INSTALLATION INSTRUCTIONS FOR REFRACTORY PANEL KITS AND MASONRY BRICK PANEL KITS
F3433, FOR USE WITH: WRT3538WS
F3434, FOR USE WITH: WRT3538WH
F3437, FOR USE WITH: WRT3543WS
F3438, FOR USE WITH: WRT3543WH
CAT NO.
DESCRIPTION
REFRACTORY PANEL KIT
(Stacked Refractory Shown)
F3433
Kit, 38" White Stk Refractory Panels
F3434
Kit, 38" White HB Refractory Panels
F3437
Kit, 43" White Stk Refractory Panels
F3438
Kit, 43" White HB Refractory Panels
MASONRY BRICK PANEL KIT
(Split Herringbone Shown)
F3435
Kit, 38" Ivory Split Stk Masonry Panels
F3436
Kit, 38" Ivory Split HB Masonry Panels
F3439
Kit, 43" Ivory Split Stk Masonry Panels
F3440
Kit, 43" Ivory Split HB Masonry Panels
TOOLS REQUIRED
•
5/16 Hex Nut-driver
GENERAL INFORMATION
This document contains installation instructions for Refractory
Panel and Masonry brick panel kits for use with models listed
above. Use care to prevent breakage when handling the panels.
IMPORTANT: Installation of refractory panels/brick panels
should be done after the fireplace is placed in a permanent
location.
READ ALL THE STEPS BEFORE STARTING THE INSTALLATION
THE FIREPLACE MUST BE OFF AND COLD BEFORE BEGINNING.
P/N 900858-00
REV. A, 09/2017
F3435, FOR USE WITH: WRT4038IS
F3436, FOR USE WITH: WRT4038IH
F3439, FOR USE WITH: WRT4043IS
F3440, FOR USE WITH: WRT4043IH
Left
Refractory
Panel 1 ea.
Hearth
Refractory
Panel 1 ea.
L e f t M a s o n r y
Brick Panel 1 ea.
Hearth Masonry
Brick Panel, 1 ea.
ALL WARNINGS AND PRECAUTIONS IN THE INSTALLATION AND
OPERATION MANUAL PROVIDED WITH THE FIREPLACE APPLY TO
THESE INSTRUCTIONS.
If you encounter any problems, need clarification of these instruc-
tions or are not qualified to properly install this kit, contact you
local distributor or dealer.
If any of these parts are missing or damaged, contact your dealer
or IHP.us.com for referral information.
IMPORTANT NOTE: Do not force the panels. Excessive force may
cause breakage. If the panels are correctly positioned, they will fit
snugly in place.
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE
HEARTH PRODUCTS
KITS AND ACCESSORIES
REFRACTORY PANEL KITS AND
MASONRY BRICK PANEL KITS
KIT CONTENTS
Retainer Refractory, 3 ea.
Retainer Refractory, 3 ea.
R e a r M a s o n r y
Brick Panel 1 ea.
Right Masonr y
Brick Panel 1 ea.
Rear Refractory
Panel 1 ea.
Right
Refractory
Panel 1 ea.
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for IHP F3433
Summary of Contents for IHP F3433
- Page 1 MASONRY BRICK PANEL KITS P/N 900858-00 REV. A, 09/2017 INSTALLATION INSTRUCTIONS FOR REFRACTORY PANEL KITS AND MASONRY BRICK PANEL KITS F3433, FOR USE WITH: WRT3538WS F3435, FOR USE WITH: WRT4038IS F3434, FOR USE WITH: WRT3538WH F3436, FOR USE WITH: WRT4038IH...
- Page 2 7. Install grate, screen assemblies and all hardware components removed in step 1. WARNING: Risk of fire! Replace grate with IHP grate only (catalog No. J4381 for 38” models and J4382 for 43” models). This grate has been designed to keep the operation of your fireplace Figure 2 - Installing Refractory Panels safe and efficient.
- Page 3 MASONRY BRICK PANEL INSTALLATION INSTRUCTIONS 1. Remove grate, screen assemblies, masonry brick panels if installed and all hardware components out of the firebox. Front 2. Install masonry brick hearth panel centered in the firebox and Cover flush with the front of the fireplace. Be careful not to pinch Plate your fingers between the panel and firebox (Figure 4).
- Page 4 NOTE: DIAGRAMS AND ILLUSTRATIONS ARE NOT TO SCALE. IHP reserves the right to make changes at any time, without notice, in design, materials, specifications, and prices, and also to discontinue colors, styles, and products. Consult your local distributor for fireplace code information.
