SMC Networks SMCGS501 - FICHE TECHNIQUE Product Overview

SMCGS501/SMCGS801
EZ Switch TM 5- and 8-port Gigabit Ethernet Switches
Product Overview
The SMC EZ Switch 10/100/1000, SMCGS501 and SMCGS801, are 5- and 8-port
unmanaged 10/100/1000 Mbps Gigabit Ethernet switches with metal chassis that
bring the speed of Gigabit copper to the desktop. Environmentally friendly, they
consume up to 75% less power than non-green Ethernet switches, without reducing
network performance. QoS priority and Auto-MDI/MDIX on all ports makes these
Gigabit desktop switches ideal for home and small office network environments.
Key Features and Benefits
IEEE P802.3az Energy-Efficient Ethernet Support
When two 802.3az-compliant switches are connected, up to
75% of power consumption can be saved.
Support for IEEE 802.1p Quality of Service
The switch supports 802.1p Quality of Service, which is useful
in implementations where time-sensitive data, such as voice
and video, are streamed across the network.
Broadcast Storm Control and CRC Filtering
Broadcast storm control prevents broadcast traffic storms from
consuming bandwidth, and CRC filtering stops bad packets
from propagating throughout the network.
68
SMCGS501
Support for Jumbo Packets
Support for Jumbo packets of up to 9K Bytes in size.
Auto MDI/MDI-X on Each Port
Support for Auto-MDI/MDIX means that no crossover cables
are required. Straight-through cables can be used for all
connections.
802.1p
QoS
SMCGS501
POWER TO CONNECT
www.smc.com
802.3az
75
SMCGS801
