Page 1: Qbix-Jwb Industrial Embedded System
QBiX-JWB-SKYB110H-A1 (QJ-H110B-SI) QBiX-JWB Industrial Embedded System Quick Start Guide www.gigaipc.com... -
Page 2: Copyright Notice
While reasonable efforts have been made in the preparation of this document to assure its accuracy, GIGAIPC assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. -
Page 3: Acknowledgement
Core, Atom are trademarks of Intel Corporation • • ITE is a trademark of Integrated Technology Express, Inc. IBM, PC/AT, PS/2, and VGA are trademarks of International Business • Machines Corporation. All other product names or trademarks are properties of their respective owners. www.gigaipc.com... -
Page 4: Packing List
Before setting up your product, please make sure the following items have been shipped: Item Quantity System kit 1 pcs HDD screw, M3 x 8L 8 pcs Exsiccator (10g) 1 pcs If any of these items are missing or damaged, please contact your distributor or sales representative immediately. www.gigaipc.com... -
Page 5: About This Document
(if any), its specifications, dimensions, jumper/ connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the GIGAIPC.com for the latest version of this document. www.gigaipc.com... -
Page 6: Safety Precautions
Make sure the device is installed near a power outlet and is easily accessible. 10. Keep this device away from humidity. 11. Place the device on a solid surface during installation to prevent falls 12. Do not cover the openings on the device to ensure optimal heat dissipation. www.gigaipc.com... - Page 7 19. D O N O T L E AV E T H I S D E V I C E I N A N U N C O N T R O L L E D ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO PREVENT DAMAGE. www.gigaipc.com...
-
Page 8: Fcc Statement
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte. Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le constructeur. Recycler les batteries usées en accord avec les instructions du fabricant et les directives gouvernementales de recyclage. www.gigaipc.com... -
Page 9: Table Of Contents
About this Document ..............5 Safety Precautions ............... 6 FCC Statement ................8 Chapter 1 - Product Specifications Specifications ............... 15 Chapter 2 – QBiX-JWB-SKYB110H-A1 (QJ-H110B-SI) Industrial Embedded System Kit Dimension ..............18 Getting Familiar with Your Unit........19 Support ................ 21 Safety and Regulatory Information ....... - Page 10 F_USB 20_2 (USB 2.0 header) ........35 3.2.10 F_USB 20_3 (USB 2.0 header) ........36 3.2.11 GPIO_CNT ..............37 3.2.12 COM1 (Serial Port header) ..........38 3.2.13 JCOM11 (Default COM1 is RI pin, can select RI/5V/12V) ..................39 3.2.14 COM2 (Serial Port header) ..........40 www.gigaipc.com...
- Page 11 The Main Menu ............50 Advanced Menu ............52 4.2.1 CPU Configuration Menu ..........53 4.2.2 A Trusted Computing Menu ......... 55 4.2.3 SATA Configuration ............56 4.2.4 Hardware Monitor Menu ..........57 4.2.5.1 IT8786 Super IO Configuration Menu ......58 www.gigaipc.com...
- Page 12 CSM Support ..............61 4.2.8 Digital IO Port Configuration Menu ......62 Chipset Menu ..............63 Security Menu ............... 65 4.4.1 Secure Boot Menu ............66 4.4.1.1 Key Management Menu ..........67 Boot Menu ..............70 Save & Exit Menu ............71 www.gigaipc.com...
-
Page 13: Chapter 1 - Product Specifications
Chapter 1 Chapter 1 - Product Specifications www.gigaipc.com... - Page 14 www.gigaipc.com...
-
Page 15: Specifications
Specifications System QBiX-JWB-SKYB110H-A1 (QJ-H110B-SI) Dimension System Size : 273W x 203D x 91H (mm) Supports for 6/7th Generation Intel® Core™ i7/i5/i3, Pentium® & Celeron® processors, TDP under 35W Chipset Intel® H110 Express Chipset 2 x DDR4 SO-DIMM sockets, Max. Capacity 32 GB,... - Page 16 System QBiX-JWB-SKYB110H-A1 (QJ-H110B-SI) 3 x Audio Jacks (Line in, Line out, Mic in) 1 x VGA 1 x HDMI Rear I/O 6 x RJ45 LAN ports 4 x USB 3.0 1 x 3-pin Terminal Block 2 x External Antenna Hole (Optional)
-
Page 17: Chapter 2 - Qbix-Jwb-Skyb110H-A1 (Qj-H110B-Si) Industrial Embedded System Kit
Chapter 2 Chapter 2 – QBiX-JWB-SKYB110H-A1 (QJ-H110B-SI) Industrial Embedded System Kit www.gigaipc.com... -
Page 18: Dimension
Dimension www.gigaipc.com... -
Page 19: Getting Familiar With Your Unit
Getting Familiar with Your Unit [Front Side] [Rear Side] www.gigaipc.com... - Page 20 [Install] x Before opening the case, make sure to unplug the power cord. x Before Connecting the power, make sure to fasten the case securely. www.gigaipc.com...
-
Page 21: Support
Support ● For a list of tested memory, M.2, 2.5’’ SSD, wireless adapters and OS supported, go to: http://www.gigaipc.com ● To download the latest drivers and BIOS updates, go to: http://www. gigaipc.com ● For product support, go to: http://www.gigaipc.com www.gigaipc.com... -
Page 22: Safety And Regulatory Information
At the end of its serviceable life, this product should not be treated as household or general waste. It should be handed over to the applicable collection point for the recycling of electrical and electronic equipment, or returned to the supplier for disposal. www.gigaipc.com... -
Page 23: Chapter 3 - Hardware Information
Chapter 3 Chapter 3 – Hardware Information www.gigaipc.com... -
Page 24: Jumpers And Connectors
3.1.1 Jumpers and Connectors 6 28 12 11 www.gigaipc.com... - Page 25 Default COM2 is RI pin, can select RI/5V/12V mSATA Connector Mini PCIe Slot M.2 slot 2422/2880 storage SATA PCIE16X PCIE x16 slot SATAIII_0 SATA 6Gb/s connector SATAIII_1 SATA 6Gb/s connector SATAPW_1 SATA 6Gb/s power connector SATAPW_2 SATA 6Gb/s power connector www.gigaipc.com...
-
Page 26: I/O
M.2 Slot, M-Key, SATA 6Gb/s & PCIe, Supports M2_M NGFF-2280 Card 3.1.2 Code Description DC_IN DC In Jack VGA D-sub port GbE LAN port Line-in Line-in Port Line-out Line-out Port Mic-in Mic-in Port USB30 USB 3.0 ports HDMI HDMI port www.gigaipc.com... -
Page 27: At_Cn (At/Atx Power Mode Select Jumper)
AT_CN (AT/ATX power mode select jumper) Pin 1 AT/ATX power mode select jumper Connector PN Vendor PH03N33BAAA00 HORNGTONG Pin No. Definition AT MODE Detect ATX MODE Jumper setting 1-2 Close : AT mode. 2-3 Close : ATX mode.(Default setting) www.gigaipc.com... -
Page 28: Battery
3.2.2 Battery Pin 1 Battery Cable Connector Connector PN Vendor 85205-0270L ACES A1250WV-S-02PC JOINT-TECH Pin No. Definition 3.3V www.gigaipc.com... -
Page 29: Clr_Cmos
3.2.3 CLR_CMOS Pin 1 Clear COMS Jumper Connector PN Vendor 210-91-02GB01 PINREX PH02R23BAZ000 HORNGTONG Pin No. Definition Clear CMOS Open: Normal Operation (Default setting) Close: Clear COMS data. www.gigaipc.com... -
Page 30: Cpu_Fan (Cpu Fan Connector)
3.2.4 CPU_FAN (CPU fan connector) Pin 1 CPU FAN Connector PN Vendor 744-81-045W11 PINREX WF04R22WJQ195 HORNGTONG Pin No. Definition Detect Speed Control www.gigaipc.com... -
Page 31: Dc_In (Dc In Jack Connector)
3.2.5 DC_IN (DC In JACK Connector) DC JACK Connector Connector PN Vendor 2MJ-3422A1I0 SINGATRON Note: *Connect only to a properly wired and ground outlet. www.gigaipc.com... -
Page 32: Dc_In2 (Atx 2X2 Pin Power Connector)
3.2.6 DC_IN2 (ATX 2x2 pin power connector) Pin 1 Power Connector Connector PN Vendor 740-81-04TW56 PINREX 25104A0400B3-93LF ATRC Note: *Connect only to a properly wired and ground outlet. Pin No. Definition +12V +12V www.gigaipc.com... -
Page 33: F_Audio (Front Audio Header)
3.2.7 F_Audio (Front audio header) Pin 1 Front Audio Connector Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Definition Pin Definition MIC_L MIC_R No Connect Detect HPOUT_L HPOUT_R www.gigaipc.com... -
Page 34: F_Usb 20_1 (Usb 2.0 Header)
3.2.8 F_USB 20_1 (USB 2.0 header) Pin 1 USB 2.0 Header Connector PN Vendor 210-92-05GB04 PINREX PH10R53BAZ009 HORNGTONG Pin No. Definition No Pin No Connect www.gigaipc.com... -
Page 35: F_Usb 20_2 (Usb 2.0 Header)
3.2.9 F_USB 20_2 (USB 2.0 header) Pin 1 USB 2.0 Header Connector PN Vendor 210-92-05GB04 PINREX PH10R53BAZ009 HORNGTONG Pin No. Definition No Pin No Connect www.gigaipc.com... -
Page 36: F_Usb 20_3 (Usb 2.0 Header)
3.2.10 F_USB 20_3 (USB 2.0 header) Pin 1 USB 2.0 Header Connector PN Vendor 210-92-05GB04 PINREX PH10R53BAZ009 HORNGTONG Pin No. Definition No Pin www.gigaipc.com... -
Page 37: 3.2.11 Gpio_Cnt
3.2.11 GPIO_CNT Pin 1 GPIO Connector Pin No. Definition SMB_CLK SMB_DATA Connector PN Vendor Pin No. Definition 725-81-12TW00 PINREX GPO1 GPI1 A2004WV-2X06P46 JOINT-TECH GPO2 GPI2 GPO3 GPI3 GPO4 GPI4 www.gigaipc.com... -
Page 38: Com1 (Serial Port Header)
3.2.12 COM1 (Serial Port header) Pin 1 Serial Port Cable Connector Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Definition Pin Definition No Connect RI/ 5V/ 12V www.gigaipc.com... - Page 39 3.2.13 JCOM11 (Default COM1 is RI pin, can select RI/5V/12V) Pin 1 JCOM11 Jumper Connector PN Vendor 220-97-03GB01 PINREX 1-2 Close: PH06N53BAZ000 HORNGTONG 5V (Power COM) 3-4 Close: RI (Stand COM) 5-6 Close: 12V (Power COM) www.gigaipc.com...
-
Page 40: Com2 (Serial Port Header)
3.2.14 COM2 (Serial Port header) Pin 1 Serial Port Cable Connector Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Definition Pin Definition No Connect RI/ 5V/ 12V www.gigaipc.com... - Page 41 3.2.15 JCOM21 (Default COM2 is RI pin, can select RI/5V/12V) Pin 1 JCOM21 Jumper Connector PN Vendor 220-97-03GB01 PINREX 1-2 Close: PH06N53BAZ000 HORNGTONG 5V (Power COM) 3-4 Close: RI (Stand COM) 5-6 Close: 12V (Power COM) www.gigaipc.com...
-
Page 42: Sataiii_0, Sataiii_1 (Sata 6Gb/S Connector)
3.2.16 SATAIII_0, SATAIII_1 (SATA 6Gb/s Connector) 21 22 SATA Connector SATAIII_1,SATAIII_0 Connector PN Vendor WATM-07ABNB2BAUW3 WINWIN 770-83-07SW19 PINREX Pin No. Definition www.gigaipc.com... -
Page 43: Satapw_1, Satapw_2 (Sata 6Gb/S Power Connector )
3.2.17 SATAPW_1, SATAPW_ 2 (SATA 6Gb/s Power Connector ) 23 24 Pin 1 Hard Disk Power Connector Connector PN Vendor 743-81-04TW00 PINREX WF04Q2-3BJQ000 HORNGTONG Pin No. Definition www.gigaipc.com... -
Page 44: Spk_Out (Speaker Out Connector)
3.2.18 SPK_OUT (Speaker out Connector) Pin 1 Audio Amplifie Connector Connector PN Vendor 721-81-045W00 PINREX A2001WV-04P146 JOINT-TECH Pin No. Definition Speaker Out L+ Speaker Out L- Speaker Out R- Speaker Out R+ www.gigaipc.com... -
Page 45: Sys_Fan (System Fan Connector)
3.2.19 SYS_FAN (System Fan Connector) Pin 1 System FAN Connector PN Vendor 744-81-045R11 PINREX WF04R22RJQ105 HORNGTONG Pin No. Definition Detect Speed Control www.gigaipc.com... -
Page 46: Sys_Panel (Front Panel Header)
3.2.20 SYS_PANEL (Front Panel Header) Pin 1 System Panel Header Connector PN Vendor 210-92-05G111 PINREX Pin No. Definition HDD LED+ Power LED+ HDD LED- Power LED- Power Button+ Reset Button Power Button- No Connect No Pin www.gigaipc.com... -
Page 47: Tpm_Lpc (Trusted Platform Module Connector)
3.2.21 TPM_LPC (Trusted Platform Module Connector) Pin 1 TPM Module Connector Pin No. Definition LAD3 LFRAME Pin No. Definition LPCCLK Connector PN Vendor 3VDUAL 52M-90-14GBE7 PINREX PFM RST VCC3 LAD0 IRQ_SERIAL LAD1 TPM_DET LAD2 www.gigaipc.com... -
Page 48: M2_M
2.2.22 M2_M (M.2 Slot, M-Key, SATA 6Gb/s & PCIe, Supports NGFF-2280/2242 Card) www.gigaipc.com... -
Page 49: Chapter 4 - Bios
Chapter 4 Chapter 4 – BIOS www.gigaipc.com... -
Page 50: The Main Menu
• When the system is not stable as usual, select the Restore User Defaults item to set your system to its defaults. • The BIOS Setup menus described in this chapter are for reference only and may differ by BIOS version. www.gigaipc.com... - Page 51 » LAN1/2/3/4/5/6 MAC Address » Total Memory Displays the technical specifications for the installed memory. » ME FW Version » System Date Set the date following the weekday-month-day- year format. » System Time Set the system time following the hour-minute- second format. www.gigaipc.com...
-
Page 52: Advanced Menu
Advanced Menu The Advanced menu display submenu options for configuring the function of various hardware components. Select a submenu item, and then press Enter to access the related submenu screen. www.gigaipc.com... -
Page 53: Cpu Configuration Menu
Enables or disables Intel® Virtualization Technology. Virtualization enhanced by Intel® Virtualization Technology will allow a platform to run multiple operating systems and applications in independent partitions. With virtualization, one computer system can function as multiple virtual systems. Options available: Enabled/Disabled. Default setting is Enabled www.gigaipc.com... - Page 54 Options available: Enabled/Disabled. Default setting is Enabled » Intel® Speed Shift Technology Enables or disables support for Intel® Speed Shift Technology Options available: Enabled/Disabled. Default setting is Enabled » CFG lock Enable/Disable CFG lock. Options available: Enabled/Disabled. Default setting is Disabled www.gigaipc.com...
-
Page 55: A Trusted Computing Menu
(if you are initializing TPM you should select Enable Take Ownership). You will then need to press F4 to save the changes and restart the computer. You can now install the TPM driver and then initialize the TPM. www.gigaipc.com... -
Page 56: Sata Configuration
The hard disk will not work properly if you enter improper information for this category. Hard drive information should be labeled on the outside device casing. Enter the appropriate option based on this information. www.gigaipc.com... -
Page 57: Hardware Monitor Menu
4.2.4 Hardware Monitor Menu » CPU/ System Temperature Displays current system/ CPU temperature. » VCORE/ DDR1.2V/ +12V/ VCC/ VCC3 Displays a real-time record of the related system voltage. www.gigaipc.com... -
Page 58: 4.2.5.1 It8786 Super Io Configuration Menu
4.2.5.1 IT8786 Super IO Configuration Menu » Serial Port 1 Configuration Press [Enter] for configuration of advanced items. www.gigaipc.com... -
Page 59: 4.2.5.2 Serial Port Configuration Menu
Options available: Enabled/Disabled. Default setting is Enabled. » Device Settings Display the specified Serial Port base I/O address and IRQ. » COM Mode Select Mode of serial port. Options available: RS-232 / RS-485 / RS-485&RS-422 Default setting is RS-232. www.gigaipc.com... -
Page 60: S5 Rtc Wake Settings Menu
Press <+> and <-> to define the wake up hour. » Wake up minute (Note) Press <+> and <-> to define the wake up minute. » Wake up second (Note) Press <+> and <-> to define the wake up second. www.gigaipc.com... -
Page 61: Csm Support
Please note that this item is visible when CSM Support is set to Disabled. » Storage Controls the execution of UEFI and Legacy Storage Option ROM. Options available: Do not launch/UEFI/Legacy setting is Disabled. Please note that this item is visible when CSM Support is set to Disabled. www.gigaipc.com... -
Page 62: Digital Io Port Configuration Menu
» SOGPO_1 / 2 / 3 / 4 Set the GPIO port as Input or output. Options available: Input / Output Default setting is Output. » Select Level Select Output Level High or Low. Options available: High / Low Default setting is High. www.gigaipc.com... -
Page 63: Chipset Menu
Default setting is Enabled. » DVMT Pre-Allocated Select DVMT 5.0 Pre-Allocated (Fixed) Graphics Memory size used by the Internal Graphics Device. Options available: 32M/64M/128M/256M. Default setting is 64M. » Onboard Audio Enable/Disable onboard audio controller. Options available: Enabled/Disabled. Default setting is Enabled. www.gigaipc.com... - Page 64 Default setting is Power Off. » WatchDog Timer Force system reboot if system gang up by memory detection fail. This option provides user to set watchdog timer as default. Options available: Disabled / 15s / 30s / 60s Default setting is Disabled. www.gigaipc.com...
-
Page 65: Security Menu
A user can only access and modify the System Time, System Date, and Set User Password fields. » Administrator Password Press Enter to configure the Administrator password. » User Password Press Enter to configure the user password. » Secure Boot menu Press [Enter] for configuration of advanced items. www.gigaipc.com... -
Page 66: Secure Boot Menu
This way, the system knows all the files being loaded before Windows 8 loads and gets to the login screen have not been tampered with. Options available: Enabled/Disabled. Default setting is Disabled. www.gigaipc.com... -
Page 67: 4.4.1.1 Key Management Menu
Please note that this item is configurable when Secure Boot Mode is set to Custom » Key Management Press [Enter] for configuration of advanced items. Please note that this item is configurable when Secure Boot Mode is set to Custom. 4.4.1.1 Key Management Menu www.gigaipc.com... - Page 68 Press [Enter] to restore all DB variables to factory defaults. Secure Boot variable Displays the current status of the variables used for secure boot. » Platform Key (PK) Displays the current status of the Platform Key (PK). Press [Enter] to enroll the PK. Options available: Update www.gigaipc.com...
- Page 69 Press [Enter] to enroll a new DBT or load additional DBT from storage devices. Options available: Update/Append. » OsRecovery Signatures Displays the current status of the OsRecovery Signature Database. Press [Enter] to enroll a new OsRecovery Signature or load additional OsRecovery Signature from storage devices. Options available: Update/Append. www.gigaipc.com...
-
Page 70: Boot Menu
» Boot Option #1 Press [Enter] to configure the boot priority. It allows you to specify the boot device priority from the available UEFI applications during system boot-up. Options available: UEFI: Built-in EFI Shell/Disabled. Default setting is UEFI: Built-in EFI Shell. www.gigaipc.com... -
Page 71: Save & Exit Menu
Highlight any of the exit options then press Enter. » Save Options » Save Changes and Reset Restarts the system after saving the changes made. Options available: Yes/No. Discard Changes and Reset Restarts the system without saving any changes. Options available: Yes/No. www.gigaipc.com... - Page 72 If you are using low-speed memory chips or other kinds of low- performance components and you choose to load these settings, the system might not function properly. Options available: Yes/No. » Me FW Image Re-Flash Enable/Disable Me FW Image Re-Flash function. Options available: Enabled/Disabled. Default setting is Disabled. www.gigaipc.com...
