Essential Inverter Heat Pump
QUICK START
GUIDE
Thank you for purchasing a Henden Inverter Heat Pump.
Built with Inverter Technology for energy efficiency and designed
for super quiet operation. Harness the power of this high
performing heat pump and enjoy more time in the pool.
HELPFUL HINTS
Prepare the installation area by removing
debris or anything that could restrict
ventillation.
Regularly check the condensate drain for
any blockages or debris build up. This will
ensure optimal drainage.
Make sure there is water flowing through
the Henden Inverter Heat Pump when
operating.
CAUTIONS AND WARNINGS
WARNING: Electrical installation
must be carried out by a licenced
electrician in accordance with the
wiring rules and local regulations.
Scan to view the complete owners and installation manual:
To maximise efficiency, install the Henden
Inverter Heat Pump in line with the ventilation
diagrams depicted.
If you intend to connect the Henden Inverter
Heat Pump to the Henden Heat Pump App,
ensure you have strong Wi-Fi in the installation
location. more than -50dBm is considered
-50dBm
suitable for use.
IMPORTANT
Please read carefully
Keep the Henden Inverter Heat Pump away
from any potental fire source.
The Henden Inverter Heat Pump must be
placed in a well ventilated area.
Repair must be carried out by manufacturer
approved service personnel.
Date Issued: November 2024
Advertisement
Table of Contents
Related Manuals for Henden Essential 9kW
Summary of Contents for Henden Essential 9kW
- Page 1 Essential Inverter Heat Pump QUICK START GUIDE Thank you for purchasing a Henden Inverter Heat Pump. Built with Inverter Technology for energy efficiency and designed for super quiet operation. Harness the power of this high performing heat pump and enjoy more time in the pool.
- Page 2 For optimal heating, the Henden Essential Inverter Heat Pump should be <10m from the pool. For a complete heating solution, pair with a Henden 550 Micron Solar Pool Cover. This addition helps reduce energy consumption, heat loss and water evaporation.
-
Page 3: Specifications
SPECIFICATIONS Henden Henden Henden Henden Henden Essential Essential Essential Essential Essential Model Inverter Heat Inverter Heat Inverter Heat Inverter Heat Inverter Heat Pump 9kW Pump 13kW Pump 17kW Pump 21kW Pump 24kW Advised pool volume (m 20-35 30-50 35-65 45-80 55-90 Working air temp (°C) -
Page 4: Installation
Handy Tip! Henden recommends using M10 Bolts to fix the unit to concrete. 4. Ensure the Henden Essential Inverter Heat Pump is installed with electrical protection devices, including a circuit breaker and electrical isolation switch in accordance with the Wiring Rules. - Page 5 Electrical Installations WARNING! Electrical installation must only be carried out by a licensed electrician. Electrical Installations must be in accordance with the Wiring Rules, local regulations and the instructions stated in the full manual. To access the full manual, scan the QR code on the front cover of this guide.
- Page 6 External Connectors Installation Depending on the type of pool heating and cooling requirements, the Henden Essential Inverter Heat Pump may be operated by external controller. There are 3 connectors on the side of the unit. These are for external control, RS485 and Pump Control.
- Page 7 Wiring cables to the connectors a. Wiring Ext. Control Cable to the connector After disassembling the connection point, pull the operation key outward. Remove the original wiring and connect the signal wire to the Pink and Blue Port. Once complete, push the operation key inward to lock the signal wire. （Outer diameter dimension of the signal wire ：5-9MM）...
- Page 8 b. Wiring RS485 to the connector After disassembling the connection point, pull the operation key outward. Connect the corresponding signal line according to the terminal of the corresponding colour. Once complete, push the operation key inward to lock the signal wire. （Outer diameter dimension of the signal wire ：3.5-7MM）...
- Page 9 Inverter Heat Pump from the isolation switch. 5. Press the power symbol on the control panel. The Henden Essential Inverter Heat Pump will turn on within a few seconds. 6. Once on, the Henden Essential will run for 1 minute before the compressor kicks in.
- Page 10 8. To adjust the bypass and calibrate the flow rate, first fully close the flow bypass. 9. Wait 3-4 minutes until the Henden Essential Inverter Heat Pump is at 100% capacity. 10. Slowly open the flow bypass valve to increase the temperature differential between the inlet and outlet.
-
Page 11: Using The App
USING THE APP The *Henden Heat Pump* App can be used to control and monitor your Henden Inverter Heat Pump via Wi-Fi. To set up the *Henden Heat Pump* App, follow the steps below: 1. Open the Apple App Store or Google Play and download *Henden Heat Pump*. - Page 12 Interpreting the keys: Smart/Silence mode Auto Heating Cooling Heating capacity percentage Wi-Fi connection Water inlet Water outlet...
-
Page 13: Maintenance
2. Use freshwater at a low pressure to clean the fins on the air inlet regularly. 3. If not in use for long periods of time (e.g. colder months), discharge all water in the Henden Essential Inverter Heat Pump, including the water at the bottom. This prevents water from... - Page 14 This page has been left intentionally blank. Date Issued: November 2024.
- Page 15 This page has been left intentionally blank. Date Issued: November 2024.
- Page 16 This page has been left intentionally blank. Date Issued: November 2024.
