Hardware Included:
#8 x 5/8"
#8 x 1-1/2"
Pan Head Screw
Flat Head Screw
3" x 3"
Mending Plate
Assemble tables only as described in this
!
guide. All fasteners must be tightened
securely and checked regularly. Failure to
CAUTION
do so could cause instability and injury.
Downtown
1/4-20 X 15mm
Connector Bolt
1" x 1" x 2"
7" Z-Bracket
L-Bracket
Tools Required:
• Phillips Head Screwdriver
• Flathead Screwdriver
• Allen Wrench
#12 x 1"
Pan Head Screw
Tables
Advertisement
Related Manuals for Media Technologies mtcontract Downtown
Summary of Contents for Media Technologies mtcontract Downtown
- Page 1 Downtown Tables Hardware Included: Tools Required: • Phillips Head Screwdriver • Flathead Screwdriver gs\3d Blocks\Tables\Downtown\Downtown 4284 x 39H.dwg, 9/30/2013 3:58:01 PM, DWG To PDF.pc3 • Allen Wrench #8 x 5/8” #8 x 1-1/2” 1/4-20 X 15mm #12 x 1” Pan Head Screw Flat Head Screw Connector Bolt Pan Head Screw...
- Page 2 Downtown Tables Keel End Panel Mending Plate Keel #2 Z Bracket Step 1: Attach (4) 3" x 3" mending plates to the top edge of each end panel using #8 x 1-1/3" Flat Head Screws. Step 2: Attach (5) 1" x 1" x 2" L-brackets to the dadoed side of each stretcher using #8 x 5/8" Pan Head Screws. Step 3: Place table top with laminate side down on a protective surface.
