Lutron Electronics Sivoia QS Wireless Installation Manual

Sivoia QS Wireless Drapery Lite System
Installation Guide-Please Read Before Installing
Important Notes - Please Read Before Installing
A. Lutron systems are intended for use with only Lutron hardware
and power supplies.
B. Codes: Install in accordance with all local and national
electrical codes.
C. Environment: Ambient operating temperature: 32 °F - 104 °F
(0 °C - 40 °C), 0 - 90% humidity, non-condensing.
Indoor use only.
D. Plan the installation to maintain sufficient clearance between
the moving drapery and any object, including window
hardware, cranks, lock levers, and stationary drapery.
! CAUTION: RISK OF FALLING OBJECTS. Securely install the
shade system per the mounting instructions.
Failure to do so could result in minor or moderate injury.
Tools required:
• Tape measure
• Small flat-blade screwdriver
• #1 Phillips screwdriver
• #2 Phillips Screwdriver
System Components:
Drapery Track
Single-track, right-draw system shown; dual systems will include additional track(s) and EDU(s)
Included with
wall-mount tracks:
Extendable
Wall-Mount
Bracket, Single*
Included with
ceiling-mount tracks:
Ceiling-Mount
Cam-Lock with Washer*
*Quantity varies with system width
Customer Assistance
USA and Canada: 1.844.LUTRON1 (588-7661) | UK: +44.(0)20.7702.0657 | lutron.com/help | support@lutron.com
For product warranty information, please see: lutron.com/TechnicalDocumentLibrary/Window Systems Warranty.pdf
Lutron Electronics Co., Inc.
7200 Suter Road
Coopersburg, PA 18036-1299, U.S.A.
Included with dual
wall-mount
tracks:
Extendable
Wall-Mount
Bracket, Dual*
Included with recess-mount tracks:
Recess-Mount #8 x 1½ inch
Bracket* Wood Screw*
11/2024
P/N 045985 Rev. A
Contents
1
Wall Mount ____________________________________________ 2
2
Ceiling Mount _________________________________________ 3
3
Recess-Mount: Prepare the Drapery Track _______________ 4
4
Recess Mount _________________________________________ 5
5a
Installing the EDU in Slim Orientation ______________________ 5
5b
Installing the EDU in Original Orientation ___________________ 6
6
Basic Wiring ___________________________________________ 6
7
Fabric Installation _______________________________________ 7
8
Ripplefold Fabric Installation ______________________________ 8
9
Power Up the Drapery and Assign a Control ________________ 10
10
Setting Open and Close Limits ___________________________ 11
Restoring Factory Default Settings ______________________ 12
• Power drill and drill bits
• Level
• Pliers
• 3/32 in hex key (included w/recess-mount system)
Terminal Block
Electronic Drive Unit (EDU) with
end motor bracket attached
EDU Model: QSSC-EDU-D105-DL
†
Lutron, the Lutron logo, and Sivoia QS are trademarks or registered
trademarks of Lutron Electronics Co., Inc., in the U.S. and/or other
countries.
English
†
24-36 V- 41 W
