APRVTIO ALD-200 Manual

ALD-200 REFRIGERANT
LEAK DETECTOR
H CO HC R1234YF
2 2
PEAK
WARM UP
SEN: L
GAS/RSET PEAK
ON/OFF
SENS MUTE
https://aprvtiotech.com/ sales@aprvtiotech.com +1 713 701 1986
The ALD-200 Refrigerant Leak Detector is a hand-held leak
detector that uses the heated diode detection principle.
Compared with the traditional leak detector, its sensor
has a longer life, higher detection accuracy, easier to
operate and can detect a wider range of refrigerants.
The ALD-200 has an ergonomic design and a large LCD
screen for easy viewing.
Structure
1. Flexible probe
①
2. Case
3. Probe tip
4. USB Port
②
5. Buzzer
6. Battery
7. Peak
③
8. Leak
9. Sensitivity
10. Button
④
Setup
H CO 2 2 HC R1234YF
PEAK
WARM UP
SEN: L
GAS/RSET PEAK
ON/OFF
SENS MUTE
- Check the device has sufficient battery - Adjust the sensitivity ( sens ).
level.Turn on ( on/off button ) and wait
for 30 seconds before testing.
EN
https://aprvtiotech.com/ sales@aprvtiotech.com
- Slowly move probe ( approx 3 inch/sec )
at a distance of 0.25 inch near suspected
leak area.
Key Operation
- ON/OFF key: press the button for 2 seconds
⑤ to power on/off.
- RSET key: long press the button for 3 seconds
⑥
H CO HC R1234YF to reset sensitivity benchmark.
2 2
⑦
- PEAK key : press the button to record the
PEAK
⑧
WARM UP
maximum value of leakage.
⑨
SEN: L
- SENS key: press the button to adjust sensitivity
GAS/RSET PEAK
⑩
ON/OFF
levels. By default sensitivity is set to medium.
SENS MUTE
- MUTE key: press the button to turn on/off the buzzer.
Specifications
- Sensor type:heated Diode
- Sensor life: 500 hours
- Max sensitivity: 4 g /yr
- Alarm mode: Sound, light and LCD display
- Battery: Built in rechargeable lithium battery 3.7 V 3000 mAh
- Working time: Continuous 6 hours
- Charging time: 4 hours
H CO HC R1234YF
2 2
- Charging current: 5V DC 1A
PEAK
WARM UP
- Operating environment: -10°C to 52°C /Relative humidity (20%
SEN: L
GAS/RSET PEAK
ON/OFF
to 85% RH)
SENS MUTE
- Storage temperature: -20°C to 60°C
- Weight: 415 g
- Dimension: 201x86x38 mm
- Certification: SAE_J1627, SAE_J2791, SAE_J2913, EN14624, 2012 CE
Certification
+1 713 701 1986 https://aprvtiotech.com/
Notices
H CO 2 2 HC R1234YF
PEAK
WARM UP
SEN: L - Do not submerge the product in water or allow water to enter the
GAS/RSET PEAK
ON/OFF
SENS MUTE intake of the probe.
- Do not expose the product to temperatures exceeding 60°C.
- Do not leave the product in direct sunlight for long periods of time.
- Do not dismantle or attempt repairs of the product without authorisation.
- Detection: when a leak is detected, the
screen will show the intensity of the
- Do not change or replace the included lithium battery.
leak and audible tone will change to a
- Do not leave for more than 6 months without charging the battery to
siren sound.
prevent damage.
- Do not use on objects with a charge or appliances connected to a power
source.
- Ensure the filter is present and clean before performing a test.
GAS/RSET PEAK
- Ensure there is enough power before performing a test.
- Use only the supplied charging cable.
ON/OFF - Avoid the inhalation of refrigerant vapor. High concentrations are harmful
and may lead to coma or death.Technical Specifications
SENS MUTE https://aprvtiotech.com/ Video Instruction
