  • Page 1 Maintenance Guide M00112815EN Rev.P...
  • Page 2 Seiko Epson Corporation’s operating and maintenance instructions. Seiko Epson Corporation shall not be liable against any damages or problems arising from the use of any options or any consumable products other than those designated as Original Epson Products or Epson Approved Products by Seiko Epson Corporation.

  • Page 3: Table Of Contents

    Contents Before Starting Maintenance Work ..............................5 1.1. Meaning of Symbols ..................................5 Symbols in This Manual ................................5 User Permissions ..................................6 Symbols on This Machine ................................. 6 Caution Labels ....................................7 1.2. Safety Information ..................................12 Safety Information for Maintenance Work ........................12 Safety Information in Handling Consumables (Ink, Maintenance Liquid) and Waste Ink ......
  • Page 4 Replacement Procedure ..................................103 5.1. Cap Replacement ..................................103 5.2. Wiper Replacement ..................................107 5.3. Towel Roller Fabric Replacement ............................111 5.4. Washing T-shaped Scraper Replacement ........................... 115 5.5. Washing Silicone Scraper Replacement ..........................120 5.6. Pressure Roller Replacement ..............................122 Glue Re-Application .....................................

  • Page 5: Before Starting Maintenance Work

    1. Before Starting Maintenance Work To use the machine safely, please read the user’s manual for this machine carefully before using the machine. Failure to comply with the user’s manual may cause malfunctions or accidents. Store the user’s manual of this machine in a location where it can be easily referred to whenever you have a question.

  • Page 6: User Permissions

    Symbols on This Machine Do not remove the caution labels that are attached to this machine. If a caution label becomes illegible or is removed, contact your dealer or Epson Support for a replacement label. CAUTION: Risk of CAUTION: High...

  • Page 7: Caution Labels

    Caution Labels Labels are affixed to the machine to draw attention to dangerous locations. Main electric box It will look like either of the following.
  • Page 8 Front Rear...
  • Page 9 When opening the front protection cover Print head...
  • Page 10 When opening the rear protection cover Ink rack...
  • Page 11 Left side of the Sub-tank rack Inside of the Ink tank housing...

  • Page 12: Safety Information

    1.2. Safety Information Safety Information for Maintenance Work WARNING Do not operate this machine or the computer while maintenance is being performed. When performing maintenance work in a location that is out of sight of the control PC operator, make sure that only the person performing maintenance work and no one else is able to operate the control PC.

  • Page 13: Safety Information In Handling Consumables (Ink, Maintenance Liquid) And Waste Ink

    Safety Information in Handling Consumables (Ink, Maintenance Liquid) and Waste Ink WARNING If fluid gets on your skin or enters your eyes or mouth, take the measures below.  If fluid gets on your skin, rinse immediately with soap and water. ...

  • Page 14: Safety Precautions

    Safety Precautions When maintenance work is completed, immediately return the protective equipment to its original location. Make sure that no tools or parts used in maintenance work, or other foreign materials are left on the operating parts of the machine or inside the machine. During maintenance, do not use sharpening stones, abrasive/corrosive materials, or solvents (excluding glue and ink film remover).

  • Page 15: Wearing Of Personal Protective Equipment

    1.3. Wearing of Personal Protective Equipment CAUTION Be sure to wear personal protective equipment (protective gloves and clothing) during maintenance work on this machine. Long hair should be tied back and worn under a hair net. Otherwise, your hands and clothing could become stained with ink, and your fingers and hair could become caught in the machine.

  • Page 16: Checks Before Maintenance Work

    1.4. Checks Before Maintenance Work Do not place tools, fasteners, or the like on the belt or near the pressure roller or print head. Doing so could cause them to be entangled in the belt, pressure roller, or print head, damaging this machine. Before turning the power on, check that there is nothing left near the moving parts, such as on the belt or near the print head.

  • Page 17: Machine Status During Maintenance Work

    1.5. Machine Status During Maintenance Work To ensure that maintenance work is done safely, for step 1 of each procedure, check that the machine is in the indicated status. The following explains each status and the procedure to put the machine in that status. Power Off Status The machine's main power switch is in 0 (OFF) and the power is off.

  • Page 18: List Of Maintenance Tools And Supplies

    Use for cap and wiper cleaning Clean stick (Dedicated consumables/commercially available) If purchasing from Epson: Item name: Clean Stick B Model no.: C13S090011 Epson recommends the following if purchasing yourself: ASPURE from AS ONE Corporation Model no.: AP125PCT Nonwoven fabric for head cleaning Cleaning cloth...
  • Page 19 Item Details/Use Grease added to the scan spindle. Grease Epson recommends the following: (Commercially available) NSK Ltd. Model no.: NSK GRS AS2 Used to contain the maintenance liquid or tap Plastic container water. (Commercially available) Epson recommends the following: Disposable cup Use during cleaning.

  • Page 20: Maintenance Work List

    2. Maintenance Work List 2.1. Inspection/Cleaning Inspection Frequency Item □ ✓ Checking the area around operating parts Disposing of waste ink of the cleaning □ ✓ 3.2.1 station (Models with waste ink tanks only) Disposing of waste ink of the flushing area □...
  • Page 21 □ ✓ ✓ 3.20 Cleaning/Replacing the cooling fan filters □ 3.21 Checking the cable protection condition ✓ *1: After printing on fabric with fuzzy surface *2: When changing the fabric type...

  • Page 22: Adjustment/Replacement

    2.2. Adjustment/Replacement Inspection Frequency Item ✓ □ Bi-directional adjustment ✓ □ Belt feed amount adjustment ✓ □ Cap replacement □ ✓ Wiper replacement ✓ □ Towel roller fabric replacement ✓ □ Washing T-shaped scraper replacement ✓ □ Washing silicone scraper replacement ✓...

  • Page 23: Inspection/Cleaning Procedure

    3. Inspection/Cleaning Procedure 3.1. Checking the Area around Operating Parts Frequency Every shift User Permissions Personal Protective Protective gloves and clothing Equipment Check that the machine is in the Power Off Status. (See: 1.5.1 Power Off Status) Make sure that no tools or other items are left on operating parts such as the print head operating area [1] and the carriage operating area [2].

  • Page 24: Disposing Of Waste Ink (Models With Waste Ink Tanks Only)

    3.2. Disposing of Waste Ink (Models with Waste Ink Tanks Only) Dispose of the waste ink in the waste ink tanks located in the cleaning station (2: Front right) and flushing area (1: Front left). Disposing of Waste Ink of the Cleaning Station Frequency Inspection: Everyday, before beginning work Disposal: Everyday, when printing ends...
  • Page 25 Slide the waste ink tank cover horizontally to remove it. Make sure the waste ink tank does not contact the drain of the waste ink pipe when removing it. Securely close the waste ink tank lid. Dispose of the waste ink in the proper manner. Set an empty waste ink tank in the original position.

  • Page 26: Disposing Of Waste Ink Of The Flushing Area

    Slide the waste ink tank cover horizontally to install it. Disposing of Waste Ink of the Flushing Area Frequency Inspection: Everyday, before beginning work Disposal: Dispose as necessary User Permissions Personal Protective Eye protection, protective gloves and clothing Equipment Required Items Replacement waste ink tank Check that the amount of waste ink in the waste ink tank is not such that the waste ink will spill out.
  • Page 27 Open the side cover on the flushing area side. Remove the six screws from the side cover. Unlock the side cover key and remove the cover.
  • Page 28 Hold the parts on the sub-tank rack as indicated by circles below with both hands, and pull it out from the ink tank housing. Be careful of the following so as not to damage the cables: Do not allow the sub-tank rack wheels to run over the cables. ...
  • Page 29 Wear eye protection. Be sure to wear eye protection. CAUTION Failure to do so could cause ink to splash into the eyes. Enter the ink tank housing with the replacement waste ink tank. Remove the waste ink tube from the waste ink tank and insert it into the new waste ink tank. Carefully remove the waste ink tube.
  • Page 30 11. Attach the side cover and tighten the six screws. 12. Lock the side cover. 13. Dispose of the waste ink in the proper manner.

  • Page 31: Inspecting The Emergency Stop Equipment

    3.3. Inspecting the Emergency Stop Equipment Frequency Everyday Inspection before beginning work User Permissions Personal Protective Protective gloves and clothing Equipment Check that the emergency stop button and the emergency stop function of the cleaning tank operate normally. For detailed procedures, refer to the "Operation Guide". 3.4.

  • Page 32: Cleaning The Area Around The Caps And Wipers

    3.6. Cleaning the Area Around the Caps and Wipers Frequency Everyday/When a problem occurs (When a problem such as mixed colors and nozzle clogging occurs) User Permissions Personal Protective Protective gloves and clothing, eye protection Equipment Required Items Clean stick, maintenance liquid, plastic container, tweezers For cleaning, be sure to use the dedicated maintenance liquid.
  • Page 33 Open the front protection cover.
  • Page 34 Lightly wipe off dirt from around the cap using the cleaning cloth or clean stick moistened with maintenance liquid. CAUTION Make sure that the machine's power is off before performing work. Do not wipe around the cap with force. Doing so may damage the ...
  • Page 35 Remove fluffy dust if adhering around the cap using plastic tweezers. Do not pinch the lip section of the cap with the tweezers. Doing so may damage the lip section, deteriorate nozzle recovery by cleaning, or result in nozzle clogging. Lip section...
  • Page 36 Lightly wipe off dirt from around the wiper using the cleaning cloth or clean stick moistened with maintenance liquid. Wipe off in the direction of the arrows. The same applies to the cleaning cloth. Do not pull the rubber part of the wipers. Rear side of wiper Wiper section 10.

  • Page 37: Cleaning The Flushing Plate

    3.7. Cleaning the Flushing Plate Frequency Everyday, when printing ends User Permissions Personal Protective Protective gloves and clothing, eye protection Equipment Required Items Clean stick, scraper/brush Be sure to wear eye protection. CAUTION Failure to do so could cause ink to splash into the eyes. Clean away any waste ink that has built up on the flushing plate.
  • Page 38 Sweep the ink remaining on the plate into the path at the corner of the plate using the scraper. If waste ink is dried, apply maintenance liquid to dissolve the ink before cleaning. For EVO TRE 16-180 For EVO TRE 32-180...
  • Page 39 Discharge the waste ink collected in the path from the drain using the clean stick or brush. For EVO TRE 16-180 For EVO TRE 32-180 When cleaning is finished, close the front protection cover.

  • Page 40: Checking The Height With The Foreign Material Detection Sensor

    3.8. Checking the Height with the Foreign Material Detection Sensor Frequency Every shift/When changing the fabric type User Permissions Personal Protective Protective gloves and clothing Equipment Required Items Hex key (width: 2 mm) or feeler gauge (2 mm) Check that the foreign material detection sensor is operating normally. Check that the machine is in the Printing Standby Status.
  • Page 41 Move to the machine rear, and check that the tool is exposed to the laser beam through the gap at the top of the pressure roller. Check the foreign material detection sensor display again to confirm that the detection threshold value is 500 or more lower than the previous value.

  • Page 42: Cleaning The Belt And Removing Ink Film (When Using Pigment Ink)

    The following is the protective equipment that must be worn when using the Equipment ethanol recommended by Epson. For details, refer to the instructions of the SDS for the ethanol you are actually using. Eye protection (For organic solvent use;...
  • Page 43 Required Items Item Quantity Details/Use Ethanol Approx. 0.1 L Commercially Removes any ink adhering to the belt. Mix with available tap water before use. Cleaning bottle Commercially This container is used to hold a cleaning liquid available made by mixing tap water and ethanol. Wipe cloths Proper amount Commercially...

  • Page 44: Removing Ink Film

    The following is the protective equipment that must be worn when using the Equipment ethanol recommended by Epson. For details, refer to the instructions of the SDS for the ethanol you are actually using. Eye protection (For organic solvent use;...
  • Page 45 Put the ink film remover (7 L) and tap water (10 L) in the container and mix well. Operate the lever to close the water supply valve. Check to see that water has filled up to the partition of the tank on the bottom of the cleaning brushes. If there is not enough water accumulated, use a bucket or the like to pour in tap water.
  • Page 46 Check to see that no water remains in the tank at the bottom of the scraper. Turn the left drain valve in the direction of the arrow to close it. Pour the ink film remover made in step 1 into the tank on the bottom of the cleaning brushes. Return the belt cleaning unit to the original position.
  • Page 47 In Leonardo, open [Maintenance] and then select [Status flags] - [Complete washing]. Confirm the message displayed and click [Yes] to start belt cleaning. When belt cleaning is completed, the tower lamp changes from white to green. When belt cleaning is completed, perform [Complete washing] again, for a total of eight times.

  • Page 48: Cleaning The Area Around The Head And Inspecting The Sub-Tank Rack

    3.10. Cleaning the Area around the Head and Inspecting the Sub-tank Rack Frequency Every week/When a problem occurs, When a large amount of printing is completed User Permissions Personal Protective Protective gloves and clothing, eye protection Equipment Required Items Clean stick, cleaning cloth, maintenance liquid, plastic container, hex key (width: 4 mm), flashlight, side cover key (supplied with the machine) Be sure to wear eye protection.
  • Page 49 Remove the fastener of the flushing plate. For EVO TRE 16-180 (1) Loosen the 2 screws using the hex key (width: 2.5 mm), then (2) slide the fastener to the left and (3) pull the fastener toward you to remove it.
  • Page 50 For EVO TRE 32-180 Loosen the two screws on the fastener of the flushing plate using the hex key (width: 4 mm), and remove the screws and fastener. Move the flushing plate to the rear. For EVO TRE 16-180...
  • Page 51 For EVO TRE 32-180 Close the front protection cover. Release the emergency stop button. Execute Set point. On the Leonardo operation screen, click [Setpoint] and then press the reset button on the main electric panel. The head carriage returns to the origin position and moves to the cleaning station.
  • Page 52 Move the head carriage to the flushing area. On the Leonardo operation screen, open [Maintenance] (1), and click [+] (2) for [Carriage] under [Axes] once. When the head carriage moves to the center, click [+] again. The head carriage moves to the left into the flushing area. Do not work for a long period of time while the head carriage is uncapped.
  • Page 53 13. Open the side cover on the flushing area side. Remove the six screws from the side cover. 14. Unlock the side cover key and remove the cover.
  • Page 54 15. Hold the parts on the sub-tank rack as indicated by circles below with both hands, and pull it out from the ink tank housing. Be careful of the following so as not to damage the cables: Do not allow the sub-tank rack wheels to run over the cables. ...
  • Page 55 16. Visually check for leaks in the ink path of the sub-tank rack.  Check the connections of the ink tubes: [1], [2]  Check for ink pack breakage and ink leaks: [3] 17. Wear eye protection. 18. Enter the ink tank housing with the following tools: Cleaning cloth, clean stick, a container of maintenance liquid, flashlight Make sure that the machine's power is off before entering the ink tank CAUTION...
  • Page 56 19. While shining the flashlight at your hands, wipe off fluffy dust from the head front and ink stains on the head side face using the clean stick. Be careful not to touch the nozzle surface of the head or wipe it with the clean stick.
  • Page 57 For EVO TRE 16-180 Flushing plate rails For EVO TRE 32-180 After moving the head carriage to the outside, be sure to return it to the inside. If it is not returned to the inside, the sensor on the head carriage may activate, and you may not be able to execute Set point.
  • Page 58 29. Return the flushing plate to the original position and then attach the fastener and tighten the two screws with the hex key. For EVO TRE 16-180: Hex key (width: 2.5 mm) For EVO TRE 32-180: Hex key (width: 4 mm) 30. Close the front protection cover. 31. Release the emergency stop button.
  • Page 59 33. From [Maintenance] menu of Leonardo, execute head cleaning. Refer to the "Operation Guide" for the corresponding procedures. 34. Perform a nozzle check. Refer to the "Operation Guide" for the corresponding procedures.

  • Page 60: Cleaning The Cleaning Brushes And The Area Around Them

    3.11. Cleaning the Cleaning Brushes and the Area around Them Frequency Every week/When necessary (After printing on fabric with fuzzy surface) User Permissions Personal Protective Protective gloves and clothing Equipment Required Items Hex key (width: 6 mm) Check that the machine is in the Power Off Status. (See: 1.5.1 Power Off Status) Remove the screw from each fastener that secures the belt cleaning carriage at two locations using the hex key (width: 6 mm).
  • Page 61 EVO TRE 32-180 Remove all fiber and other dust from the cleaning brushes. For the cleaning brushes, a metallic brush as shown below can also be used.
  • Page 62 When cleaning is finished, return the belt cleaning tank to the original position. Insert the belt cleaning tank straight into its original position. If put in at a slant, the frame of the belt cleaning carriage may touch the side, making it difficult to enter.

  • Page 63: Cleaning The Head Cover

    3.12. Cleaning the Head Cover Frequency When necessary User Permissions Personal Protective Protective gloves and clothing Equipment Required Items Cleaning cloth, maintenance liquid, plastic container For cleaning, be sure to use the dedicated maintenance liquid. Check that the machine is in the Printing Standby Status. (See: 1.5.2 Printing Standby Status) Move the head carriage to the flushing area.
  • Page 64 Moisten the cleaning cloth with maintenance liquid and wipe the head cover surface. CAUTION Make sure that the machine's power is off before performing work. Completely wipe off ink-stained fiber or similar dust. Printing with such dust remaining on the parts may cause ink to drip on the fabric, resulting in a printing error.

  • Page 65: Cleaning The Plate (Guide Beside The Belt)

    3.13. Cleaning the Plate (Guide Beside the Belt) Frequency When necessary User Permissions Personal Protective Protective gloves and clothing Equipment Required Items Cleaning cloth, maintenance liquid, plastic container If the plate (guide beside the belt) is stained by ink, wipe it off. Check that the machine is in the Power Off Status.

  • Page 66: Cleaning The Carriage Operating Parts

    3.14. Cleaning the Carriage Operating Parts Frequency Every month User Permissions Personal Protective Protective gloves and clothing Equipment Required Items Cleaning cloth Check that the machine is in the Power Off Status. (See: 1.5.1 Power Off Status) Open the front protection cover. Clean the carriage rail with the cleaning cloth.
  • Page 67 When cleaning is finished, close the front protection cover. Turn the main power switch to 1 (ON) to turn the power on. Start up Leonardo. Release the emergency stop button. Execute Set point. On the Leonardo operation screen, click [Setpoint] and then press the reset button on the main electric panel.
  • Page 68 14. Clean the carriage rail on the cleaning station side with the cleaning cloth. CAUTION Make sure that the machine's power is off before performing work. Never touch the linear scale or the magnet rail. Doing so may cause malfunction. 15.

  • Page 69: Adding Grease To The Scan Spindle

    3.15. Adding Grease to the Scan Spindle Frequency Every six months User Permissions Personal Protective Protective gloves and clothing Equipment Required Items Scan spindle grease, grease gun, cleaning cloths, flashlight Add grease to the scan spindle. Check that the machine is in the Printing Standby Status. (See: 1.5.2 Printing Standby Status) Move the head carriage to the flushing area.
  • Page 70 Open the front protection cover. Open the side cover on the flushing area side. Remove the six screws from the side cover.
  • Page 71 Unlock the side cover key and remove the cover.
  • Page 72 Hold the parts on the sub-tank rack as indicated by circles below with both hands, and pull it out from the ink tank housing. Be careful of the following so as not to damage the cables: Do not allow the sub-tank rack wheels to run over the cables. ...
  • Page 73 11. Use the flashlight to light the area around your hands and add grease using the grease gun through the two oil filler holes (upper and lower holes) of the linear block on the left side of the scan spindle. Use cleaning cloths to wipe off any excess grease or ink adhering to the oil filler holes and surrounding area before working.
  • Page 74 12. Add grease in the same way from under the head carriage to the oil filler hole (lower) of the linear block on the right side of the scan spindle. Be careful of the area above your head while working. Looking up from under the head carriage 13.
  • Page 75 14. Add grease from the front of the machine to the oil filler hole (upper) of the linear block on the right side of the scan spindle. Never touch the linear scale or the magnet rail. Doing so may cause malfunction.
  • Page 76 16. Return the sub-tank rack to the original position. 17. Attach the side cover and tighten the six screws. 18. Lock the side cover. 19. Turn the main power switch to 1 (ON) to turn the power on. 20. Start up Leonardo. 21.
  • Page 77 24. Wipe off any grease that has spilled from around the oil filler holes. Perform procedures 1 to 10, check the two oil filler holes (upper and lower holes) of the linear block on the left side of the scan spindle, and use cleaning cloths to wipe off any excess grease. 25.
  • Page 78 26. Exit the ink tank housing. 27. From the front of the machine, check the oil filler hole (upper) of the linear block on the right side of the scan spindle and use cleaning cloths to wipe off any excess grease. Never touch the linear scale or the magnet rail.
  • Page 79 31. Lock the side cover. 32. Turn the main power switch to 1 (ON) to turn the power on. 33. Start up Leonardo. 34. Release the emergency stop button. 35. Execute Set point. On the Leonardo operation screen, click [Setpoint] and then press the reset button on the main electric panel.

  • Page 80: Checking For Water Leaks In The Pipe Joints

    3.16. Checking for Water Leaks in the Pipe Joints Frequency Every month User Permissions Personal Protective Protective gloves and clothing Equipment Check that the machine is in the Power Off Status. (See: 1.5.1 Power Off Status) Check that the joints for the cleaning tank of the cleaning unit [1] and [2] are not loosened and are free water leaks.

  • Page 81: Draining Wastewater Of The Air Filter And Mist Separator

    3.17. Draining Wastewater of the Air Filter and Mist Separator Discharge any water or impurities that have accumulated in the air filter and mist separator. Draining the Compressed Air Route Air Filter Frequency Everyday User Permissions Required Items Plastic container and personal protective equipment (protective gloves and clothing) Close the facility's pressurized air valve.

  • Page 82: Draining The Dry Air System Air Filter And Mist Separator (Only For Models Equipped With A Dry Air System)

    Draining the Dry Air System Air Filter and Mist Separator (Only for Models Equipped with a Dry Air System) Frequency Everyday User Permissions Required Items Plastic container and personal protective equipment (protective gloves and clothing) The water and impurities are discharged automatically. Dispose of the water and impurities collected in the container.

  • Page 83: Cleaning/Replacing The Mist Filter

    3.18. Cleaning/Replacing the Mist Filter Frequency Cleaning: Every month Replacement: When necessary User Permissions Personal Protective Protective gloves and clothing Equipment Required Items Replacement: Replacement mist filter Check that the machine is in the Power Off Status. (See: 1.5.1 Power Off Status) Remove the maintenance window cover from the mist filter on the side face of the machine.
  • Page 84 Remove the two screws from the mist filter cover and remove the cover. Pull out the mist filter. Clean the removed mist filter with water. Dry the filter thoroughly and attach it again. Replace the filter if it is extremely dirty. Make sure that the mist filter is set in the correct direction while attaching it.

  • Page 85: Checking The Blower And Cleaning/Replacing The Filter

    3.19. Checking the Blower and Cleaning/Replacing the Filter Frequency Inspection: Every month Cleaning/Replacement: When necessary User Permissions Personal Protective Protective gloves and clothing Equipment Clean the filter for the blower on the rear side of the machine. Check that the machine is in the Power Off Status. (See: 1.5.1 Power Off Status) Remove the screw from the filter cover.
  • Page 86 Remove the filter and clean dirt and dust with a vacuum cleaner. After cleaning, attach the filter again. Replace the filter if it is extremely dirty.

  • Page 87: Cleaning/Replacing The Cooling Fan Filters

    3.20. Cleaning/Replacing the Cooling Fan Filters If the cooling fan filters are used continuously without cleaning, the machine will become unable to lower the temperature of the print head drive substrate, which may result in a failure. Follow the procedures below to clean the cooling fan filters.
  • Page 88 While holding the cooling fan cover so that it does not fall, loosen the four screws on the cover using the hex key (width: 3 mm) and remove the cover.
  • Page 89 Remove all eight cooling fan filters. Cooling fan Cooling fan filter Remove the cooling fan filter from the cover. Put tap water into the container. Wash the cooling filter on the tray, so as not to spill dirty water.
  • Page 90 Place the cooling fan filter in the plastic container and wash off the stains by hand. The dirty water is industrial waste. Dispose of it in the proper manner. Dry the cooling fan filter. Place the cooling fan filter on the cover.
  • Page 91 Install all the cooling fan filters in their original positions.
  • Page 92 Attach the cooling fan cover and tighten the four screws using the hex key (width: 3 mm). Close the front protection cover.

  • Page 93: Replacing The Cooling Fan Filters

    Replacing the Cooling Fan Filters Required Items New cooling fan filters and personal protective equipment (protective gloves and clothing, eye protection) Check that the machine is in the Power Off Status. (See: 1.5.1 Power Off Status) Open the front protection cover.
  • Page 94 While holding the cooling fan cover so that it does not fall, loosen the four screws on the cover using the hex key (width: 3 mm) and remove the cover. Remove the cooling fan filters. Cooling fan Cooling fan filter...
  • Page 95 Remove the cooling fan filter from the cover. A dirty filter is industrial waste. Dispose of it in the proper manner. Place the new cooling fan filter on the cover.
  • Page 96 Install the cooling fan filters straight in their original positions, with the cover protrusions on the top and bottom sides.
  • Page 97 Attach the cooling fan cover and tighten the four screws using the hex key (width: 3 mm). Close the front protection cover.

  • Page 98: Checking The Cable Protection Condition

    3.21. Checking the Cable Protection Condition Frequency Every month User Permissions Personal Protective Protective gloves and clothing Equipment Check that the machine is in the Power Off Status. (See: 1.5.1 Power Off Status) Check the cable protective tubes between the machine and the main electric box for any damage.

  • Page 99: Adjustment Procedure

    4. Adjustment Procedure 4.1. Bi-directional Adjustment Frequency When replacing heads/When changing jobs User Permissions Personal Protective Protective gloves and clothing Equipment Adjust the ink dot position in the head reciprocating path. Make adjustment when vertical misalignment occurs. Check that the machine is in the Printing Standby Status. (See: 1.5.2 Printing Standby Status) From the printed result of a printing job, measure the misaligned amount in mm.
  • Page 100 Press [3] to save the settings. Print again and check the result.

  • Page 101: Belt Feed Amount Adjustment

    4.2. Belt Feed Amount Adjustment Frequency When sideways streaking occurs/When changing jobs User Permissions Personal Protective Protective gloves and clothing Equipment When sideways streaking occurs horizontally in print results, adjust the belt feed amount at every printing pass. Check that the machine is in the Printing Standby Status. (See: 1.5.2 Printing Standby Status) From the printed result of a printing job, check the misaligned amount.
  • Page 102 Press [3] to save the settings. Print again and check the result.

  • Page 103: Replacement Procedure

    5. Replacement Procedure 5.1. Cap Replacement Frequency When necessary/When a problem occurs (For example, when nozzle clogging is not resolved by cleaning) User Permissions Personal Protective Eye protection, protective gloves and clothing Equipment Required Items Replacement cap unit, forceps, hex key (width: 2.5 mm), maintenance liquid, clean stick, plastic container Be sure to wear eye protection.
  • Page 104 Turn the main power switch to 0 (OFF) to turn the power off. Open the front protection cover. A cap unit is equipped with four caps. Loosen the screw at the center of the cap unit with the hex key (width: 2.5 mm). CAUTION Make sure that the machine's power is off before performing work.
  • Page 105 While taking care not to let the springs fall out, lift the cap upward keeping it horizontal. Hold the ink tubes with the forceps. 10. Pull out the ink tubes at the locations indicated by circles. Be careful of splashing ink. 11.
  • Page 106 13. Secure the cap unit by tightening the screw at the center with the hex key (width: 2.5 mm). 14. Grease may have oozed out of the surface of the lip section. Wipe the lip section gently using the clean stick moistened with maintenance liquid. 15.

  • Page 107: Wiper Replacement

    5.2. Wiper Replacement Frequency When necessary/When a problem occurs (For example, when nozzle clogging is not resolved by cleaning) User Permissions Personal Protective Eye protection, protective gloves and clothing Equipment Required Items Replacement wiper unit, hex key (width: 2.5 mm), maintenance liquid, clean stick, cleaning wiper, plastic container Be sure to wear eye protection.
  • Page 108 Open the front protection cover. Remove the wiper unit (assembly). Loosen the screw that secures the wiper unit at the center with the hex key (width: 2.5 mm) and remove the wiper unit. CAUTION Make sure that the machine's power is off before performing work.
  • Page 109 Wipe the location where the wiper unit is removed using the cleaning cloth or clean stick moistened with maintenance liquid. Attach a new wiper unit. Insert the pin at the installation position into the hole on the bottom surface of the wiper unit. Hole on the bottom surface 10.
  • Page 110 11. Grease may have oozed out of the rubber surface. Wipe the wiper rubber section gently using the clean stick moistened with maintenance liquid. 12. After replacement, make sure that no tools or other items are left on the print head operating area or carriage operating area.

  • Page 111: Towel Roller Fabric Replacement

    5.3. Towel Roller Fabric Replacement Frequency When necessary/When a problem occurs When to Replace Replace the fabric attached to the towel roller when it is very wet or dirty. If you continue to use it without replacing it, the water left on the belt will not be sufficiently wiped up, leaving water remaining on the belt.
  • Page 112 Place the towel roller on a horizontal location. Peel off the double-sided tape from the edge of the fabric, and remove the fabric. Use a wipe cloth soaked in alcohol disinfectant to remove any tape adhesive left on the towel roller shaft. Spread out the replacement fabric on a level location free from foreign material.
  • Page 113 Apply double-sided tape to the towel roller shaft. 10. (1) Peel off the liner of the tape applied to the towel roller, then (2) press the tape up against the fabric edge to adhere it. 11. Turn the towel roller horizontally to roll up the fabric.
  • Page 114 12. When you reach the edge of the fabric, peel off the curing tape and apply double-sided tape to the fabric edge. 13. Peel off the tape liner, and then adhere the fabric edge to the towel roller. 14. Attach the towel roller to this machine. Firmly hold the towel roller in both hands, and move to the rear of this machine.

  • Page 115: Washing T-Shaped Scraper Replacement

    5.4. Washing T-shaped Scraper Replacement Frequency When necessary When to Replace When the area in contact with the glue belt is worn/deteriorated. If the contacting area is worn/deteriorated, water cannot be wiped off completely after belt cleaning, resulting in water remaining on the belt. User Permissions Personal Protective Protective gloves and clothing...
  • Page 116 Remove the fixing plate that secures the washing T-shaped scraper to be replaced. Remove the screw and washer [1] on the fixing plate on the side to be pulled out using the spanner (width: 7 mm), and remove the fixing plate [2]. Be careful not drop the screw, washer, and fixing plate into the cleaning tank.
  • Page 117 Pull out the scraper. If fluffy dust has become fused, remove it first as the scraper may be stuck when pulled out. 10. Insert a new scraper in the location where the scraper was pulled out. 11. Tighten the 10 screws that secure the whole scraper using the spanner (width: 7 mm) and hex key (width: 2.5 mm).
  • Page 118 13. Return the belt cleaning tank to the original position. Return the belt cleaning tank to the carriage rail. Attach the stopper and remove the belt cleaning unit wheels. When returning the belt cleaning tank to the original position, check if the two fasteners on the belt cleaning tank are touching the machine, and if the belt cleaning tank is touching the belt cleaning unit position sensor.
  • Page 119 14. Tighten each screw on the two fasteners on the belt cleaning tank with the hex key (width: 6 mm). 15. Turn the left drain valve in the direction of the arrow to open it.

  • Page 120: Washing Silicone Scraper Replacement

    5.5. Washing Silicone Scraper Replacement Frequency When necessary When to Replace When the area in contact with the glue belt is worn/deteriorated. If the contacting area is worn/deteriorated, water cannot be wiped off completely after belt cleaning, resulting in water remaining on the belt. User Permissions Personal Protective Protective gloves and clothing...
  • Page 121 Return the belt cleaning tank to the original position. Perform Procedures 12 to 13 in 5.4. (See: 5.4 Washing T-shaped Scraper Replacement) When returning the belt cleaning tank to the original position, check if the two fasteners on the belt cleaning tank are touching the machine, and if the belt cleaning tank is touching the belt cleaning unit position sensor.

  • Page 122: Pressure Roller Replacement

    5.6. Pressure Roller Replacement Frequency When necessary User Permissions Personal Protective Protective gloves and clothing Equipment Required Number of Workers Required Items Replacement pressure roller Check that the machine is in the Printing Standby Status. (See: 1.5.2 Printing Standby Status) Operate the button to move the pressure roller toward you and stop it.
  • Page 123 Insert the stopper pins on both sides. CAUTION Make sure that the machine's power is off before performing work. Lift the pressure roller vertically to remove it. Make sure that removal and installation of the pressure roller is performed by CAUTION two workers due to the weight of the roller.
  • Page 124 10. From the removed pressure roller, remove the two bearings and replace them. 11. Attach a new pressure roller. 12. Remove the stopper pins on both sides. 13. Close the rear protection cover. 14. Turn the main power switch to 1 (ON) to turn the power on. 15.

  • Page 125: Glue Re-Application

    The following is the protective equipment that must be worn when using the glue or glue remover Equipment recommended by Epson. For details, refer to the instructions of the SDS for the glue and glue remover you are actually using.
  • Page 126 Required Items Item Quantity Details Glue collection bucket Bundled item 2 sheets bundled. After these are used, use commercially available felt Glue-removal felt 1 sheet products of the same size: 190 (Width) x 45 (Length) cm {75 x 18 in} Recommended product ・Cleanser TS (Murayama Chemical...
  • Page 127 Required Items Item Quantity Details Rubber spatula or plastic spatula (a material that does not dissolve in organic solvents) Commercially available Bags or plastic sheets (a material that does not dissolve in organic solvents) Commercially available. Proper Used to protect the belt amount cleaning tank and electric box.
  • Page 128 6.1.1 Preparation Check that the machine is in the Power Off Status. Two persons are required to remove the fabric. (See: "Operation Guide" - "Set the Fabric") CAUTION Make sure that removal and installation of the fabric roller is performed by two or more workers due to the weight of the fabric.
  • Page 129 Remove the fabric feeding position sensor. Fabric feeding position sensor Turn by hand and loosen screw [1] under the sensor and remove the sensor in direction [2]. Open the rear protection cover. Remove the fabric guide bar. Remove the screws on each side of the roller (1 each) using the hex key (width: 6 mm). Two persons are required to remove the fabric guide bar.
  • Page 130 Remove the tension roller. Remove the screws on each side of the roller (2 each) using the hex key (width: 5 mm). Two persons are required to remove the tension roller. Remove the catching-prevention cover of hair and body parts on the right and left sides of the belt. Remove the screws (2 each on left and right) of the catching-prevention cover using the hex key (width: 4 mm).
  • Page 131 Use a spanner (width: 7 mm) to loosen the screw on the blower hose, and remove the blower hose from the blower. Loosen and remove the screws on the blower (4 each) using the hex key (width: 5 mm). With two persons, pull out the blower toward you and remove it.
  • Page 132 Remove the pressure roller. Lift the pressure roller vertically to remove it. CAUTION Make sure that removal and installation of the pressure roller is performed by two workers due to the weight of the roller. When lifting a pressure roller, lift with your legs and not your back. Remove the belt holder covers from both sides of the belt.
  • Page 133 Pull out the belt cleaning tank. Perform Procedures 1 to 6 in 5.4. (See: 5.4. Washing T-shaped Scraper Replacement) Cover the belt cleaning tank and the electric box on the underside of the feeding side, so they do not become soiled by glue or solvents.
  • Page 134 Move to the rear of the machine, and install the blade installation parts on the right and left. Install next to the belt and tighten the screws (1 each on right and left) using the hex key (width: 5 mm). Attach the felt to the application rod.
  • Page 135 Place the application rod on the belt. Secure the application rod and blade installation parts with cable ties.
  • Page 136 6.1.2 Glue Removal Turn the main power switch to 1 (ON) to turn the power on. Insert the maintenance key in [Maintenance] and turn it to the right. Leonardo switches to the glue application mode. CAUTION Do not insert the maintenance key except for when applying glue. Inserting the maintenance key disables the belt operation safety function, resulting in a dangerous situation.
  • Page 137 Pour the glue remover into the glue remover bucket. CAUTION When using the glue remover, wear the personal protective equipment for organic solvent use, such as protective gloves, eye protection, and respiratory protection. Soak the felt with an appropriate amount of glue remover (approx. 2 L). Worker 1 (at the rear of the machine): Soak the felt a little at a time so that the remover completely permeates the felt.
  • Page 138 Remove the glue from all areas of the belt. Worker 1 (at the rear of the machine): To prevent the glue remover on the surface of the belt from drying, soak the entire surface of the felt with more glue remover. Worker 2 (at the front of the machine): Securely grasp the handles of the glue collection bucket with both hands and press it against the belt surface to scrape away the glue.
  • Page 139 Belt Surface Cleaning 6.1.3 Use a wipe cloth soaked in ethanol (proper amount) to wipe the belt surface. When the belt surface is completely clean, slowly rotate the belt and wipe clean using an ethanol-soaked cloth. Wipe off the glue until the belt surface has a luster. Be especially careful to remove the glue from both edges of the belt.
  • Page 140 The following is the protective equipment that must be worn when using the glue or glue remover Equipment recommended by Epson. For details, refer to the instructions of the SDS for the glue and glue remover you are actually using.
  • Page 141 Required Items Item Quantity Details Glue application blocks Bundled item Bucket for glue Commercially available Scale Commercially available Scissors Commercially available Stirring rod for preparing glue Commercially available Hex key 1 set Commercially available Glue (1st layer): ATR1945 (ML/T) 1.6 kg Recommended product Glue (2nd layer): ATR1946 (ML/S) 0.8 kg...
  • Page 142 CAUTION Wear eye protection, protective gloves, protective clothing, and respiratory protection when performing these procedures. Check the Safety Data Sheet (SDS) for the glue or remover you will actually use for details, and wear the necessary protective gear. - Wear a hat so that your hair does not fall onto the belt. - Long hair should be tied back and worn under a hair net.
  • Page 143 6.2.1 Preparation 1. Clean the belt surface. Use a wipe cloth soaked in ethanol (proper amount) to wipe the belt surface clean while slowly feeding the belt. Wipe off the glue until the belt surface has a luster. Be especially careful to remove the glue from both edges of the belt.
  • Page 144 4. Check that a check mark is placed in [Feedrate enable] in Leonardo before clicking [+]. When continuously feeding the belt, you can adjust the feeding speed using the volume in the electric box. 5. Dry the belt. Set the scale of the volume in the electric box to 5, and then rotate the belt in the forward direction for 30 minutes. 6.
  • Page 145 8. Stop rotation of the completely affixed belt and overlap the tape seams by about 5 to 10 mm. 9. Slowly rotate the belt again while checking there is no foreign material adhering to the belt and remove any that is found.
  • Page 146 12. Align the holes on each end of the blade with the supports on the blade installation parts, and slowly and evenly lower the blade on both right and left sides to avoid damaging the belt. 13. Rotate the belt a little in the forward direction and stop. This operation sets the blade at a slight angle against the belt.
  • Page 147 14. Place one glue application block on each end of the belt so that they are aligned with the edge of the blade. When placing the blocks, do not place them on the seams of the insulating tape applied to both sides of the belt. If the seams of the insulating tape come where you want to place the blocks, feed the belt to where there are no seams.
  • Page 148 15. Affix the glue application blocks to both ends of the blade using insulating tape so that there are no gaps in the following: - Between the block and the belt - Between the block and the blade CAUTION Do not affix the blocks in the states described below. There is a risk that the glue may not be applied evenly, or the glue may leak from the belt edge into the machine, causing a malfunction.
  • Page 149 6.2.2 Glue Preparation 1. Prepare the glue for the first layer. Set the glue bucket on the scale and pour in the glue (ATR1945 (ML/T), 1.6 kg). CAUTION When using the glue, wear the personal protective equipment for organic solvent use, such as protective gloves, eye protection, and respiratory protection.
  • Page 150 6.2.3 Glue Application (1st Layer) 1. Rotate the belt in the forward direction. Set the scale of the volume in the electric box at 4 to 6, and then rotate the belt in the forward direction. 2. Apply the 1st-layer glue. Pour a proper amount of glue to right next to the blade. Pour so that the glue flows from the center to both edges.
  • Page 151 6.2.4 Glue Application (2nd Layer) 1. Maintain the belt rotation speed as it is, and when the 1st-layer glue has nearly all been used, pour the 2nd-layer glue. Pour the 2nd-layer glue before the 1st-layer glue has all been used. It is not necessary to pour all of the glue at once.
  • Page 152 2. After it has been completely poured, prepare the soapy water, and gradually pour the soapy water above the belt before locations where the 2nd-layer glue has nearly all been used. The soapy water creates a water repellent membrane on the belt surface so that the glue and blade can be easily separated.
  • Page 153 3. Check that the glue accumulated in front of the blade has been completely used and soapy water is completely applied.
  • Page 154 6.2.5 Blade Removal 1. Two persons are required to lift the blade evenly on both right and left sides, and remove it. Be careful that the blade does not contact the belt surface when removing it. 2. Wipe the blade, glue application blocks, and glue buckets clean using ethanol. If the dirt cannot be removed, soak a wipe cloth in glue remover to wipe off any glue.
  • Page 155 6.2.6 Drying 1. Set the scale of the volume in the electric box to 10, and then rotate the belt in the forward direction for 2 hours. 2. Set the scale of the volume in the electric box to 0 and then stop the rotation of the belt. 3.
  • Page 156 6. Return the belt cleaning tank to the original position. Perform Procedures 13 to 16 in 5.4. (See: 5.4. Washing T-shaped Scraper Replacement) When returning the belt cleaning tank to the original position, check if the two fasteners on the belt cleaning tank are touching the machine, and if the belt cleaning tank is touching the belt cleaning unit position sensor.
  • Page 157 9. Install the catching-prevention covers of hair and body parts on the right and left sides of the belt. Install the catching-prevention covers, and tighten the screws (2 each on right and left) using the hex key (width: 4 mm). 10.
  • Page 158 13. Tighten the screws on the blower (4 each) using the hex key (width: 5 mm). 14. Cover the blower with the blower hose, up to the position indicated in the figure.
  • Page 159 15. Use a spanner (width: 7 mm) to tighten the screw on the blower hose. 16. Attach the tension roller. Use two persons to attach the tension roller in the original position. Tighten the screws on each side of the roller (1 each) using the hex key (width: 5 mm).

This manual is also suitable for:

Evo tre 16-180

Table of Contents
