SMC Networks 6608M INT - FICHE TECHNIQUE Features And Benefits page 2

TigerSwitch 100M
8 Port Modular Fast Ethernet Switch
10BASE-TX, FX Ports
Features and Benefits
TigerSwitch 100M Base Unit
Forwarding Mode
Adaptive cut-through (includes cut-through, fragment-free and
store-and-forward)
MAC Address Table
4,096 entries
Latency
<20 µsec
VLAN Support
Port-based grouping, up to 8 groups with port overlapping
Network Bridging Functions
Filtering
Forwarding
Learning
Blocking (with Spanning Tree Algorithm enabled)
Filtering/Forwarding/Learning Rates
Full line rate
Memory Buffer
256 K per port
In-Band Management
Telnet or SNMP
Out-of-Band Management
RS-232 Console port
Software Loading
TFTP in-band
BOOTP/TFTP for IP address assignment
Size
17.25 in. W x 13.75 in. D x 1.75 in. H (43.8 cm x 34.9 cm x
4.4 cm)
Weight (without modules)
7.8 lbs. (3.5 kg)
Temperature
Operating 32° to 104°F (0° to 40°C)
Humidity
10% to 90% (non-condensing)
Button
Configure
Power Supply
Universal ACinput
100 to 240 VAC, 50 to 60 Hz
Power Consumption
80 watts max. @ 100-240 VAC
Product Order No.
TigerSwitch 100M* SMC6608M
Fast Ethernet Modules SMC6600T
SMC6600F
SMC6600FSCT
SMC6600FSTT
Accessory SMCRPUX5
*Switch is also available in an International (INT) version.
SMC is a registered trademark; and EliteFax, TigerStack and TigerSwitch are trademarks of SMC Networks, Inc. Other product and company names are trademarks or registered
trademarks of their respective holders. © Copyright 1999 SMC Networks, Inc.
Standards
ANSI/IEEE 802.3u Fast Ethernet
ANSI/IEEE 802.3 Ethernet
ISO/IEC 8802-3 Ethernet
ANSI/IEEE 802.1d Spanning Tree
RFC 950 BOOTP
EMC/Safety Compliances
CE marking
UL 1950
EN60950 (TÜV/GS)
CSA 22.2 No. 950
FCC Class A
Industry Canada Class A
EN55022 (CISPR 22) Class A
VCCI Class A
AS/NZS 3548 (1995) - Class A
IEC 1000-4-2/3/4/6
Warranty
Three years
Fast Ethernet Modules
SMC6600T
Ports 1-3: Twisted-pair, RJ-45, fixed crossover
Port 4: Twisted-pair, RJ-45, switch-selectable crossover
SMC6600F
Ports 1-4: Fiber, SC connector
SMC6600FSCT
Ports 1-2: Fiber, SC connector
Port 3: Twisted-pair, RJ-45, fixed crossover
Port 4: Twisted-pair, RJ-45, switch-selectable crossover
SMC6600FSTT
Ports 1-2: Fiber, ST connector
Port 3: Twisted-pair, RJ-45, fixed crossover
Port 4: Twisted-pair, RJ-45, switch-selectable crossover
Network Interface
100BASE-TX
RJ-45 (UTP cable; EIA/TIACategory 5)
10BASE-T
RJ-45 (UTP cable; EIA/TIA Categories 3, 4, 5)
100BASE-FX
SC or ST connector (multimode fiber cable;
50/125, 62.5/125 µ core)
Description
Modular Fast Ethernet switch - base unit
4 100BASE-TX ports
4 100BASE-FX ports with SC connectors
2 100BASE-FX ports with SC connectors and 2 100BASE-TX ports
2 100BASE-FX ports with ST connectors and 2 100BASE-TX ports
Redundant Power Unit with cables
