Trane XR 13 Product Data
Split system cooling
Hide thumbs
Also See for XR 13:
- Installer's manual (24 pages) ,
- Application manual (20 pages) ,
- Installation manual (8 pages)
Subscribe to Our Youtube Channel
Related Manuals for Trane XR 13
Summary of Contents for Trane XR 13
- Page 1 Split System Cooling Product Data XR 13 4TTR3018-060 1½ – 5 Tons PUB. NO. 22-1790-08...
-
Page 2: Features And Benefits
• Glossy corrosion resistant finish • Low ambient cooling to 0°F with BAYLOAM103 • Internal high/low pressure and temperature protection • 018, 024, 030 and 060 ship with start kit • Extended warranties available • Liquid line filter-drier © 2010 Trane 22-1790-08... -
Page 3: Table Of Contents
Contents Features and Benefits General Data Product Specifications A-weighted Sound Power Level [dB(A)] Accessory Description and Usage ARI Standard Capacity Rating Conditions Model Nomenclature Electrical Data Dimensions Mechanical Specification Options 22-1790-08... -
Page 4: General Data
General Data Product Specifications Model No. 1 4TTR3018A1 4TTR3024A1 4TTR3030A1 4TTR3036B1 Electrical Data V/Ph/Hz 2 200/230/1/60 200/230/1/60 200/230/1/60 208/230/1/60 Min Cir Ampacity Max Fuse Size (Amps) ® ® ® ® Compressor CLIMATUFF CLIMATUFF CLIMATUFF CLIMATUFF RL Amps - LR Amps 6.4 - 38.6 8.8 - 57.8 11.1 - 63... -
Page 5: Accessory Description And Usage
General Data Product Specifications Model No. 1 4TTR3042A1 4TTR3048A1 4TTR3060B1 Electrical Data V/Ph/Hz 2 208/230/1/60 208/230/1/60 208/230/1/60 Min Cir Ampacity Max Fuse Size (Amps) ® ® ® Compressor CLIMATUFF - SCROLL CLIMATUFF - SCROLL CLIMATUFF - SCROLL RL Amps - LR Amps 18.6 - 105 20.5 - 109 27.6 - 135... - Page 6 Furnace Configuration 2 = R-22 TU = Upflow / Horizontal TD = Downflow / Horizontal 4 = R-410A Type TRANE D = 80% Premium Product Type X = 90% Premium W = Split Heat Pump Number of Heating Stages T = Split Cooling...
-
Page 7: Electrical Data
Electrical Data SCHEMATIC DIAGRAMS (SEE LEGEND) 4TTR3018,024,030A1, 036B1 4TTR3042A1 22-1790-08... - Page 8 Electrical Data SCHEMATIC DIAGRAMS (SEE LEGEND) 4TTR3048A1 4TTR3060B1 PRINTED FROM D155205P01 REV00 22-1790-08...
- Page 9 Electrical Data SCHEMATIC DIAGRAMS LEGEND SYMBOLS 22-1790-08...
-
Page 10: Dimensions
Dimensions 4TTR3 OUTLINE DRAWING NOTE: ALL DIMENSIONS ARE IN MM (INCHES) MODELS BASE FIG. 4TTR3018A 832 (32-3/4) 829 (32-5/8) 756 (29-3/4) 143 (5-5/8) 92 (3-5/8) 210 (8-1/4) 79 (3-1/8) 508 (20) 4TTR3024A 832 (32-3/4) 829 (32-5/8) 756 (29-3/4) 143 (5-5/8) 92 (3-5/8) 210 (8-1/4) 79 (3-1/8) -
Page 11: Mechanical Specification Options
Mechanical Specification Options General Condenser Coil The 4TTR3 shall be fully charged from The Spine Fin™ coil shall be continu- the factory for matched indoor section ously wrapped, corrosion resistant all and up to 15 feet of piping. This unit must aluminum with minimum brazed joints. - Page 12 SS-PRC007-EN 07/10 File Number — Supersedes SS-PRC007-EN 2/02 Stocking Location PI Louisville & Webb/Mason Houston Trane www.trane.com Trane has a policy of continuous product and product data improvement and it reserves the right to change design and specifications without notice.
