- Page 1 SDB 5006T User Manual SET TOP BOX Uživatelská příručka SET TOP BOX Používateľská príručka SET TOP BOX Felhasználói kézikönyv SET TOP BOX Podręcznik użytkownika SET TOP BOX...
-
Page 3: Table Of Contents
Information About This STB ......................9 Front panel ............................9 Rear panel ............................9 Learning remote control ........................11 Switch remote control mode (supports multiple Sencor set top boxes) ......11 Programmable button learning mode ..................11 SYSTEM CONNECTION ........................12 General information......................... 12 GET STARTED ............................13... - Page 4 Audio Description Setting ......................22 Other ..............................22 HDMI CEC ............................22 TOOLS ..............................23 Tools main menu ..........................23 Information ............................23 Factory Setting ..........................23 Software Upgrade ........................... 24 Remove USB device safely ......................24 MULTIMEDIA PLAYER .........................25 Multimedia player main menu ....................25 Media Playback ..........................25 DVR Settings ...........................28 TIME SHIFT / RECORDING ........................29...
-
Page 5: Safety Information
Safety Information TO MINIMIZE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. NOTICE RISK OF ELECTRIC SHOCK CURRENT - DO NOT OPEN CAUTION To minimize fire hazard or electric shock, do not remove the cover (or the rear panel) of the device. -
Page 6: Important Safety Measures
IMPORTANT SAFETY MEASURES In the production of this set-top box, great attention was paid not only to meeting quality standards, but also to ensuring safety, which is a decisive factor in the design of each of our devices. But you must also do your part to ensure safety. This document contains important information that will teach you how to use this set-top box and its accessories properly so that you are satisfied. -
Page 7: Use
Accessories - To avoid any danger, do not use accessories other than those recommended by the manufacturer of this set-top box. 10. Do not expose the unit to dripping or splashing water or place objects filled with liquid, such as vases, on the unit. Warning: Be safe when using electricity. -
Page 8: Repairs
Repairs 17. Repairs - Do not attempt to repair this set-top box yourself, as opening the cabinet or removing the covers could expose you to dangerous voltage or other hazards. Entrust all repairs to qualified service technicians. 18. Damage requiring repair - In the following situations, unplug the set-top box from the power outlet and have it repaired by qualified service technicians: A. -
Page 9: Home
Home Information About This STB Front panel Power indicator Display Channel USB port up/down Remote control sensor Standby button (Stand-by mode) Rear panel TV antenna For external TV antenna 12V/1A DC power supply TV Scart Connecting to a TV set Digital coaxial audio RF IN RF OUT COAXIAL... - Page 10 Remote control RED/GREEN/YELLOW/Blue button (For interactive functions / Nested menu function buttons) EPG (Electronic Programme Guide) (Open the Electronic Programme Guide menu) OK button (Confirmation of selection in the offer) Cursor / CH+,- (Previous/Next Channel) / VOL+,- (Volume Up/ Down) (Cursor: Navigation buttons to browse menu items) (CH+/-: Previous/Next channel)
-
Page 11: Learning Remote Control
Learning remote control (1) The remote control with four learning buttons is compatible with Sencor set top box models SDB 550T, SDB 5002T, SDB 5003T, SDB 5104T (first group, factory set) or SDB 520T (second group, after switching mode). In case your set top box does not respond to the commands of this remote control, first check the battery level (AAA, not included) -
Page 12: System Connection
System connection General information There are many different types of TVs and other devices that can be connected to this STB. This guide lists the most common ways to connect your devices. Connecting a TV HDMI TV Antenna Scart cable RF cable Remark: Please connect the HDMI cable to the receiver ONLY when turned off (red Standby indicator lights) -
Page 13: Get Started
Get Started Welcome When using this STB for the first time, “Welcome" menu will appear. Press the cursor keys to set Region, Language, Display Mode and Aspect Mode. Highlight “OK” and press “OK” to start searching the channels. Installation The Installation menu allows you to set channel searching and LCN Installation option. Press the "MENU"... - Page 14 Channel Scan The “Channel scan” menu allows you to set manual channel searching. Select “Channel Scan” and press "OK” to open the Channel Scan menu. Press the cursor buttons to set Scan Mode, Scan Band, Channel No. Frequency, Bandwidth, then highlight “Search” and press “OK” to start the channel searching. LCN (Logical Channel Numbering) If the LCN (Logical channel numbering) feature is enabled, you cannot change the original TV channel numbers created by searching.
-
Page 15: Controls
Controls Switching Channels There are three ways to select a channel - by scrolling through the channel list, selecting by number and selecting from the on-screen channel list. Scroll through the channel list: To move through the channel list, press the up or down arrow button on the remote control. -
Page 16: Editing Channels
Editing channels Edit Channel menu Press the "MENU" button to open the main menu. Press the “UP” or “DOWN” button to highlight “Edit Channel” and press “RIGHT” to open the “Edit Channel” menu. Press the “UP” or DOWN” cursor button to highlight the desired item, then press “OK”... -
Page 17: Radio Channel List
• Press the "GREEN" button to enable the “Skip” feature, then press “OK” to skip the selected channel. • Press the “YELLOW” button to enable the “Move” feature, highlight the desired channel and press OK to confirm. Press “UP” or “DOWN” button to select a new position, then press “OK”. -
Page 18: System Settings
System Settings System Setup menu The System Setup alows you to set Language, TV System, Local Time Setting, Timer Setting, Parental Lock, OSD Setting, Favorite, Audio Description Setting and Other. Press the "MENU" button to open the main menu. Press the “UP” or “DOWN” button to highlight “System Setup” and press “RIGHT” to open the System Setup”... -
Page 19: Tv System
TV System This menu allows you to set Video Resolution, Aspect Mode, Video Out and Digital Audio Out. Video Resolution: Setting different video signal resolutions Aspect Mode: Auto / 4:3PS / 4:3LB / 16:9 Video Out:CVBS/RGB Digital Audio Out: LPCM Out (LPCM output) / BS Out (BS output) Local Time Setting This menu allows you to make region and time settings. -
Page 20: Timer Setting
Timer Setting This menu allows you to set the programme timer. You can set up to 32 timers. Timer Mode: Off / Once / Daily / Weekly / Monthly Timer Service: Channel / Record Wakeup Channel: Allows you to set the channel to be tuned during the wakeup. Wakeup Date: Press the numeric buttons to set the wakeup date. -
Page 21: Osd Setting
OSD Setting This menu allows you to set the display duration and transparency of your OSD menu. OSD Timeout: 1-10 seconds. OSD Transparency: To set the OSD menu transparency to Off / 10% / 20% / 30% / 40%. Favorite This menu allows you to rename the favorite group. -
Page 22: Audio Description Setting
Audio Description Setting This menu allows you to set Use AD as default and AD Volume Offset: This is only applicable to programs for which the sound description is broadcast by a TV station Use AD as default: On/Off AD Volume Offset: -3 ~ 3 Other This menu allows you to set Antenna Power, Channel Play Type, Auto Standby Antenna Power (Power supply to the antenna): On/Off... -
Page 23: Tools
Tools Tools main menu Press the "MENU" button to open the main menu. Press the “UP” or “DOWN” button to highlight “Tools” and press “RIGHT” to open the “Tools” menu. Press the “UP” or DOWN” cursor button to highlight the desired item, then press “OK”... -
Page 24: Software Upgrade
Software Upgrade This unit offers features for the user to update the software version - either wirelessly (OTA) or using a USB flash drive. Open the “Tools“ menu, select “S/W Upgrade by OTA” or "Upgrade by USB” and press “OK” - Software Upgrade menu appears. Press the cursor buttons to select a desired option and then highlight “Start”... -
Page 25: Multimedia Player
Multimedia player Multimedia player main menu Make sure that external data storage device is connected to the USB port. Press the "MENU" button to open the main menu. Press the “UP” or “DOWN” button to highlight “Media Player” and press the “RIGHT” button to open the multimedia player menu. - Page 26 Video: BLUE button: Press the “BLUE” button to open the nested Edit channel menu. “1” button: Press to switch among Music /Image /Video /Record tabs. “2” button: Press the button “2” to open the sorting. You can sort by Name / Time / Size. EXIT (End) button: Return to the parent directory.
- Page 27 HDD Information This menu allows you to display some parameters of the exchangeable disc. In the Media Player menu, select “HDD Information“ and press “OK” to open the disc information window. Press the "EXIT" button to exit. Press the YELLOW button to open the Format menu. •...
-
Page 28: Dvr Settings
DVR Settings This menu allows you to set the DVR Setting parameters. In the ”Media Player” menu, select “DVR Setting” and press “OK” to open the “DVR Settings” menu. Press the “UP” or “DOWN” cursor button to select the desired item, then press the “LEFT”... -
Page 29: Time Shift / Recording
Time shift / recording Connecting a Mass Storage Device to the USB port will enable the Time Shift/Record feature for a broadcast program. • Pause the program being broadcast and resume the watching later on (Time Shift feature). • Record the broadcast program. •... -
Page 30: Record
Record Instantaneous record • To start recording the main channel immediately, press "RECORD” in the view mode. • Press “RECORD” once again to set the time duration. To stop recording, press the "STOP" button - a confirmation window will appear. • To stop the recording, select “Yes”. -
Page 31: Troubleshooting
Troubleshooting The Problem Possible cause What to do Standby indicator is Disconnected power adapter. Check the mains adapter. not lit. No signal detected. Disconnected antenna. Check the antenna cable. Damaged / incorrectly adjusted Check the antenna. antenna. Consult your dealer. You are outside the digital signal coverage area. -
Page 32: Technical Data
Technical Data TUNER AND CHANNEL • RF INPUT CONNECTOR × 1 (IEC TYPE, IEC169-2, DRAWER TYPE) • VF OUTPUT CONNECTOR × 1 (IEC TYPE, IEC169-2, MALE (BYPASS LOOP)) • FREQUENCY BAND: 174MHz ~ 230MHz (VHF) 470MHz ~ 862MHz (UHF) • SIGNAL LEVEL: -15 ~ -70 dBm DECODER •... - Page 33 FAST ČR, a.s. hereby declares that the radio device type SDB 5006T conforms to the 2014/53/EU directive. For full version of the EU declaration of conformity, please refer to www.sencor.
- Page 34 Manufacturer: FAST ČR, a.s., U Sanitasu 1621, Říčany 251 01, Czech Republic Visit www.sencor.com for detailed information about authorized service centers. The original version of the instructions is in the Czech language, other language versions are made by the appropriate translation.
- Page 35 FAST ČR, a.s., U Sanitasu 1621, Říčany CZ-251 01...
