Elevate Inverter Heat Pump
QUICK START
GUIDE
Thank you for purchasing a Henden Inverter Heat Pump.
Built with Inverter Technology for energy efficiency and designed
for super quiet operation. Harness the power of this high
performing heat pump and enjoy more time in the pool.
HELPFUL HINTS
Prepare the installation area by removing
debris or anything that could restrict
ventillation.
Regularly check the condensate drain for
any blockages or debris build up. This will
ensure optimal drainage.
Make sure there is water flowing through
the Henden Inverter Heat Pump when
operating.
CAUTIONS AND WARNINGS
WARNING: Electrical installation
must be carried out by a licenced
electrician in accordance with the
wiring rules and local regulations.
Scan to view the complete owners and installation manual:
To maximise efficiency, install the Henden
Inverter Heat Pump in line with the ventilation
diagrams depicted.
If you intend to connect the Henden Inverter
Heat Pump to the Henden Heat Pump App,
ensure you have strong Wi-Fi in the installation
location. more than -50dBm is considered
-50dBm
suitable for use.
IMPORTANT
Please read carefully
Keep the Henden Inverter Heat Pump away
from any potental fire source.
The Henden Inverter Heat Pump must be
placed in a well ventilated area.
Repair must be carried out by manufacturer
approved service personnel.
Date Issued: November 2024
Advertisement
Table of Contents
Related Manuals for Henden Elevate 11kW
Summary of Contents for Henden Elevate 11kW
- Page 1 Elevate Inverter Heat Pump QUICK START GUIDE Thank you for purchasing a Henden Inverter Heat Pump. Built with Inverter Technology for energy efficiency and designed for super quiet operation. Harness the power of this high performing heat pump and enjoy more time in the pool.
- Page 2 Harness the power of this high performing heat pump. Built with full Inverter Technology for energy efficiency and designed for super quiet, elite operation. Helpful Hints The surroundings of the Henden Elevate Inverter Heat Pump should be kept clear to avoid restricting ventilation. Install the Henden Elevate Inverter Heat Pump in a well-ventilated area.
-
Page 3: Specifications
SPECIFICATIONS Henden Henden Henden Henden Henden Henden Henden Elevate Elevate Elevate Inverter Elevate Elevate Inverter Elevate Elevate Model Inverter Heat Inverter Heat Heat Pump Inverter Heat Heat Pump Inverter Heat Inverter Heat Pump 11kW Pump 14kW 18kW Pump 21kW Pump 32kW Pump 40kW Advised pool volume (m³) -
Page 4: Installation
For details, please refer to the data plate. INSTALLATION Positioning the Henden Elevate Inverter Heat Pump 1. To begin, position the Henden Elevate Inverter Heat Pump on solid level ground. Do not install the unit in an enclosed area. - Page 5 4. Ensure the Henden Elevate Inverter Heat Pump is installed with electrical protection devices, including a circuit breaker and electrical isolation switch in accordance with the Wiring Rules. Electrical Installations WARNING! Electrical installation must only be carried out by a licensed electrician. Electrical...
- Page 6 <10m. External Connectors Installation Depending on the type of pool heating and cooling requirements, the Henden Essential Inverter Heat Pump may be operated by external controller. There are 3 connectors on the side of the unit. These are for external control, RS485 and Pump Control.
- Page 7 a. Wiring Ext. Control Cable to the connector After disassembling the connection point, pull the operation key outward. Remove the original wiring and connect the signal wire to the Pink and Blue Port. Once complete, push the operation key inward to lock the signal wire. （Outer diameter dimension of the signal wire ：5-9MM）...
- Page 8 b. Wiring RS485 to the connector After disassembling the connection point, pull the operation key outward. Connect the corresponding signal line according to the terminal of the corresponding colour. Once complete, push the operation key inward to lock the signal wire. （Outer diameter dimension of the signal wire ：3.5-7MM）...
- Page 9 Inverter Heat Pump from the isolation switch. 5. Press the power symbol on the control panel. The Henden Elevate Inverter Heat Pump will turn on within a few seconds. 6. Once on, the Henden Elevate will run for 1 minute before the compressor kicks in.
- Page 10 8. To adjust the bypass and calibrate the flow rate, first fully close the flow bypass. 9. Wait 3-4 minutes until the Henden Elevate Inverter Heat Pump is at 100% capacity. 10. Slowly open the flow bypass valve to increase the temperature differential between the inlet and outlet.
-
Page 11: Using The App
USING THE APP The *Henden Heat Pump* App can be used to control and monitor your Henden Inverter Heat Pump via Wi-Fi. To set up the *Henden Heat Pump* App, follow the steps below: 1. Open the Apple App Store or Google Play and download *Henden Heat Pump*. - Page 12 Interpreting the keys: Turbo/Smart/ Silence mode Auto Heating Cooling Heating capacity percentage Wi-Fi connection Water inlet Water outlet...
-
Page 13: Maintenance
3. If not in use for long periods of time (e.g. colder months), discharge all water in the Henden Elevate Inverter Heat Pump, including the water at the bottom. This prevents water from freezing in the Henden Elevate Inverter Heat Pump and potentially causing damage. - Page 14 This page has been left intentionally blank. Date Issued: November 2024.
- Page 15 This page has been left intentionally blank. Date Issued: November 2024.
- Page 16 This page has been left intentionally blank. Date Issued: November 2024.
