opticlimate.com
WATER COOLER
OPTIMAL CLIMATE CONTROL
INSTALLATION MANUAL
INSTALLATION
PLEASE READ THE FOLLOWING INFORMATION CAREFULLY BEFORE USING THE UNIT:
High Temperature Safeguard on page 7
& USER GUIDE
Delete alarm history on page 12
Dehumidify without cooling pro4 on page 12
Engineered & Designed in Holland
THE FUTURE OF COOLING
JUST GOT COOLER.
www.opticlimate.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for OPTICLIMATE Compact Ultra light V 3500pro3
Summary of Contents for OPTICLIMATE Compact Ultra light V 3500pro3
- Page 1 WATER COOLER OPTIMAL CLIMATE CONTROL INSTALLATION MANUAL INSTALLATION PLEASE READ THE FOLLOWING INFORMATION CAREFULLY BEFORE USING THE UNIT: High Temperature Safeguard on page 7 & USER GUIDE Delete alarm history on page 12 Dehumidify without cooling pro4 on page 12 Engineered &...
- Page 2 The circulator pump must supply a pre defi ned fl ow at a given pressure. The fl ow is determined by the energy that must be circulated (KW) and the pressure depends on the pressure-drop of the complete system (Opticlimate(s) + piping + water-cooler) We always calculate the correct pump for your setup.
- Page 3 A maxi-controller evo in combination with a fan-pump controller (Smart Box) is used to control pump on/off and fanspeed. The controller recieves 2 signals from 2 sensors: temperature sensor to determen water temperature in the system and a current transformer to determen or the compressor inside the opticlimate is on or off. © The Climate Factory www.theclimatefactory.com...
- Page 4 The design T of the the system is 5K. This means that the temperature difference between the water-inlet and outlet of the Opticlimate must be maintained at 5K. To deter-men this value press the S-key short on the remote of the Opticlimate.
- Page 5 THE CLIMATE FACTORY/MANUALS/WATER COOLER THE CLIMATE FACTORY/MANUALS/WATER COOLER INSTALLATION INSTALLATION Example: Balancing with manual or auto by-pass A 15000pro3 high capacity (HC) on 1 x 17KW and a total pipe length of 100mtr x 32mm = 8.6 ltr + 1 1ltr + Adding glycol to the system (100x 0.6ltr=60ltr) = 79.6ltr total volume.
- Page 6 THE CLIMATE FACTORY/MANUALS/WATER COOLER INSTALLATION INSTALLATION DESIGN SHEET Number of Opticlimates on one water cooler_______________________________________ Opticlimate model (s)___________________________________________________pro3/pro4 Distance between Opticlimates and water cooler_________________________________mtr Heat load Opticlimates (KW)_________________________________________________KW Max. outside temperature ____________________________________________________°C Min. outside temperature ____________________________________________________°C Sketch of the situation ©...
-
Page 7: Water Cooler
WATER COOLER OPTIMAL CLIMATE CONTROL INSTALLATION MANUAL ® Opticlimate is a registered trademark of airSupplies INSTALLATION & USER GUIDE Engineered & Designed in Holland Manual version 01 13 2023 THE FUTURE OF COOLING JUST GOT COOLER. www.opticlimate.com...
