to activate. Press the indicated number buttons. ～ ✱ Press the [ ] button. It is used to complete an input process. ✱... -
Page 19: To Begin Programming
Installation and Programming Instructions for Electronic Stand-Alone Cylindrical Locks To Begin Programming: The Lock is preset at the factory with Master PIN Code [123456]. Touch the screen with palm of hand or fingers to activate. 1 2 3 4 5 6 ✱ B. - Page 20 Installation and Programming Instructions for Electronic Stand-Alone Cylindrical Locks Register One-Time User PIN Code Mstr ✱ One-Time Register RF Card Mstr Enter the Card Place the RF Card ✱ ...
-
Page 21: Programming
Installation and Programming Instructions for Electronic Stand-Alone Cylindrical Locks PROGRAMMING Change Default Master Code Before Programming Note: The factory default Master Code must be changed prior to adding users. Mstr Mstr Mstr ✱ Default Enter New Enter New ... - Page 22 Installation and Programming Instructions for Electronic Stand-Alone Cylindrical Locks 4. Press the button. Beep melody and Number pad blink one time. [Repeat steps 3 and 4 for each new user (if necessary).] ✱ 5. Press the button. Completes with beep sound. [For example, John Smith and Jessica are users.
- Page 23 Installation and Programming Instructions for Electronic Stand-Alone Cylindrical Locks 1. Enter the Master PIN Code and press the button. Green and Red LED blinks. 2. Enter the Program Code and press the button. Green and Red LED blinks. 3. Enter the One-Time User PIN Code and press the button.
- Page 24 Installation and Programming Instructions for Electronic Stand-Alone Cylindrical Locks Delete RF Card Mstr Enter the Card ✱ Registered No. Touch the screen with palm of hand or fingers to activate. 1. Enter the Master PIN Code and press the button.
- Page 25 Installation and Programming Instructions for Electronic Stand-Alone Cylindrical Locks Setting Up/Releasing Lockout Mode Mstr ✱ Enable ✱ Disable Touch the screen with palm of hand or fingers to activate. 1. Enter the Master PIN Code and press the button.
-
Page 26: Miscellaneous Information
Installation and Programming Instructions for Electronic Stand-Alone Cylindrical Locks MISCELLANEOUS INFORMATION Returning the Lock to Factory Defaults 1. Remove battery cover using #2 phillips screw driver. 2. Push and hold the Reset Button with the lever removal tool provided for 10 seconds. 3. -
Page 27: Glossary
Installation and Programming Instructions for Electronic Stand-Alone Cylindrical Locks GLOSSARY Lock Activation: Touch the screen with palm of hand or fingers to illuminate the number pad with beep. Enter the PIN Code while the number pad is illuminated. Master PIN Code: The Master PIN Code is used for programming User codes and feature settings. -
Page 28: Troubleshooting
Installation and Programming Instructions for Electronic Stand-Alone Cylindrical Locks TROUBLESHOOTING Symptom Suggested Action There is no power. Check if the batteries are faulty or in the correct polarity. Check if the batteries are inserted properly or completely discharged. I can't change the Master ... -
Page 29: User Pin Code Record Sheet
Installation and Programming Instructions for Electronic Stand-Alone Cylindrical Locks USER CODE RECORD SHEET User User User PIN Code RF Card Number Name (4~6 digits) registered No. ※ We recommend placing this record sheet in a safe and secure place. - 29 - DWG # ELG8032-10/24-29of31 Ver.2023... - Page 30 Installation and Programming Instructions for Electronic Stand-Alone Cylindrical Locks USER CODE RECORD SHEET User User User PIN Code RF Card Number Name (4~6 digits) registered No. ※ We recommend placing this record sheet in a safe and secure place. - 30 - DWG # ELG8032-10/24-30of31 Ver.2023...
- Page 31 Installation and Programming Instructions for Electronic Stand-Alone Cylindrical Locks USER CODE RECORD SHEET User User User PIN Code RF Card Number Name (4~6 digits) registered No. ※ We recommend placing this record sheet in a safe and secure place. - 31 - DWG # ELG8032-10/24-31of31 Ver.2023...
