Page 1: Table Of Contents
Replacement Thermal Germ Barrier Extra I-Tap Exchange Extra I-Tap temperature sensor Repair thread housing screw Extra I-Tap Replace Extra I-Tap fan motor and fan blade Replacement E-Box Extra I-Tap Replacement of insulation cooling line Replacement of the Extra I-Tap pressostat... -
Page 2: Repair Extra I-Tap Pump
Exchange / repair Top Pro & Extra I-Tap pump... - Page 3 Remove water and CO2 1. Close H2O and draw off the device by drawing off still water. 2. Then close the CO2 bottle. Establish a stress-free state 1. Switch off the device using the power switch. 2. First disconnect the power plug from the socket and then from the device.
- Page 4 Separate motor and head 1. As soon as the screw clamp is loosened, the head can also be removed without a motor. The clamp can be reached from the front. 2. The spacer (serves to reduce the running noise) must be present. 3.
-
Page 5: Extra I-Tap Co2 Pressure Relief Valve
Exchange / repair Top Pro & Extra I-Tap CO2 pressure relief valve... - Page 6 Remove water and CO2 1. Close H2O and draw off the device by drawing off still water. 2. Then close the CO2 bottle. Make water dispenser tension-free 1. De-energize the water dispenser - pull out the plug. 2. Note: The locking hook is used to prevent it from being pulled of.
- Page 7 Remove pressure relief valve 1. In the first step, the red safety clips are removed. 2. The relief valve is then pulled off the hose with a release aid. Pressure can escape carefully here. 3. The new pressure relief valve can then be installed. Note: Small opening on the pressure relief valve must always point downwards.
-
Page 8: Exchange/Repair Drip Tray Sensor
Exchange / repair drip tray sensor... - Page 9 Make water dispenser tension-free 1. De-energize the water dispenser - pull out the plug. 2. Note: The locking hook is used to prevent it from being pulled of. Disassemble the housing Disassembly of the drip tray sensor 1. First, the electrical connection of the drip tray cable harness is disconnected at the bottom left of the dis- penser shaft.
-
Page 10: Exchange/Repair Extra I-Tap Hmi
Exchange / repair Extra I-Tap HMI... - Page 11 Remove water and CO2 1. Close H2O and draw off the device by drawing off still water. 2. Then close the CO2 bottle. Establish a stress-free state 1. Switch off the device using the power switch. 2. First disconnect the power plug from the socket and then from the device.
-
Page 12: Exchange Compensator Block Extra I-Tap
Exchange compensator block Top Pro / Extra I-Tap... - Page 13 Remove water and CO2 1. Close H2O and draw off the device by drawing off still water. 2. Then close the CO2 bottle. Establish a stress-free state 1. Switch off the device using the power switch. 2. First disconnect the power plug from the socket and then from the device.
- Page 14 Set the flow diagram 1. Set the CO2 pressure to 65 psi 2. Draw off the sparkling water and measure the flow rate per minute. This must be less than 1.7 l / min. If the flow rate is too high, turn the lower adjusting screw in slightly and measure the flow rate again. Repeat this until the flow rate is between 1.6 and 1.7 l / min.
-
Page 15: Exchange Of The Check Valves Extra I-Tap
Exchange of the check valves Top Pro / Extra I-Tap... - Page 16 Remove water and CO2 1. Close H2O and draw off the device by drawing off still water. 2. Then close the CO2 bottle. Establish a stress-free state 1. Switch off the device using the power switch. 2. First disconnect the power plug from the socket and then from the device.
-
Page 17: Remove Check Valve
Remove check valve 1. To remove the check valves, the safety clips must first be loosened. 2. The easiest way to remove connectors is to use the release aid. Perform dry cleaning 1. Perform dry cleaning via admin menu (code 0112) -
Page 18: Replacement Thermal Germ Barrier Extra I-Tap
Replacement Thermal Germ Barrier Extra I-Tap... - Page 19 Establish a stress-free state 1. Switch off the device using the power switch. Remove cover with HMI 1. Loosen the grub screw on the back of the cover (image 1). Allen key 1.5 mm 2. Then turn the cover with the HMI counterclockwise and carefully lift it up a little. 3.
- Page 20 Removal of the outlet tube 1. Remove the fastening screw of the outlet tube (Fig. 1). 2. With newer taps, the screw sits a little further inside on the clamping ring of the outlet tube (Fig.2). 3. Pull out the outlet pipe a little. Remove the safety clip and disconnect the hose on the outlet side from the connector (image 3).
- Page 21 Removing the heating element (3) 1. Grasp the screw with pliers and carefully pull out the plastic guide (photo 1). Make sure that the connection cables are not damaged. 2. By pulling on the screw, the plastic guide is pressed against the locking mechanism of the connector. The connector is thus released and can be removed from the outlet pipe.
- Page 22 Installation of the heating element 1. Spray all connection points (thermal gate / hose) with disinfectant before installation. 2. Insert the heating element from the outlet side. Unscrew the screw from the plastic guide and insert the guide in the outlet pipe 3.
-
Page 23: Functional Test
Adjust the tap spout 1. Adjust the spout of the tap so that the water jet runs vertically down to the center of the drip tray. 2. Use a suitable and disinfected tool for this. Carry out cleaning 1. Carry out cleaning via the menu. Functional test 1. -
Page 24: Exchange Extra I-Tap Temperature Sensor
Exchange Top Pro & Extra I-Tap temperature sensor... - Page 25 Establish a stress-free state 1. Switch off the device using the power switch. 2. First disconnect the power plug from the socket and then from the device. To do this, push the red snap-in hooks (pull-out protection) to the rear. 3.
-
Page 26: Repair Thread Housing Screw Extra I-Tap
Repair thread housing screw Extra I-Tap... - Page 27 Remove side panel Position of the threaded sleeve 1. Picture 1 shows the hole of the torn out threaded sleeve. Picture 2 shows an undamaged threaded sleeve. Mount threaded insert 1. Remove lock nut. Then insert the sleeve and fasten it from the inside with a lock washer and lock nut.
-
Page 28: Replace Extra I-Tap Fan Motor And Fan Blade
Replace Top Pro Extra I-Tap fan motor and fan blade... - Page 29 Establish a stress-free state 1. Switch off the device using the power switch. 2. First disconnect the power plug from the socket and then from the device. 3. To do this, push the red snap-in hooks (pull-out protection) to the rear. Disassemble the housing Loosen electrical connections and screw 1.
- Page 30 2. Installation is carried out in the reverse order to removal. 3. Table-top units (Top Pro) and under-table units (Extra I-Tap) have different fan wheels (image 2). When installing, ensure that the correct fan wheel is used and installed in the correct direction.
-
Page 31: Function Control
Figure 2. Function control 1. Switch on the device and wait until the fan starts up. 2. Check whether the air is blown outwards on the Extra I-Tap (Image 1) or sucked in on the Top Pro (Image 2) -
Page 32: Replacement E-Box Extra I-Tap
Replacement E-Box Top Pro & Extra I-Tap... - Page 33 Remove water and CO2 1. Close H2O and draw off the device by drawing off still water. 2. Then close the CO2 bottle. Make water dispenser tension-free 1. De-energize the water dispenser - pull out the plug. 2. Note: The locking hook is used to prevent it from being pulled of.
-
Page 34: Replacement Of Insulation Cooling Line
Replacement of insulation cooling line Top Pro and Extra I-Tap... -
Page 35: Delivery Status
Remove water and CO2 1. Close H2O and draw off the device by drawing off still water. 2. Then close the CO2 bottle. Make water dispenser tension-free Switch off the device using the power switch. 2. First disconnect the power plug from the socket and then from the device. - Page 36 Attach insulation to the suction line 1. The thickness of the insulation should be at least 6 mm. If the 3 mm thick insulation is used, it must 2. therefore be laid twice (4 strips required from both sides). 3. Cut 14 cm long strips (50 mm wide) for the suction line. 4.
-
Page 37: Replacement Of The Extra I-Tap Pressostat
Replacement of the Top Pro & Extra I-Tap pressostat... -
Page 38: Chemical Cleaning
Remove water and CO2 1. Close H2O and draw off the device by drawing off still water. 2. Then close the CO2 bottle. Make water dispenser tension-free Switch off the device using the power switch. 2. First disconnect the power plug from the socket and then from the device. -
Page 39: Replacement Of Solenoid Valves Extra I-Tap
Replacement of solenoid valves Extra I-Tap... - Page 40 Remove water and CO2 1. Close H2O and draw off the device by drawing off still water. 2. Then close the CO2 bottle. Make water dispenser tension-free Switch off the device using the power switch. 2. First disconnect the power plug from the socket and then from the device.
-
Page 41: Installation
Removal of the solenoid valve 1. In the first step, pull the plug on the valve. (see first photo) 2. Then loosen the red safety clips. 3. The best way to loosen the connections is to use the release aid. 4.
