Summary of Contents for RENPHO YY-A01L
- Page 1 User Manual...
-
Page 2: Table Of Contents
CONTENTS 1. Introduction..................01 2. Contraindications................01 3. Important Safety Instructions............02 4. Normalized Symbols..............04 5. About the Product................06 6. Using the Product................08 7. Cleaning and Maintenance.............11 8. Troubleshooting Guide..............13 9. Warranty Policy................14 10. Customer Servlce................14... -
Page 3: Introduction
Non-compliance may cause injuries, death and/or severe property damage. Introduction RENPHO Leg Massager YY-A01L is intended for use in massaging your entire leg to alleviate minor muscle aches and/or pains from swelling and inflammation and to increase blood circulation. -
Page 4: Important Safety Instructions
Important Safety Instructions When using the device, basic precautions should always be followed, including the following: READ ALL INSTRUCTIONS CAREFULLY BEFORE USING. 1. This device can only be used by children aged from 8 years and above and persons with reduced physical, sensory or cognitive capabilities if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. - Page 5 - People suffering from a sensory impairment that reduces the feeling of pain (e.g. metabolic disorder) - People suffering from fever over 100.4℉ 2. DO NOT use spare parts that are not approved by RENPHO. 3. Non-professional repair personnel should not dismantle or replace the device without manufacturer's permission.
- Page 6 13. DO NOT use the device for more than 60 minutes at a time. Extensive use could lead to the device's excessive heating and shorter lifespan. 14. DO NOT operate under a blanket or pillow. Excessive heating can occur and cause fire, electric shock, or injury.
-
Page 7: Normalized Symbols
Normalized Symbols The signs below might be in the user manual, labeling or other components. SYMBOL DESCRIPTION SYMBOL DESCRIPTION Indicates a medical device that needs protection Direct current from light sources Indicates a medical device that can be broken or CLASS II equipment damaged if not handled carefully Indicates a medical device that needs to be... - Page 8 SYMBOL DESCRIPTION SYMBOL DESCRIPTION Manufacturer information: The Use by date manufacturer name and address Date of manufacture The device should be sent to the special agencies according to local regulations for separate collection after its useful life Serial number MR Unsafe To identify an item which poses unacceptable risks to the patient, medical staff or other persons with the MR environment.
-
Page 9: About The Product
About the Product 1. What’s in the box Zipper Controller Leg wrap Wall Charger Storage Bag Charging Cable 2. Product Overview LCD Display Buttons Battery Indicator Power Button Timer Indicator Intensity - / + Pressure Value Mode Button MODE Combine Mode Indicator MODE Section Mode Indicator Timer Button... - Page 10 3. Specifications Product Name: Air Compression Leg Massager Noise: ≤55dB Model: YY-A01L Application: Home, Hospital, Athlete training, and Clinics Input: 5V Inflation Time: 1-35s Battery: 7.2V/3200mAh/23.04Wh Duration of Inflation: 1-5s Power Supply: Rechargeable Li-ion battery Deflation Time: 1-5s Power Adapter: Input: 100-240V~, 50/60Hz, Output:...
-
Page 11: Using The Product
Using the Product 1. Before Use Charge the device Charging Port a. Please charge the device using the provided Type-C charging cable and DC 5V 2A charger when the battery indicator turns red. b. It takes about 2.5 hours to fully charge the device. When charging the battery, the battery indicator will flash and turn solid green once the charging is complete. - Page 12 2. Wear the Leg Wrap 2.1 Lay the leg wrap flat. ② ② ③ 2.2 Begin by unzipping the leg wrap. ⑤ ④ Insert your leg and re-zip to seal. ① The leg wrap is not size-adjustable ④ and may provide a loose fit which is normal.
- Page 13 3. Operation Instruction 1. Power Button: Press and hold to turn on the massager. It will activate Combine mode 1 with the lowest intensity level and 20-minute timer by default. To turn off the massager, simply press and hold the power button again. 2.
-
Page 14: Cleaning And Maintenance
3. Intensity +/- Button: Press to increase/decrease through 16 intensity levels (50mmHg to 200mmHg). 4. Timer Button: Press to toggle massage duration: 20mins, 30mins and 40mins Note: 1. The massager has a built-in auto-off timer. It will automatically turn off the massager when the time is up. -
Page 15: Troubleshooting Guide
C. Maintenance B. Cleaning 1. Do not attempt to disassemble or repair 1. Turn off the massager before cleaning. the massager. The massager does not 2. Do not machine wash. Do not immerse it in any contain user-serviceable parts. liquid to clean. Do not clean it with abrasive 2. -
Page 16: Warranty Policy
If you choose not to register your product, it will not diminish the product warranty. Customer Servlce Please feel free to contact us if you have any questions or concerns. RENPHO Customer Service Team guarantees a quick response and hassle-free solutions to any issue you may have within business hours. - Page 17 FCC Regulatory Compliance This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
- Page 18 (1)This device may not cause interference. (2)This device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment.
