EN User Manual | Washing Machine
LR6F60489

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LR6F60489 and is the answer not in the manual?

Questions and answers

Related Manuals for AEG LR6F60489

Summary of Contents for AEG LR6F60489

  • Page 1 EN User Manual | Washing Machine LR6F60489...

  • Page 2: Table Of Contents

    FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.

  • Page 3: Safety Information

    SAFETY INFORMATION Before beginning the installation and use of this appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.

  • Page 4: General Safety

    • If a tumble dryer is stacked on the top of the washing machine, make sure to use the correct stacking kit approved by AEG (see more details in chapter "Accessories - Stacking kit"). ENGLISH...

  • Page 5: Safety Instructions

    2. SAFETY INSTRUCTIONS 2.1 Installation • WARNING: This appliance is designed to be installed / connected to a grounding connection in the building. • Always use a correctly installed The installation must comply with shockproof socket. relevant national regulations. • Make sure that the parameters on the rating plate are compatible with the •...

  • Page 6: Product Description

    • Make sure that there is access to the tap elements, including heat pumps, piping after the installation. and related equipment including hoses, valves, filters and aquastops, printed 2.4 Use circuit boards, electronic displays, pressure switches, thermostats and sensors, software and firmware including WARNING! reset software, door, door hinge and Risk of injury, electric shock, fire, burns...

  • Page 7: Appliance Overview

    3.2 Appliance overview 11 12 Worktop Drain hose Detergent dispenser Inlet hose connection Control panel Mains cable Door handle Transit bolts Rating plate Hose support Drain pump filter Feet for levelling the appliance The rating plate reports the model name (A), product number (B), electrical ratings (C) and serial number (D).

  • Page 8: Installation

    Water supply pressure Minimum 0.5 bar (0.05 MPa) Maximum 10 bar (1.0 MPa) Cold water Water supply Maximum Load Cotton 8 kg Spin Speed Maximum spin speed 1351 rpm Connect the water inlet hose to a water tap with a 3/4'' thread. 5.

  • Page 9: Positioning And Levelling

    We recommend that you keep the A correct adjustment of the appliance packaging and the transit bolts for any level prevents the vibration, noise and transport of the appliance. the movement of the appliance when in operation. 5. Put the plastic caps, that you find in the user manual bag, in the holes.

  • Page 10: Water-Stop Device

    5.4 Water-stop device 2. Connect the water inlet hose to the back of the appliance. The inlet hose has a water stop device. This 3. Position it toward left or right depending device prevents water leaks in the hose on the position of the water tap. because of its natural ageing.
  • Page 11 5. Without the plastic hose guide, to a sink spigot - Put the drain hose in the spigot and tighten it with a clamp. Refer to the illustration. Make sure that the drain hose end is not immersed in the water. There may be a return of dirty water into the appliance.

  • Page 12: Accessories

    Read carefully the instructions supplied with the accessory. Only appropriate accessories approved by AEG ensure the safety standards of the appliance. If unapproved parts are used, any claims will be invalidated. 6.2 Fixing plate kit If you install the appliance on a plinth that is not an accessory supplied by AEG, secure the appliance in the fixing plates.

  • Page 13: Control Panel

    7. CONTROL PANEL 7.1 Control panel description 11 10 Programme dial Flecken/Vorwäsche skipping touch button Display Leichtbügeln touch button Zeit Sparen touch button Extra Spülen touch button Zeitvorwahl touch button Schleudern reduction touch button Option skipping touch button • Nur Spülen option Temperatur touch button •...

  • Page 14: Dial And Buttons

    Washing phase indicator. It flashes during prewash and wash phase. Rinsing phase indicator. It flashes during rinse phase. Spinning and draining phase indicator. It flashes during spin and drain phase. The digital indicator can show: • Programme duration (e. g. •...
  • Page 15 8.2 Introduction The appliance empties the water out automatically after 18 hours The options/functions are not selectable approximately. with all washing programmes. Check the • Activate the Extra Silent option. compatibility between options/functions The intermediate and the final spinning and washing programmes in the phases are suppressed and the "Programme Chart".
  • Page 16 This option is recommended for heavily The related indicator comes on. soiled laundry, especially if containing 8.8 Leichtbügeln sand, dust , mud and other solid particles. The appliance carefully washes and spins the laundry to prevent the creases. The options can increase the programme The appliance decreases the spin speed, duration.

  • Page 17: Programmes

    9. PROGRAMMES 9.1 Programme Chart Washing programmes Programme Programme description Washing programmes Eco 40-60 Low energy cycle for cottons. Decreases temperature and extends time to reach good washing results. White and coloured cotton fabrics. Ideal for normal and heavy soil. Baumwolle Synthetic items or mixed fabric items.
  • Page 18 Programme Programme description White cotton items. This high-performance wash programme combined with Hygiene steam vapour, removes more than 99,99% of bacteria and viruses keeping the temperature above 60°C throughout the washing phase; with an additional action on the fibers thanks to a vapour phase, an enhanced rinsing phase ensures a proper removal of detergent and micro-organism residues.

  • Page 19: Programme Options Compatibility

    Programme Default tempera‐ Reference spin speed Maximum load ture Spin speed range Temperature range 1400 rpm 60 °C 8 kg Hygiene 1400 rpm - 400 rpm According to Commission Regulation EU 2019/2023, this programme at 40 °C is able to clean normally soiled cotton laundry declared to be washable at 40 °C or 60 °C, together in the same cycle.
  • Page 20 Options ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ Zeitvorwahl This option is not available with temperature lower than 40 °C. If you set the shortest duration, we recommend that you decrease the load size. It is possible to fully load the appliance, however the washing results can be less satisfactory.

  • Page 21: Settings

    9.2 Woolmark Wool Care - Blue The wool wash cycle of this machine has been approved by The Woolmark Company for the washing of wool gar‐ ments labelled as «hand wash» provided that the prod‐ ucts are washed according to the instructions on the gar‐ ment label and those issued by the manufacturer of this washing machine.

  • Page 22: Before First Use

    3. Press and hold the Flecken/Vorwäsche and Leichtbügeln buttons for some seconds (within 10 seconds after the If the procedure does not work (due to switching on. After these 10 seconds, the timeout, wrong programme dial position key combination activates and or wrong keys combination), switch the deactivates the acoustic signals).

  • Page 23: Filling The Detergent And Additives

    12.3 Filling the detergent and additives 2. Press the lever down to remove the dispenser. 3. To use powder detergent, turn the flap Compartment for prewash phase, soak programme or stain remover. Compartment for washing phase. Compartment for liquid additives (fabric conditioner, starch).

  • Page 24: Setting A Programme

    The ProSense estimation starts at the end of the countdown. Cancelling the delay start after the countdown has started To cancel the delay start: 1. Touch the Start/Pause button to pause the appliance. The related indicator flashes. 2. Touch the Zeitvorwahl button repeatedly Make sure that the flap does not cause a until the display shows blockage when you close the drawer.

  • Page 25: Programme Phase Indicators

    12.9 Programme phase indicators the indicator flashes, the ProSense System starts the laundry load detection: When the programme starts the indicator of the running phase flashes and the other 1. The appliance detects the load in the first phase indicators are steady on. 30 seconds, the indicator flashes.

  • Page 26: Opening The Door - Adding Garments

    12.12 Opening the door - Adding After five minutes from the end of the garments programme, the energy saving function automatically deactivates the appliance. While a programme or the delay start operates, the appliance door is locked. When you activate the appliance again, the display show the end of the last selected programme.

  • Page 27: Stand-By Option

    • After 5 minutes from the end of the washing programme Press the Ein/Aus button to activate the In any case, the appliance empties the appliance again. water out automatically after The display shows the end of the last set approximately 18 hours.

  • Page 28: Stubborn Stains

    13.2 Stubborn stains • the wash load to turn grey, • greasy clothes, For some stains, water and detergent is not • mould in the appliance. sufficient. Excessive detergent may cause: We recommend that you pre-treat these • sudsing, stains before you put the items in the •...

  • Page 29: Care And Cleaning

    14. CARE AND CLEANING 14.3 External cleaning WARNING! Clean the appliance with mild soap and warm Refer to Safety chapters. water only. Fully dry all the surfaces. Do not use a scouring pads or any scratching 14.1 Periodic cleaning schedule material.

  • Page 30: Cleaning The Detergent Dispenser

    14.6 Door seal This appliance is designed with a self Occasionally, at the end of a cycle the cleaning draining system, allowing light fluff display may show the icon : this is a fibers that fall off the clothes to be drained out recommendation to perform the “drum with the water.

  • Page 31: Cleaning The Drain Pump

    the recess. Use a small brush to clean WARNING! the recess. • Do not remove the filter while the appliance operates. • Do not clean the pump if the water in the appliance is hot. Wait until the water cools down Proceed as follows to clean the pump: 1.

  • Page 32: Cleaning The Inlet Hose And The Valve Filter

    180˚ 5. When the bowl is full of water, turn the 11. Put the filter back into the special guides filter back and empty the container. by turning it clockwise. Make sure that 6. Repeat the steps 4 and 5 until the water you tighten the filter correctly to prevent stops to flow out.

  • Page 33: Emergency Drain

    45° 20° 2. Remove the inlet hose from the appliance 14.11 Emergency drain by loosening the ring nut. If the appliance cannot drain the water, carry out the same procedure, described in 'Cleaning the drain pump' paragraph. If necessary, clean the pump. 14.12 Frost precautions If the appliance is installed in an area where the temperature can reach the values around...
  • Page 34 15.1 Alarm Codes and Possible failures The appliance does not start or it stops during operation. First try to find a solution to the problem (refer to the tables). WARNING! Deactivate the appliance before carrying out any check. With some problems, the display shows an alarm code and the Start/ Pause button may flash continuously: Problem Possible solution...
  • Page 35 Problem Possible solution • Make sure that the mains plug is connected to the mains socket. • Make sure that the appliance door is closed. • Make sure that there is no damaged fuse in the fuse box. The programme does not •...

  • Page 36: Consumption Values

    After the check, activate the appliance. The programme continues from the point of interruption. If the problem occurs again, contact the Authorised Service Centre. The necessary data for the service centre are on the rating plate. 16. CONSUMPTION VALUES 16.1 Introduction See the web link www.theenergylabel.eu for detailed information about Energy Label.
  • Page 37 16.3 According to Commission Regulation Eu 2019/2023 Eco 40-60 pro‐ rpm 1) Litres hh:mm °C gramme Full load 0.790 52.0 3:25 53.00 39.0 1351 Half load 0.420 42.0 2:40 53.00 30.0 1351 Quarter load 0.165 33.0 2:35 54.00 22.0 1351 Maximum spin speed.

  • Page 38: Quick Guide

    17. QUICK GUIDE 17.1 Daily use Connect the mains plug to the mains socket. 2. Set the desired options by means of the corresponding touch buttons. To start the Open the water tap. programme, touch the Start/Pause Load the laundry. button.

  • Page 39: Environmental Concerns

    Pro‐ Load Product description grammes Baumwolle 8 kg White cotton and coloured cotton. Pflegeleicht 3 kg Synthetic items or mixed fabric items. Feinwäsche 2 kg Delicate fabrics such as acrylics, viscose, polyester items. 1,5 kg Machine washable wool, hand washable wool and delicates. Wolle 20 Min.
  • Page 40 135970410-A-072023...
