IHP F1762 Manual

FM100 FLOOR MEDIA KIT
[FOR USE WITH APPLIANCE MODELS BLAZE&GLOW18/24, MAGNIFLAME24/30, MULTISIDED27, DUAL-FLAME EOS18, MONTEBELLO18/24, SHERIDAN18/24, MNF24/30/36
LMF24/30/36, GLOWRAMP LBG18/24/30/36, MULTI-SIDED FVFM27, VF18/24, DUAL-BURNER VD1824, SINGLE-BURNER VS1824, SOMERSET27 FVFM27]
KIT CONTENTS
9 ea. Fiber Log Pieces
1 ea. Volcanic Stone
1 ea. Ember Material
1 ea. Instruction Sheet
Cat. No. Model
F1762 FM100
REQUIRED TOOLS AND SUPPLIES
None
f i r e - p a r t s . c o m
GENERAL INFORMATION
The fl oor media kit is used to give a more natural appearance to the
fi replace fl oor where the gas log set is installed.
READ ALL THE STEPS BEFORE STARTING THE INSTALLATION
THE APPLIANCE MUST BE OFF AND COLD BEFORE BEGINNING.
ALL WARNINGS, PRECAUTIONS AND INSTRUCTIONS IN THE
INSTALLATION AND OPERATION MANUAL PROVIDED WITH THE
APPLIANCE APPLY TO THESE INSTRUCTIONS.
If you encounter any problems, need clarifi cation of these instructions
or are not qualifi ed to properly install this kit, contact you local
distributor or dealer.
If any of these parts are missing or damaged, contact your dealer or
IHP.us.com for referral information.
WARNING
• Make sure the unit is turned off and cool before
adding fl oor media material to fi replace fl oor.
• Do not add extra logs or ornaments such as pine
cones, vermiculite or glowing embers (rockwool).
Using these added items can cause sooting. Use
only the material included in this kit.
• Do not place volcanic stone, embers or fi ber log
pieces on logs or burners. This may cause sooting.
Place fl oor media material only on the fi replace fl oor.
P/N 115579-01
Rev. B, 04/2017
Description
Floor Media Kit
IHP.us.com
Figure 1 - FM100 Floor Media Kit
INSTALLING FLOOR MEDIA KIT
1. Place decorative log pieces randomly as desired on fi replace hearth.
Place volcanic stone around base of unit making sure the burner
ports and valve access are not blocked (see Figure 2). Retain a
small amount of volcanic stone to be used in step 4.
Figure 2 - Placing Volcanic Stone
HEARTH PRODUCTS
KITS AND ACCESSORIES
FM100 FLOOR MEDIA KIT
1
