Summary of Contents for Sencor SDB 524T
- Page 1 SDB 524T DVB-T2 SET-TOP BOX User Manual Uživatelská příručka Používateľská príručka Felhasználói kézikönyv Podręcznik użytkownika...
- Page 2 EN ................................3 CZ ................................28 SK ................................53 HU ................................78 PL ................................107 2 EN Copyright © 2024, Fast ČR, a. s. Revision 11/2024...
-
Page 3: Safety Information
Safety Information TO MINIMIZE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. NOTICE ELECTRIC SHOCK HAZARD – DO NOT OPEN CAUTION To minimize fire hazard or electric shock, do not remove the cover (or the rear panel) of the device. -
Page 4: Technical Data
This document is just an abridged version. The full version of this manual can be found at www.sencor.com. This document contains important information that will help you learn how to correctly use this set-top box and its accessories to your satisfaction. -
Page 5: Important Safety Measures
Important Safety Measures In the production of this set-top box, great attention was paid not only to meeting quality standards, but also to ensuring safety, which is a decisive factor in the design of each of our devices. But you must also do your part to ensure safety. This document contains important information that will teach you how to use this set-top box and its accessories properly so that you are satisfied. - Page 6 on the accessory itself and must not be modified so as to block the safety functions. This minimises the potential risk of electric shock or fire. In case of any doubt, contact a qualified service technician. Accessories – Do not place this set-top box on an unstable cart, stand, tripod, bracket or table.
- Page 7 A. If the power adapter or the connecting power cable is damaged. B. If liquid or foreign objects get into the set-top box. C. If the set-top box has been exposed to rain or water. D. If the image is not displayed correctly even though you follow the operating instructions.Only adjust the controls that are described in this manual.
- Page 8 • If you will not be using the remote control for a long period of time, remove the batteries to prevent potential damage caused by a subsequent battery leakage. • If the remote control is not working correctly or its operational range is reduced, change all batteries for new ones.
-
Page 9: Remote Control
Remote Control MEDIA (Media) (Open the Record menu) RED/GREEN/YELLOW/Blue button (For interactive functions / Nested menu function buttons) EPG (Electronic Programme Guide) (Open the Electronic Programme Guide menu) OK button (Confirm a menu selection) Cursor / CH+,- (Previous/Next Channel) / VOL+,- (Volume Up/Down) (Cursor: Navigation buttons to browse menu items) (CH+/-: Previous/Next channel) -
Page 10: Get Started
Programmable Button Learning Mode To enter the learning mode, press the “SET” button in the TV CONTROL area for 3 seconds (until the LED lights up intensely). Press the blue “POWER” button of the learning remote control (the LED will flash slowly). -
Page 11: System Connection
System Connection General Information There are many different types of TVs and other devices that can be connected to this STB. This guide lists the most common ways to connect your devices. Connecting a TV Antenna Scart cable RF cable Television HDMI cable Note: Please connect the HDMI cable to the receiver ONLY when turned off (red Standby... -
Page 12: Electronic Programme Guide (Epg)
Electronic Programme Guide (EPG) Press the “EPG” button to open the EPG (Electronic Programme Guide) menu. Press the cursor buttons to toggle between the channel list, the selected channel's event schedule. Press the “LEFT/RIGHT” button to switch between channel and programme windows. - Page 13 Main Menu The main menu is used to set reception parameters, set advanced functions and manage channels. Press the MENU button to enter the menu. Use the LEFT and RIGHT keys to navigate through its categories, press OK to enter a category. Within a category, use the UP and DOWN keys to move between items.If the item has values to set marked with arrows before and after the current value, to toggle these values use the LEFT and RIGHT arrows on the remote control.
-
Page 14: Channel Settings
Channel Settings Editing Channels This option allows you to manage channel lists. In the submenu, select a mode using the number buttons 1–5, and its marking will light up in blue. Pressing the number button again will exit the mode and the blue mode marking will turn grey again. Use the UP/DOWN buttons to navigate the list. -
Page 15: Volume Adjustment
5. Fav (Favourites) – after switching on the mode, select the channel to be added to one (or more) favourites list by pressing OK. When pressed, a list of favourite channel groups will appear (e.g. Movies, News, Sports, etc.). You can also indicate your inclusion in more than one group. -
Page 16: Picture Setting
Picture Setting Aspect ratio Set to Auto if you have a widescreen TV and it receives all commands from the HDMI interface. If not, set a suitable 16:9 image processing method Resolution Set the correct resolution according to your TV's characteristics. Proceed from lower values to the highest possible. -
Page 17: Automatic Search
Search Search Mode Choose between terrestrial DVB-T2 and cable DVB-C. All or Free – FTA only Select, if you want to tune all channels or only free, non-paid (FTA). Automatic Search Before starting, you will be asked to clear all previously tuned channels and automatically retune the entire band according to the parameters specified above. -
Page 18: Setting The Clock
Setting the Clock Region and Time Select the method of entering the time, either Manual, where you also select Region and Time Zone. Or select DVB, where the exact time will be loaded automatically from the broadcast (recommended). The automatic time depends on the accuracy of the broadcast and its operators. -
Page 19: Subtitle Language
Automatic On and Off You can leave full manual control by selecting Disabled or enable a function by entering a specific time. The function depends on the correct entry of the time and, if necessary, updating the time from the broadcast. Options OSD Language Select the receiver menu language from the available languages. - Page 20 Sound Memorisation Saves the soundtrack determination. It depends on the broadcast and identification of the soundtrack. Audio Description If an audio description (usually marked AD for a particular programme) is broadcast, it can be switched on by selecting ON. The ratio of the original sound to the audio description (AD Volume Offset) can then be adjusted.
-
Page 21: System Information
System Information Displays information about the receiver's hardware and software. Software Upgrade If you receive an approved software upgrade from the manufacturer, you can install it using this option. Select the type and location according to the instructions issued for this update and start the installation by selecting Start. -
Page 22: Pvr Settings
PVR Records If you have already recorded broadcasts to your USB drive, this option will display a list of them. Press OK to start playback of the selected recording. You can delete a particular recording with the RED button, or you can delete all with the BLUE button. Note: The record list can be accessed in normal operation by pressing the MEDIA button. -
Page 23: Timeshift Recording
ATTENTION! Formatting irreversibly deletes all the contents of the disk! Time Shift / Recording Time Shift The Time Shift function can be activated in broadcast monitoring mode by pressing the “PAUSE” button if this function is enabled in the MENU/USB/PVR settings. When the function is started, an information window is briefly displayed. -
Page 24: Multimedia Player
Multimedia Player Multimedia Player Main Menu Make sure that external data storage device is connected to the USB port. Press the "MENU" button to open the main menu. Press the “LEFT” or “RIGHT” button to highlight USB and press OK to select "”Multimedia”. - Page 25 Note: When you stop playing a file, e.g. a movie, and restart it, the player will offer you the option to resume where you left off. You can confirm this by pressing OK or cancel and play from the beginning. Audio: Useful features include Settings (the gear symbol), which will offer to set the repetition and the way text is displayed and coded if available.
- Page 26 FAST ČR, a.s. hereby declares that the radio device type SDB 524T conforms to the 2014/53/EU directive. For full version of the EU declaration of conformity, please refer to www.sencor.com website...
-
Page 27: Warranty Conditions
Manufacturer: FAST ČR, a.s., U Sanitasu 1621, Říčany 251 01, Czech Republic Visit www.sencor.com for detailed information about authorized service centers. The original version of the instructions is in the Czech language, other language versions are made by the appropriate translation. - Page 28 FAST ČR, a.s., U Sanitasu 1621, Říčany CZ-251 01...
