Hardware Included:
#8 x 5/8"
#8 x 1-1/2"
PH Screw
FH Screw
7" Z-Bracket
Tools Required:
• Phillips Head Screwdriver
• Flat Head Screw Driver
• Allen Wrench
Assemble tables only as described in this
!
guide. All fasteners must be tightened
securely and checked regularly. Failure to
CAUTION
do so could cause instability and injury.
Quorum
3" x 3" Mending
1/4-20 X 15mm
Connector bolt
1" x 1" x 2"
plate
L-Bracket
instructions-quorum-230213
Tables
Advertisement
Related Manuals for Media Technologies mt contract Quorum
Summary of Contents for Media Technologies mt contract Quorum
- Page 1 Quorum Tables Hardware Included: 3" x 3" Mending #8 x 5/8" #8 x 1-1/2" 1/4-20 X 15mm 1" x 1" x 2" plate PH Screw FH Screw Connector bolt L-Bracket 7" Z-Bracket Tools Required: • Phillips Head Screwdriver • Flat Head Screw Driver •...
- Page 2 Quorum Tables Step 1: Place top with laminate side down on a protective surface. Step 2: Loosely attach z-brackets to the end and adder panels with the bolts. Step 3: Set the stretchers in place so the lip of the z-bracket fits into the dado on both ends of the stretcher, then attach the stretcher.
