Engineering Data
High Static Pressure Duct TVR Connect IDU
4TVA0018KF000AA
4TVA0024KF000AA
4TVA0027KF000AA
4TVA0030KF000AA
4TVA0038KF000AA
4TVA0043KF000AA
4TVA0048KF000AA
4TVA0055KF000AA
Commercial Air Conditioners
4TVA0068KF000AA
4TVA0076KF000AA
4TVA0085KF000AA
4TVA0095KF000AA
R410A/R32
4TVA0115KF000AA
4TVA0136KF000AA
4TVA0154KF000AA
4TVA0192KF000AA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4TVA0018KF000AA and is the answer not in the manual?

Questions and answers

Related Manuals for Trane 4TVA0018KF000AA

Summary of Contents for Trane 4TVA0018KF000AA

  • Page 1 R410A/R32 Commercial Air Conditioners Engineering Data High Static Pressure Duct TVR Connect IDU 4TVA0018KF000AA 4TVA0038KF000AA 4TVA0068KF000AA 4TVA0115KF000AA 4TVA0024KF000AA 4TVA0043KF000AA 4TVA0076KF000AA 4TVA0136KF000AA 4TVA0027KF000AA 4TVA0048KF000AA 4TVA0085KF000AA 4TVA0154KF000AA 4TVA0030KF000AA 4TVA0055KF000AA 4TVA0095KF000AA 4TVA0192KF000AA...
  • Page 2 TVR Connect Indoor Units High Static Pressure Duct 1 Specifications..................... 4 2 Dimensions ....................8 3 Unit Placement ..................8 4 Piping Diagrams ..................13 5 Wiring Diagrams ..................14 6 Capacity Tables ..................17 7 Electrical Characteristics ................19 8 Sound Levels ....................

  • Page 3: Specifications

    TVR Connect Indoor Units 1 Specifications 4TVA0018KF000AA / 4TVA0024KF000AA / 4TVA0027KF000AA/ 4TVA0030KF000AA Table 1.1: 4TVA0018(0024,00027,0030)KF000AA specifications Model name 4TVA0018KF000AA 4TVA0024KF000AA 4TVA0027KF000AA 4TVA0030KF000AA Power s upply 1-pha se, 220-240V, 50/60Hz Ca pa city 19.1 24.2 27.3 30.7 Cool i ng kBut/h Input 10.0...
  • Page 4 TVR Connect Indoor Units 4TVA0038KF000AA / 4TVA0043KF000AA/ 4TVA0048KF000AA / 4TVA0055KF000AA Table 1.2: 4TVA0038(0043,0048,0055) KF000AA specifications Model name 4TVA0038KF000AA 4TVA0043KF000AA 4TVA0048KF000AA 4TVA0055KF000AA Power s upply 1-pha se, 220-240V, 50/60Hz 11.2 12.5 14.0 16.0 Ca pa city 38.2 42.7 47.8 54.6 Cool i ng kBut/h Input 12.5...
  • Page 5 TVR Connect Indoor Units 4TVA0068KF000AA / 4TVA0076KF000AA / 4TVA0085KF000AA/ 4TVA0095KF000AA Table 1.3: 4TVA0068(0076,0085,0095) KF000AA specifications Model name 4TVA0068KF000AA 4TVA0076KF000AA 4TVA0085KF000AA 4TVA0095KF000AA Power s upply 1-pha se, 220-240V, 50/60Hz 20.0 22.4 25.2 28.0 Ca pa city 68.3 76.5 86.0 95.6 Cool i ng kBut/h Input 22.5...
  • Page 6 TVR Connect Indoor Units 4TVA0115KF000AA / 4TVA0136KF000AA/ 4TVA0154KF000AA / 4TVA0192KF000AA Table 1.4: 4TVA0115(0136,0154,0192)KF000AA specifications Model name 4TVA0115KF000AA 4TVA0136KF000AA 4TVA0154KF000AA 4TVA0192KF000AA Power s upply 1-pha se, 220-240V, 50/60Hz 33.5 40.0 45.0 56.0 Ca pa city 114.3 136.5 153.6 191.1 Cool i ng kBut/h 1850 1850...

  • Page 7: Unit Dimensions

    TVR Connect Indoor Units 2 Dimensions 2.1 Unit Dimensions 4TVA0018KF000AA / 4TVA0024KF000AA / 4TVA0027KF000AA/ 4TVA0030KF000AA 4TVA0038KF000AA / 4TVA0043KF000AA/ 4TVA0048KF000AA / 4TVA0055KF000AA Figure 2.1: 4TVA0018(0024,0027,0030,0038,0043,0048,0055)KF000AA dimensions (unit: mm) 4-Φ5 I (liquid side) H (gas side) External Φ23 (inner External thread of...
  • Page 8 TVR Connect Indoor Units 4TVA0068KF000AA / 4TVA0076KF000AA / 4TVA0085KF000AA/ 4TVA0095KF000AA/ 4TVA0115KF000AA Figure 2.2: 4TVA0068(0076,0085,0095,0115)KF000AA dimensions (unit: mm) Capacity (kW) 20.0≤kW≤22.4 5/8-18 UNF 22.4＜kW≤33.5 3/4-16 UNF...
  • Page 9 TVR Connect Indoor Units 4TVA0136KF000AA / 4TVA0154KF000AA / 4TVA0192KF000AA Figure 2.3: 4TVA0136(0154,0192)KF000AA dimensions (unit: mm) Capacity (kW) 33.5＜kW≤40.0 3/4-16 UNF 40.0＜kW≤56.0 7/8-14 UNF...

  • Page 10: Unit Placement

     Short-circuit ventilation (where outlet air returns quickly to a unit’s air inlet) will not occur. 3.2 Space Requirements 4TVA0018KF000AA / 4TVA0024KF000AA / 4TVA0027KF000AA/ 4TVA0030KF000AA 4TVA0038KF000AA / 4TVA0043KF000AA/ 4TVA0048KF000AA / 4TVA0055KF000AA Figure 3.1: High Static Pressure Duct space requirements (unit: mm)
  • Page 11 TVR Connect Indoor Units 4TVA0068KF000AA / 4TVA0076KF000AA / 4TVA0085KF000AA/ 4TVA0095KF000AA 4TVA0115KF000AA / 4TVA0136KF000AA/ 4TVA0154KF000AA / 4TVA0192KF000AA Figure 3.1: High Static Pressure Duct space requirements (unit: mm) Bottom view (Unit: mm) Wall ≥500mm Maintenance space Access hole Electric control assembly ≥600mm Maintenance space Side view Air outlet...

  • Page 12: Piping Diagrams

    TVR Connect Indoor Units 4 Piping Diagrams Figure 4.1: Piping diagram Gas side Liquid side Heat exchanger Legend Inlet Air Temp. Sensor Liquid Pipe Temp. Sensor Middle Pipe Temp. Sensor Gas Pipe Temp. Sensor Electronic expansion valve Fan motor...

  • Page 13: Wiring Diagrams

    TVR Connect Indoor Units 5 Wiring Diagrams 4TVA0018KF000AA / 4TVA0024KF000AA / 4TVA0027KF000AA/ 4TVA0030KF000AA 4TVA0038KF000AA / 4TVA0043KF000AA / 4TVA0048KF000AA / 4TVA0055KF000AA Figure 5.1: 4TVA0018(0024,0027,0030,0038,0043,0048,0055) KF000AA Duct wiring diagram...
  • Page 14 TVR Connect Indoor Units 4TVA0068KF000AA / 4TVA0076KF000AA / 4TVA0085KF000AA/ 4TVA0095KF000AA 4TVA0115KF000AA / 4TVA0136KF000AA/ 4TVA0154KF000AA / 4TVA0192KF000AA Figure 5.2: 4TVA0068(0076,0085,0095,0115,0136,0154,0192) KF000AA Duct wiring diagram...
  • Page 15 TVR Connect Indoor Units Legend Code Name Code Name XS XP connectors Inl et Air Temp. Sensor Stea m pipe temperature sensor* Ga s Pi pe Temp. Sensor CS-SW Wa ter level s witch Fres h air inlet temperature sensor* El ectronic expansion va lve ALARM Al a rm output...

  • Page 16: Cooling Capacity Table

    6 Capacity Tables 6.1 Cooling Capacity Table Table 6.1: High Static Pressure Duct cooling capacity Indoor air temperature (°C WB/DB) 14/20 16/23 18/26 19/27 20/28 22/30 24/32 Model 4TVA0018KF000AA 4TVA0024KF000AA 4TVA0027KF000AA 4TVA0030KF000AA 4TVA0038KF000AA 10.6 11.1 11.2 11.3 11.6 11.9 4TVA0043KF000AA 11.0...

  • Page 17: Heating Capacity Table

    TVR Connect Indoor Units 6.2 Heating Capacity Table Table 7.2: High Static Pressure Duct heating capacity Indoor air temperature (°C DB) Model 4TVA0018KF000AA 4TVA0024KF000AA 4TVA0027KF000AA 4TVA0030KF000AA 10.6 10.5 10.0 4TVA0038KF000AA 13.3 13.1 12.5 12.1 11.8 10.9 4TVA0043KF000AA 14.8 14.7 14.0 13.6...

  • Page 18: Electrical Characteristics

    TVR Connect Indoor Units 7 Electrical Characteristics Table 8.1: High Static Pressure Duct electrical characteristics Power supply Indoor fan motors Model Volts Power input Min. volts Max. volts 4TVA0018KF000AA 50/60 220-240 2.33 1.86 4TVA0024KF000AA 50/60 220-240 2.33 1.86 4TVA0027KF000AA 50/60 220-240 2.33...

  • Page 19: Sound Levels

    TVR Connect Indoor Units 8 Sound Levels 8.1 Overall Figure 8.1: High Static Pressure Duct sound pressure level Table 8.1: High Static Pressure Duct sound pressure levels measurement Sound pressure levels dB(A) Model name 4TVA0018KF000AA 4TVA0024KF000AA 4TVA0027KF000AA 4TVA0030KF000AA 4TVA0038KF000AA 4TVA0043KF000AA 4TVA0048KF000AA 4TVA0055KF000AA...
  • Page 20 TVR Connect Indoor Units Figure 8.4: 4TVA0038KF000AA octave band levels Figure 8.5: 4TVA0043KF000AA octave band levels NR-70 NR-70 NR-60 NR-60 NR-50 NR-50 NR-40 NR-40 NR-30 NR-30 NR-20 NR-20 NR-10 NR-10 NR-0 NR-0 31.5 125 250 500 1000 2000 4000 8000 31.5 125 250 500 1000 2000 4000 8000 Octave band center frequency (Hz)
  • Page 21 TVR Connect Indoor Units Figure 8.10: 4TVA0085KF000AA octave band levels Figure 8.11: 4TVA0095KF000AA octave band levels NR-70 NR-70 NR-60 NR-60 NR-50 NR-50 NR-40 NR-40 NR-30 NR-30 NR-20 NR-20 NR-10 NR-10 NR-0 NR-0 31.5 63 125 250 500 1000 2000 4000 8000 31.5 63 125 250 500 1000 2000 4000 8000 Octave band center frequency (Hz)

  • Page 22: Fan Performance

    TVR Connect Indoor Units 9 Fan Performance 9.1 How to switch between Constant Airflow mode and Constant Speed mode ①In the main interface, press " " +" " for 3 seconds at the same time, and the main interface will display "CC". Press the "▲" and "▼" to select the indoor unit ("n00-n63"...
  • Page 23 TVR Connect Indoor Units Figure 9.3: 4TVA0038KF000AA Figure 9.4: 4TVA0043KF000AA Figure 9.5: 4TVA0048KF000AA Figure 9.6: 4TVA0055KF000AA Figure 9.7: 4TVA0068KF000AA Figure 9.8: 4TVA0076KF000AA...
  • Page 24 TVR Connect Indoor Units Figure 9.9: 4TVA0085KF000AA Figure 9.10: 4TVA0095KF000AA Figure 9.11: 4TVA0115KF000AA Figure 9.12: 4TVA0136KF000AA Figure 9.13: 4TVA0154KF000AA Figure 9.14: 4TVA0192KF000AA...
  • Page 25 TVR Connect Indoor Units 9.2.2 How to Read the Diagram (Constant Airflow mode) The vertical axis is the External Static Pressure (Pa) while the horizontal axis represents the Air Flow (m /h). The characteristic curve for the “H”, “M”, “L”,”SL” and “SSL” fan speed control. “SSH”,“SH”, For 4TVA0048KF000AA, in “H”...
  • Page 26 TVR Connect Indoor Units 9.3.2 Fan performance diagram Figure 9.15: 4TVA0018(0024,0027)KF000AA Figure 9.16: 4TVA0030KF000AA Figure 9.17: 4TVA0038KF000AA Figure 9.18: 4TVA0043KF000AA Figure 9.19: 4TVA0048KF000AA Figure 9.20: 4TVA0055KF000AA Figure 9.21: 4TVA0068KF000AA Figure 9.22: 4TVA0076KF000AA...
  • Page 27 TVR Connect Indoor Units Figure 9.23: 4TVA0085KF000AA Figure 9.24: 4TVA0095KF000AA Figure 9.25: 4TVA0115KF000AA Figure 9.26: 4TVA0136KF000AA Figure 9.27: 4TVA0154KF000AA Figure 9.28: 4TVA0192KF000AA 9.3.3 How to Read the Diagram (Constant Speed mode) The vertical axis is the External Static Pressure (Pa) while the horizontal axis represents the Air Flow (m /h).
  • Page 29 T-V8T1H Ver. 2023-6...
