Summary of Contents for Sencor SDB 523T
- Page 1 SDB 523T User Manual SET TOP BOX Uživatelská příručka SET TOP BOX Používateľská príručka SET TOP BOX SET TOP BOX Felhasználói kézikönyv Podręcznik użytkownika SET TOP BOX...
-
Page 3: Table Of Contents
Table of Contents SAFETY INFORMATION ..............................2 IMPORTANT SAFETY PRECAUTIONS ............................3 Installation .......................................3 Use ........................................4 Repairs......................................4 Remote Control and Battery ...............................5 HOME ....................................6 Information About This STB ...............................6 Front panel ......................................6 Rear panel .......................................6 System wiring....................................8 GET STARTED ................................9 CONTROLS ................................... -
Page 4: Safety Information
Safety information TO MINIMIZE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. NOTICE RISK OF ELECTRIC SHOCK CURRENT - DO NOT OPEN NOTICE To minimize fire hazard or electric shock, do not remove the cover (or the rear panel) of the device. -
Page 5: Important Safety Precautions
IMPORTANT SAFETY PRECAUTIONS In the production of this set-top box, great attention was paid not only to meeting quality standards, but also to ensuring safety, which is a decisive factor in the design of each of our devices. But you must also do your part to ensure safety. This document contains important information that will teach you how to use this set-top box and its accessories properly so that you are satisfied. -
Page 6: Use
Accessories - Do not place this set-top box on an unstable cart, stand, tripod, bracket or table. The set-top box could fall to the ground and cause serious injury to children or adults, or seriously damage itself. Use this set-top box only with the cart, stand, bracket or table recommended by the manufacturer or sold with the set-top box. -
Page 7: Remote Control And Battery
E. If the set-top box has fallen to the ground or its cabinet has been damaged. F. If the set-top box shows an obvious change in behaviour - this clearly indicates the need for repair. 19. Replacement Parts - If replacement parts are required, ask the service technician to verify that the replacement parts used have the same safety characteristics as the original replacement parts. -
Page 8: Home
Home Information About This STB Front panel Power indicator Port USB Rear panel TV Scart for connection to a TV set Antenna HDMI output 6 EN Copyright © 2022, Fast CR, a. s. Revision 06/2022... - Page 9 Remote control RED/GREEN/YELLOW/Blue button (For interactive functions / Nested menu function buttons) TV/RADIO (TV/radio) (Switching between TV and radio modes) MEDIA (Media) (Open the Record menu) AUDIO (Sound) (Selecting the audio mode and audio track) EPG (Electronic Programme Guide) (Open the Electronic Programme Guide menu) OK button (Confirmation of selection in the offer)
-
Page 10: System Wiring
System wiring There are many different types of TVs and other devices that can be connected to this STB. This guide lists the most common ways to connect your devices. Connecting a TV HDMI TV Antenna RF cable Power Remark: Plug the HDMI cable ONLY into a receiver that is switched off (red Standby indicator is lit). 8 EN Copyright ©... -
Page 11: Get Started
Get Started The first time you use this STB, the "Installation Guide" menu will appear. Press the cursor buttons to set Language, Country and Save by pressing OK. On the next page, select TV System, Resolution and Aspect Mode. We recommend to keep the original or automatic values. -
Page 12: Controls
Controls Switching Channels There are three ways to select a channel - by scrolling through the channel list, selecting by number and selecting from the on-screen channel list. Scroll through the channel list: To move through the channel list, press the up or down arrow button on the remote control. -
Page 13: Settings
Settings Press the "MENU" button to open the main menu. Press the "LEFT" or "RIGHT" arrow to select a group. Press the "UP" or "DOWN" arrow to select the desired setting item and press the "OK" button to open the nested menu. Use the arrow keys and the OK button to move around. -
Page 14: Av Settings Group
AV Settings Group TV System - select according to the system supported by your TV PAL/NTSC/Auto. Consult its instruction manual. Resolution - select the appropriate resolution from 480i/60 to 1080p/50 depending on your TV. Proceed with discretion! A higher value than is supported by your TV set may lead to unwanted effects from a fluttering picture up to a black picture. -
Page 15: Timer Setting
USB Update - if the manufacturer releases a software update for the device in the future, it can be uploaded to the device here. Follow the instructions supplied with the new software and use only the software supplied by the instrument manufacturer. Any subsequent errors and problems are not covered by the manufacturer's warranty. -
Page 16: Timeshift
Record Manager: RED button - to open the rename window. The GREEN button allows you to lock the record. You will be asked to enter your password. OK button - starts the selected record. BLUE button - allows you to delete the record after confirmation. YELLOW button - allows you to delete all of the record, after confirmation. - Page 17 • The USB memory device must be plugged directly into the device. Do not use a USB extension cable to avoid data transmission failure and interference. • Before using a USB memory device, test its communication function with the device and its data reading and writing speed. •...
-
Page 18: Troubleshooting
Troubleshooting In some regions, the digital terrestrial signal may be weak. Therefore, we recommend using an antenna with a built-in amplifier to monitor channels with weak signals. The Problem Possible cause What to do Standby indicator is Disconnected power cable Check the mains cable not lit No signal detected Disconnected antenna... -
Page 19: Technical Data
Technical Data TUNER AND CHANNEL • RF INPUT CONNECTOR × 1 (IEC TYPE, IEC169-2, DRAWER TYPE) • FREQUENCY BAND: 174 MHz ~ 230 MHz (VHF) 470 MHz ~ 862 MHz (UHF) • SIGNAL LEVEL: -15 ~ -70 dBm DECODER • MPEG-2 MP@HL, AVC/H.264 HP @L4.1 •... - Page 20 INSTRUCTIONS AND INFORMATION ON THE DISPOSAL OF DISCARDED PACKAGING MATERIALS Take the packaging material to a collection yard for disposal. DISPOSAL OF DISCARDED ELECTRICAL AND ELECTRONIC EQUIPMENT This symbol on the product, accessory or packaging indicates that the product must not be treated as normal household waste. Please dispose of this product in a collection yard designated for the recycling of electrical and electronic equipment.
- Page 21 Cases when the claiming product cannot be indentified according to the presented documents (e.g. the serial number or the warranty seal has been damaged). Authorized service centers Visit www.sencor. for detailed information about authorized service centers. EN 19 Copyright © 2022, Fast CR, a. s.
