Swimming Pool Heat Pumps
HHP14, HHP22, HHP28, HHP34
INSTALLATION &
OWNERS MANUAL
WARNING:
Failure to follow
these instructions
and comply with all
applicable codes
may cause serious
bodily injury and/or
property damage.
The installation of
this product should
be carried out by a
person knowledgeable
in swimming
pool plumbing
requirements following
the installation
instructions provided
in this manual.
Please pass these instructions on to the operator of this equipment
IMPORTANT
Please read carefully
Advertisement
Table of Contents
Related Manuals for Henden HHP14
Summary of Contents for Henden HHP14
- Page 1 Swimming Pool Heat Pumps HHP14, HHP22, HHP28, HHP34 INSTALLATION & OWNERS MANUAL IMPORTANT Please read carefully WARNING: The installation of Failure to follow this product should these instructions be carried out by a and comply with all person knowledgeable applicable codes...
-
Page 3: Table Of Contents
Electronic Card Setting Mode (Temperature Adjustment) Changing the Display from Celsius to Fahrenheit De-icing Mode 5. WINTERISING 6. MAINTENANCE Safety Instructions Regular Maintenance 7. WATER QUALITY 8. TROUBLESHOOTING 9. HENDEN REPAIR OR REPLACEMENT GUARANTEE HENDEN INSTALLATION & OWNERS MANUAL | 3... -
Page 4: How It Works
2.1 Installation Site In accordance with AS/NZS 60335.2.41 To get the best results from your Henden heat pump, its we are obligated to inform you that this location is critical. The Henden heat pump takes hot air... -
Page 5: Water Connection
Current total (A) 13.0 21.0 27.1 13.7 practice as solar absorbers can’t typically accommodate the same flow rates as the Henden heat pump. The solar Min circuit 20.5 31.5 40.0 13.2 absorber may also act to cool water rather than heating, current (A) in cooler weather. - Page 6 Henden Heat Pump Installation Manual Wiring diagram for models: HHP14, HHP22, HHP28 Where applicable Figure 1 Wiring diagram for model: HHP34 Figure 2 6 | HENDEN INSTALLATION & OWNERS MANUAL...
-
Page 7: Connecting A Henden H8Vspbt Pump
Heat Pump The Henden heat pump uses a 24V AC contactor to turn on Henden H8VSPBT pump 100% speed using either the compressor to operate. Depending on the system your... -
Page 8: Fil Mode (Optional)
(shown below). FIL mode OFF: This is the factory default setting and is used when the Henden heat pump does not power the circulation pump. FIL mode ON: This option allows for the pool pump to be powered by the Henden heat pump. -
Page 9: Before Start-Up
To avoid the risk of injuries, or damage to the unit, never: • Pool mode: Between 16°C – 35°C • Sit on the Henden heat pump, or place a heavy object on it; • Spa mode: Between 16°C – 40°C •... -
Page 10: Regular Maintenance
Wash, with a stream of water from top to bottom to remove any grass, leaves or other objects that could obstruct the evaporator. • Clean the Henden heat pump casing with a mild soap (dishwashing liquid). Do not use abrasives, or bleach. Inspect the pool skimmer basket regularly. -
Page 11: Troubleshooting
• The flow switch is faulty. should be between 68 – 137kPa. The flow switch has cut out 3 times • Cycle the power off then on to reset the Henden heat pump; CODE: FL3 in the same hour for one reason •... -
Page 12: Henden Repair Or Replacement Guarantee
MUST provide evidence of the date of original purchase when making a claim. Henden shall not be liable for any loss of profits or any consequential, indirect or special loss, damage or injury of any kind whatsoever arising directly or indirectly from Henden products. - Page 13 Henden Heat Pump Owners Manual NOTES HENDEN INSTALLATION & OWNERS MANUAL | 13...
- Page 14 Henden Heat Pump Owners Manual NOTES 14 | HENDEN INSTALLATION & OWNERS MANUAL...
- Page 15 Henden Heat Pump Owners Manual HENDEN INSTALLATION & OWNERS MANUAL | 15...
- Page 16 P/N 403227-2...
