Page 1: Open Pluggable Specification (Ops)
OPS-H610B Open Pluggable Specification (OPS) Quick Start Guide www.gigaipc.com... -
Page 2: Copyright Notice
While reasonable efforts have been made in the preparation of this document to assure its accuracy, GIGAIPC assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. -
Page 3: Acknowledgement
Core, Atom are trademarks of Intel Corporation ITE is a trademark of Integrated Technology Express, Inc. • • IBM, PC/AT, PS/2, and VGA are trademarks of International Business Machines Corporation. All other product names or trademarks are properties of their respective owners. www.gigaipc.com... -
Page 4: Packing List
Exsiccator (25g) ※The ratio of OPS system to antennas is 1:2 Quantity of above items by varied based on the actual packing. If any of these items are missing or damaged, please contact your distributor or sales representative immediately. www.gigaipc.com... -
Page 5: About This Document
(if any), its specifications, dimensions, jumper/ connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the GIGAIPC.com for the latest version of this document. www.gigaipc.com... -
Page 6: Safety Precautions
Make sure the device is installed near a power outlet and is easily accessible. 10. Keep this device away from humidity. 11. Place the device on a solid surface during installation to prevent falls 12. Do not cover the openings on the device to ensure optimal heat dissipation. www.gigaipc.com... - Page 7 18. D O N O T L E AV E T H I S D E V I C E I N A N U N C O N T R O L L E D ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO PREVENT DAMAGE. www.gigaipc.com...
-
Page 8: Fcc Statement
Skilled person have to pay special attention or take special protection. Only authorized by well trained professional person can access the restrict access location. (2) External metal parts are hot!! Before touching it, special attention or protection is necessary www.gigaipc.com... -
Page 9: Table Of Contents
B) M.2 SSD Installation: How to safely install the M.2 2280 SSD ..............21 C) Wireless Module: How to safely install the Module (Wireless Module inclusion may vary based on local distribution) ..............22 Antenna Installation (Antenna inclusion may vary based on local distribution) ............ 23 www.gigaipc.com... - Page 10 IT8613 Super IO Configuration ........43 4.3.4 Hardware Monitor ............44 4.3.5 S5 RTC Wake Settings ........... 45 4.3.6 Network Stack Configuration ........46 4.3.7 NVMe Configuration ............. 47 4.3.8 Offboard SATA Controller Configuration ...... 48 4.3.9 Tls Auth Configuration ..........49 www.gigaipc.com...
- Page 11 4.3.10 Realtek PCIe GBE Family Controller (MAC:10:FF:E0: 30:95:F4)(MAC address may varied based on different motherboard)..............50 Chipset ................51 Security ................. 52 Boot ................55 Save & Exit ..............56 www.gigaipc.com...
-
Page 12: Chapter 1 - Product Specifications
Chapter 1 Chapter 1 - Product Specifications www.gigaipc.com... - Page 13 www.gigaipc.com...
-
Page 14: Specifications
2 x External Antenna Holes 1 x Reset button 1 x Power button 1 x PWR LED 1 x HDD LED Rear I/O 1 x 80-pin JAE Tx25 OPS connector Onboard TPM 2.0 security chip INFINEON SLB9670VQ2.0 Windows 10/11 (x64) Compatibility www.gigaipc.com... - Page 15 Operation: IEC 60068-2-27, 50 G, half sine, 11 ms duration, With Operation Carton size: 505 x 333 x 231 (mm) Packing Capacity: 10pcs Packaging Content Including: External Antenna x 20 (P/N: 25CA0-112001-A5S) ※ The ratio of OPS system to antennas is 1:2 Order System: 6BOPH610BNR-SI (Bulk Packing) Information www.gigaipc.com...
-
Page 16: Chapter 2 - Ops-H610B (Op-H610B-Si) Open Pluggable Specification System Kit
Chapter 2 Chapter 2 – OPS-H610B (OP-H610B-SI) Open Pluggable Specification System Kit www.gigaipc.com... -
Page 17: Dimension
Dimension www.gigaipc.com... -
Page 18: Getting Familiar With Your Unit
2 x Antenna HDD LED Reset button USB 3.2 Type C Gen 1 USB 3.2 Gen 1 Combo Audio Jack RJ45 LAN Port (Headphone & Headset) Display port Power button PWR LED [Rear Side] [Right Side] 80-pin JAE Tx25 OPS connector www.gigaipc.com... - Page 19 * Before Connecting the power, make sure to fasten the case securely. [Bottom PCB Side] Information Information 1 x M.2 slot 2280 M-key 1 x DDR4 SO-DIMM socket 1 x M.2 slot 2230 E-key www.gigaipc.com...
-
Page 20: A) Memory Installation: Ddr4 So-Dimm
A) Memory Installation: DDR4 SO-DIMM www.gigaipc.com... -
Page 21: B) M.2 Ssd Installation: How To Safely Install The
Remove the screw from the screw Carefully insert the M.2 SSD into the Carefully insert the wireless module into Lock the screw in the middle. the M.2 slot hole (Location : MSO1) slot, and secure with the screw. 鎖入固定於無線模組中央頂端的螺 小心地將無線模組安裝於M.2插槽中。 絲。 www.gigaipc.com... -
Page 22: C) Wireless Module: How To Safely Install The Module (Wireless Module Inclusion May Vary Based On Local Distribution)
Carefully insert the wireless module into Carefully insert the wireless module into (Location : MSO2) the M.2 slot the M.2 slot 小心地將無線模組安裝於M.2插槽中。 Lock the screw in the middle. Install the antenna on the left side of the connection wireless module down. www.gigaipc.com... -
Page 23: Antenna Installation (Antenna Inclusion May Vary Based On Local Distribution)
Antenna Installation (Antenna inclusion may vary based on local distribution) www.gigaipc.com... -
Page 24: I/O Pin-Define
USB Type C Connector Pin No. Definition Pin No. Definition TX1+ TX2+ TX1- TX2- VBUS VBUS VBUS VBUS RX2- RX1- RX2+ RX1+ 2. USB 3.2 Type A Gen 1 port USB Connector Pin No. Definition USB3_RX1n USB3_RX1p USB3_TX1n USB3_TX1p www.gigaipc.com... - Page 25 Orange On 1Gbps data rate Green On 100Mbps data rate 10Mbps data rate 4. Display port DP Connector Pin No. Definition Pin No. Definition TX0p TX3n TX0n TX1p AUXp TX1n TX2p AUXn Hot Plug Detect TX2n 3.3V TX3p 3.3V www.gigaipc.com...
-
Page 26: Support
Support ● For AVL list, go to: http://www.gigaipc.com ● To download the latest drivers, go to: http://www.gigaipc.com ● For product support, go to: http://www.gigaipc.com www.gigaipc.com... -
Page 27: Safety And Regulatory Information
At the end of its serviceable life, this product should not be treated as household or general waste. It should be handed over to the applicable collection point for the recycling of electrical and electronic equipment, or returned to the supplier for disposal. www.gigaipc.com... -
Page 28: Chapter 3 - Hardware Information
Chapter 3 Chapter 3 – Hardware Information www.gigaipc.com... -
Page 29: Jumpers And Connectors
Jumpers and Connectors www.gigaipc.com... - Page 30 Code Description CPU_FAN CPU fan connector SODIMM DDR4 SO-DIMM Slot BATTERY Battery cable connector M.2 Slot, 2230 E-key M.2 Slot, 2280 M-key www.gigaipc.com...
-
Page 31: Cpu_Fan (Cpu Fan Connector)
3.2.1 CPU_FAN (CPU fan connector) Pin 1 CPU fan Connector Connector PN Vendor 85205-0470N ACES A1250WV-S-04PC JOINT-TECH Connector type 1x4pin header, pitch 1.25mm Pin No. Definition Detect Speed control www.gigaipc.com... -
Page 32: Sodimm (Ddr4 So-Dimm Slot)
3.2.2 SODIMM (DDR4 SO-DIMM Slot) www.gigaipc.com... -
Page 33: Battery (Battery Cable Connector)
3.2.3 BATTERY (Battery cable Connector) Pin 1 Battery cable Connector Connector PN Vendor 85205-0270L ACES A1250WV-S-02PC JOINT-TECH Connector type 1x2pin header, pitch 1.25mm Pin No. Definition www.gigaipc.com... -
Page 34: M2E (M.2 Slot, 2230 E-Key)
M.2 E Key Connector PCIe_RXp CL_DATA PCIe_RXn CL_CLK CLK_Dp CLK_Dn SUSCLK Pin No. Definition Pin No. Definition CLK_REQ PCIe_RST PCIe_WAKE BT_Disable# USB_Dp PCIe_DISABLE USB_Dn Connector PN Vendor Pin No. Definition Pin No. Definition APCI0076-P001A LOTES AS0BC21-S40BE-7H FOXCONN PCIe_TXp PCIe_TXn www.gigaipc.com... -
Page 35: M2M (M.2 Slot, 2280 M-Key)
PLT_RST 3.3V CK_REQ PCIE_RXn3 CLK_n PCIE_WAKE# PCIE_RXp3 CLK_p PCIE_TXn3 3.3V Pin No. Definition Pin No. Definition PCIE_TXp3 3.3V SUSCLK 3.3V PCIE_RXn2 3.3V M2_SSD_ 3.3V Detect PCIE_RXp2 3.3V 3.3V PCIE_TXn2 PCIE_TXp2 Connector PN Vendor PCIE_RXn1 APCI0073-P001A LOTES PCIE_RXp1 AS0BC21-S40BM-7H FOXCONN www.gigaipc.com... -
Page 36: Chapter 4 - Bios
Chapter 4 Chapter 4 – BIOS www.gigaipc.com... -
Page 37: Introduction
Execute command or enter the submenu Increase the numeric value or make ＋ changes Decrease the numeric value or make – changes General Help Previous Values Load Optimized Defaults Settings Save changes & Exit the BIOS Setup program Exit the BIOS Setup program www.gigaipc.com... -
Page 38: The Main Menu
ME FW version Shows ME firmware version Set the Date for the system System Date (Format : Week - Month - Day - Year) Set the time for the system System Time (Format : Hour - Minute - Second) www.gigaipc.com... -
Page 39: Advanced
Advanced The Advanced menu is to configure the functions of hardware settings through submenu. Use arrow keys to move among the items, and press <Enter> to access into the related submenu. www.gigaipc.com... -
Page 40: Tpm Configuration
4.3.1 TPM Configuration Use TPM Configuration submenu to choose TPM interface. Item Description PTT : Internal TPM TPM Device dTPM : External TPM (When using External TPM module or having Selection TPM chip on MB)(Default setting) www.gigaipc.com... - Page 41 Item Description Security Device Enabled : Enables TPM feature (Default setting) support Disabled : Disables TPM feature None : No execution will be conducted (Default setting) Pending operation TPM clear : Set to clear data on TPM www.gigaipc.com...
-
Page 42: Cpu Configuration
C states Enabled : Enables C states (Default setting) Disabled : Disables C states To optimize CPU performance. Dual Tau Boost Enabled : Enables Dual Tau Boost function Disabled : Disables Dual Tau Boost function (Default setting) www.gigaipc.com... -
Page 43: It8613 Super Io Configuration
Disabled : if Disabled, displays no configuration for the serial port Device settings : Serial Port 1 Display the specified Serial Port base I/O address and IRQ Configuration Change settings : Auto (Default setting) IO=3F8h; IRQ=3; IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12; IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12; IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; www.gigaipc.com... -
Page 44: Hardware Monitor
Normal : Fan speed set by BIOS default(Default setting) Control Full Speed : Set Fan operates at full speed CPU Temperature Shows current CPU temperature System Shows current system temperature Temperature CPU Fan Speed Shows current CPU fan Speed www.gigaipc.com... -
Page 45: S5 Rtc Wake Settings
Enable or Disable System to wake on a specific time. Disabled : Disables system to wake on a specific time (Default Wake system setting) from S5 Fixed Time : Enables system to wake on a specific time (Format : hr : min : sec) www.gigaipc.com... -
Page 46: Network Stack Configuration
Disabled : Disables IPv6 HTTP Support Enabled : Enables IPv6 HTTP Support PXE boot wait time Wait time in seconds, or use ESC key to abort the PXE boot. Media detect count Number of times the presence of media will be checked. www.gigaipc.com... -
Page 47: Nvme Configuration
4.3.7 NVMe Configuration NVMe Configuration shows information when your M.2 NVMe PCIe SSD is installed. www.gigaipc.com... -
Page 48: Offboard Sata Controller Configuration
4.3.8 Offboard SATA Controller Configuration www.gigaipc.com... -
Page 49: Tls Auth Configuration
Press [Enter] to configure advanced items : Server CA Configuration : Enroll Cert : 1. Enroll Cert Using File Enroll Cert 2. Cert GUID : Input digit character in 11111111-2222-3333-4444-1234567 890ab format. 3. Commit Changes and Exit 4. Discard Changes and Exit www.gigaipc.com... -
Page 50: Realtek Pcie Gbe Family Controller (Mac:10:Ff:e0: 30:95:F4)(Mac Address May Varied Based On Different Motherboard)
4.3.10 Realtek PCIe GBE Family Controller (MAC:10:FF:E0:30:95:F4) (MAC address may varied based on different motherboard) Shows Realtek Ethernet controller information www.gigaipc.com... -
Page 51: Chipset
Enable/Disable Control Iommu Pre-boot behavior Pre-boot Disabled : Disables IOMMU during boot (Default setting) Behavior Enabled : Enables IOMMU during boot Enable/Disable BIOS Lock function BIOS Lock Enabled : Enables BIOS Lock function (Default setting) Disabled : Disabled BIOS Lock funtion www.gigaipc.com... -
Page 52: Security
To set up Administrator's password Administrator Minimum length : 3 Password Maximum length : 20 To set up User's password User Password Minimum length : 3 Maximum length : 20 Secure Boot Press <Enter> to configure the advanced items www.gigaipc.com... - Page 53 Yes : Agree to setup mode Mode No : Cancel to setup mode When Secure Boot mode is set to Custom : Enables expert users to modify Secure boot policy variables without Key Management full authentication Press <Enter> to configure the advanced items www.gigaipc.com...
- Page 54 Device Guard ready system variables file system device must not list ’Microsoft MS UEFI CA Key UEFI CA’ Certificate in A u t h o r i z e d S i g n a t u r e database(db) www.gigaipc.com...
-
Page 55: Boot
Enable/Disable Built-in EFI Shell Built-in EFI shell Enabled : Enables Built-in EFI Shell Disabled : Disables Built-in EFI Shell (Default setting) Boot Option Shows the information of the storage that be installed in the system Priorites Choose/set the boot priority www.gigaipc.com... -
Page 56: Save & Exit
Yes : Agree to load optimized defaults No : Cancel to load optimized defaults Enable/Disable Me FW image re-flash function Me FW Image Enabled : Enables Me FW image re-flash function Re-Flash Disabled : Disables Me FW image re-flash function (Default setting) www.gigaipc.com...
