- Page 1 Installation Guide Extra I-Tap...
- Page 2 Step 1 — Unpack the device and inspect the parts • To unpack the device, pull the packaging upwards. • Check for completeness of the installation kit and accessories. Which are in the upper part of the box. Step 2 — Examination installation environment •...
- Page 3 Step 3 —Insert drip tray • Apply clear silicon to the bottom edge of the drip tray. • Insert drip tray with drain hose (image 1) and press on. • Remove excess sealant. • Bend the fastening tabs on the underside of the drip tray. Step 4 —...
- Page 4 Step 5 — Guide the data cable through the ferrite ring • Guide the data cable through the ferrite ring and wrap it around the ferrite ring a total of 2 times. • The ferrite ring should be positioned as high as possible in front of the threaded sleeve of the tap.
-
Page 5: Step 7 - Connection Concept
Step 7 — Connection concept • The water connection concept must already be implemented as described above. • Important: : When attaching the filter head, there should be enough distance from the filter head to the worktop so that the head of the filter can be changed if necessary. •... - Page 6 Step 8— Remove sidewalls • Open the housing (instructions below)* • Check the device for possible leaks. Open / close the I-Tap housing Instructions* Step 1— Establish a stress-free state • Switch off the device using the power switch. • First disconnect the power plug from the socket and then from the device.
- Page 7 Step 2 — Remove sidewalls • The left side wall can be dismantled individually. The right side wall is a component together with the upper part of the housing. • For most activities it is sufficient to dismantle the left side wall. •...
- Page 8 Step 5 — Dismantling the hood • Loosen 4 screws. • When installing , make sure that the hood is pushed all the way down. There should be no gap between the scoop and the floor of the base unit.
- Page 9 Step 9 — For devices with the Hygiene Plus option • The SX3 hygiene filter is enclosed separately on delivery. The point at which this is later used is bridged with a piece of hose. The SX3 filter is only used in the course of the cleaning program (step 8)! •...
-
Page 10: Step 12 - Chemical Cleaning
Step 11 — Adjust the tap spout • Adjust the spout of the tap so that the water jet runs vertically down to the center of the drip tray. • Use a suitable and disinfected tool for this. Step 12 — Chemical cleaning •... - Page 11 Dry cleaning Top Pro & Extra I-Tap with Iodophore USA Only or Huwa-San Canada Only Step 1— Preparations • During the entire cleaning process, it must be ensured that no drinking water is drawn off. If the housing is open, the device must be protected against access. Caution! Danger to life in the event of electric shock by touching live parts! •...
- Page 12 Step 3 — only with Hygiene Plus: insert a new SX3 filter • Not relevant for devices without the Hygiene Plus option. • Insertion of the new SX3 filter. It is essential to wear clean gloves because a sterile filter. The connectors are sprayed with alcohol-based disinfectant •...
- Page 13 Step 5 — Service cartridge insert • Cold water filter Pull cartridge out of filter head. • Insert new input filter. • Disconnect the line to the device and place it in a container / bucket. • Open H2O and rinse the filter with water according to the manufacturer‘s instructions (Clarity button 1L). •...
- Page 14 Step 6 — Rinse in detergent • If the filling process of the carbonator cannot be completed due to high counter pressure, pull the safety valve (Fig. 1). Use a cloth to absorb any splashing water. • Draw off the respective types of water as specified by the cleaning program (first still and still chilled, then sparkling).
- Page 15 Step 8 — Empty the carbonator • Remove the service cartridge and insert a new pre-rinsed cold water filter cartridge. Step 9 — Rinse out cleaning agent • Open the water supply. • Place a vessel under the outlet. The cleaning program carries out rinses for all types of water. The carbonator is completely flooded (overpressure valve must be pulled).
- Page 16 Step 10 — Set the flow pattern on the compensator if the flow is too fast or too slow • Set the flow diagram of the compensator. Instructions starting on the next page. • Close the housing. Step 11 — Ensure operation •...
- Page 17 Setting the Flow Diagram Step 1 — Setting flow diagram • Set the CO2 pressure to 65 psi • Draw off the sparkling water and measure the flow rate per minute. This must be less than 1.7 l / min. If the flow rate is too high, turn the lower adjusting screw in slightly and measure the flow rate again.
