NEC DTR-1R-2 Setup Manual

Start Here!
Set-Up Guide
DTR-1R-2
Step 1 Checking the Package Contents
Make sure your cordless phone's packaging
includes the following items (The number of items
may vary depending on the model purchased).
NEC
Base Handset AC adapter Belt Clip
Wall mount Rechargeable Telephone
adapter battery cord
Also included: • This set-up guide
• Owner's manual
• Other printed material
Step 2 Install Handset Battery Pack and Charge
Note Use ONLY the NEC rechargeable battery
pack supplied with your new phone!
Remove the
cover.
Connect the
battery pack
with the correct
polarity.
Replace the cover.
Step 3 Set up the Base
Plug the AC
Adapter cord to
the DC IN 9V
jack (yellow).
Plug the AC Adapter to a 120V AC power
outlet.
Note Use ONLY the NEC AC Adapter sup-
plied with your new phone!
Step 4 Charging the Handset
Place the handset in the base
or charger.
Make sure that charge LED
illuminates.
Charge the handset 15~20 hours.
Fully charge the battery pack by placing the
handset on the base before using phone.
Step 5 Connect to the Phone Line
Plug one end of the
telephone cord into
the base TEL LINE
jack.
Plug the other end into the telephone
wall jack.
Step 6 Make & Receive Calls
To Make a Call
Press talk/flash .
Listen for dial tone.
Dial the desired num-
ber.
To Receive a Call
Pick up the handset and
press talk/flash .
To Hang Up a Call
Press end or return the
handset to the base or
charger.
Additional Features
For more information on these and other fea-
tures, please refer to your Owner's Manual. For
your convenience, listed below are important fea-
tures that will help you set up your new cordless
phone.
Handset Set up:
- Set the day & time
- Adjust the earpiece and speaker volume
- Set the Ringer Volume
- Set Tone/Pulse Dialing
Refer to your Owner's Manual for detailed
operations.
Contact your NEC Representative for questions
or for ordering parts or accessories.
For complete User's Guide, go to:
www.necunifiedsolutions.com
Printed in China
UPZZ69788BZ(0)
INT-1060 (DTERM)
Document Revision 1
