Summary of Contents for Vivreau Top Pro
- Page 1 Installation Guide Top Pro...
- Page 2 Step 1 — Unpack the device and inspect the parts • To unpack the device, pull the packaging upwards. • Check for completeness of the installation kit and accessories. Which are in the upper part of the box. Step 2 — Examination installation environment •...
- Page 3 Step 3 — Water connection concept • Make the connections at the customer water supply, water block and filter head.
- Page 4 Step 4 — Optional Drain to waste If no drain is available skip to step 6 • If the drip tray is connected to the drain hose, the blind plug must be removed. (see first picture) • To connect the hose to the drip tray, the water dispenser must be tilted slightly to the side. (see second photo) •...
- Page 5 • Open the housing (instructions below)* • Check the device for possible leaks. • No adjustments are made to the pump. *Open / close the Top Pro housing Instructions Step 1— Establish a stress-free state • Switch off the device using the power switch.
- Page 6 Step 2 — Remove sidewalls • Remove 2 screws on the back of each side panel (image 1). • Pull the side wall backwards a little (picture 2). • Pull the side panel away from the device at the bottom and then unhook it from the latches (image 3). Step 3 —...
- Page 7 Step 4 — Remove side panels • Remove 2 screws on the back of each side panel (image 1). • Pull the side wall backwards a little (picture 2). • If necessary, use a plastic tire lever or something similar for this purpose. •...
- Page 8 Step 7 — For devices with the Hygiene Plus option • The SX3 hygiene filter is enclosed separately on delivery. The point at which this is later used is bridged with a piece of hose. The SX3 filter is only used in the course of the cleaning program (step 8)! •...
- Page 9 Dry cleaning Top Pro & Extra I-Tap with Iodophore USA Only or Huwa-San Canada Only Step 1— Preparations • During the entire cleaning process, it must be ensured that no drinking water is drawn off. If the housing is open, the device must be protected against access. Caution! Danger to life in the event of electric shock by touching live parts! •...
- Page 10 Step 3 — only with Hygiene Plus: insert a new SX3 filter • Not relevant for devices without the Hygiene Plus option. • Insertion of the new SX3 filter. It is essential to wear clean gloves because a sterile filter. The connectors are sprayed with alcohol-based disinfectant •...
- Page 11 Step 5 — Service cartridge insert • Cold water filter Pull cartridge out of filter head. • Insert new input filter. • Disconnect the line to the device and place it in a container / bucket. • Open H2O and rinse the filter with water according to the manufacturer‘s instructions (Clarity button 1L). •...
- Page 12 Step 6 — Rinse in detergent • If the filling process of the carbonator cannot be completed due to high counter pressure, pull the safety valve (Fig. 1). Use a cloth to absorb any splashing water. • Draw off the respective types of water as specified by the cleaning program (first still and still chilled, then sparkling).
- Page 13 Step 8 — Empty the carbonator • Remove the service cartridge and insert a new pre-rinsed cold water filter cartridge. Step 9 — Rinse out cleaning agent • Open the water supply. • Place a vessel under the outlet. The cleaning program carries out rinses for all types of water. The carbonator is completely flooded (overpressure valve must be pulled).
- Page 14 Step 10 — Set the flow pattern on the compensator if the flow is too fast or too slow • Set the flow diagram of the compensator. Instructions starting on the next page. • Close the housing. Step 11 — Ensure operation •...
- Page 15 Setting the Flow Diagram Step 1 — Setting flow diagram • Set the CO2 pressure to 65 psi • Draw off the sparkling water and measure the flow rate per minute. This must be less than 1.7 l / min. If the flow rate is too high, turn the lower adjusting screw in slightly and measure the flow rate again.
- Page 16 • Needle valves from the manufacturer Römer (Fig. 1, included in production at the end of 2020) are completely opened for the basic setting and then 4.5 turns closed for Top Pro. To fine-tune the medium spray pattern, the Römer needle valve must then be opened slightly wider.
- Page 17 Step 9 — Completion of the installation • Remove transparencies • Adjust portioning with the customer • Handover to the customer...
- Page 18 Additional top installation on base cabinet...
- Page 19 Step 1 — Unpack and control Number Description Used for Washer 6.4x18.1.6 Wall bracket Tube wall bracket Wall bracket Dowel 8x52 mm Wall bracket Screw countersunk Wall bracket head D6x160mm Screw cross recess Fixing unit to Base Cabinet M6X50 CO2 belt and clamp pressure Screw M4X8 reducer Hose clamp...
- Page 20 Step 3 — Fasten the Base Cabinet to the wall (optional) switch order to have base plate 1st • Alternatively, the Base Cabinet can also be set up freely. The base plate must be used for this, see step 4 of these instructions. •...
-
Page 21: Step 6 - Installation Of The Components
Step 5 — Place the device on the base cabinet • Attach the drain hose of the drip tray to the drip tray connection. • Attach hoses for H2O and CO2 to the device. Provide all connectors with safety clips (image 1). •...
