Page 1: Sbc Boards
QBiP-1185G7EB/ QBiP-1145G7EB 3.5” SBC Boards User’s Manual 1st Ed www.gigaipc.com... -
Page 2: Copyright Notice
While reasonable efforts have been made in the preparation of this document to assure its accuracy, GIGAIPC assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. -
Page 3: Acknowledgement
Core, Atom are trademarks of Intel Corporation • • ITE is a trademark of Integrated Technology Express, Inc. IBM, PC/AT, PS/2, and VGA are trademarks of International Business • Machines Corporation. All other product names or trademarks are properties of their respective owners. www.gigaipc.com... -
Page 4: Packing List
Before setting up your product, please make sure the following items have been shipped: Item Quantity QBiP-1185G7EB/ QBiP-1145G7EB MB SATA power cable If any of these items are missing or damaged, please contact your distributor or sales representative immediately. www.gigaipc.com... -
Page 5: About This Document
(if any), its specifications, dimensions, jumper/ connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the GIGAIPC.com for the latest version of this document. www.gigaipc.com... -
Page 6: Safety Precautions
Make sure the device is installed near a power outlet and is easily accessible. 10. Keep this device away from humidity. 11. Place the device on a solid surface during installation to prevent falls 12. Do not cover the openings on the device to ensure optimal heat dissipation. www.gigaipc.com... - Page 7 18. D O N O T L E AV E T H I S D E V I C E I N A N U N C O N T R O L L E D ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO PREVENT DAMAGE. www.gigaipc.com...
-
Page 8: Fcc Statement
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte. Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le constructeur. Recycler les batteries usées en accord avec les instructions du fabricant et les directives gouvernementales de recyclage. www.gigaipc.com... -
Page 9: China Rohs Requirements (Cn)
China RoHS Requirements (CN) 产品中有毒有害物质或元素名称及含量 GIGAIPC Main Board/ Daughter Board/ Backplane 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷电路板 及其电 ○ ○ ○ ○ ○ ○ 子组件 外部信号 连接器 ○ ○ ○ ○... -
Page 10: China Rohs Requirement (En)
China RoHS Requirement (EN) Poisonous or Hazardous Substances or Elements in Products GIGAIPC Main Board/ Daughter Board/ Backplane Poisonous or Hazardous Substances or Elements Component Hexavalent Polybrominated Polybrominated Lead Mercury Cadmium Chromium Biphenyls Diphenyl Ethers (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) PCB &... -
Page 11: Table Of Contents
AT_CN (AT/ATX mode select jumper) ......25 2.2.5 JCOM1 (COM1 RI# pin RI#/5V/12V Select) ....26 2.2.6 SATA0 (SATA 6Gb/s connector) ........27 2.2.7 SATAPW0 (SATA power connector) ....... 28 2.2.8 COM2, COM3, COM4 (Serial port header, ....29 RS-232/422/485) ............29 www.gigaipc.com... - Page 12 2.2.24 TPM (Trusted Platform Module Connector) ....45 Chapter 3 – BIOS Introduction ..............47 The Main Menu............. 48 Advanced ..............49 3.3.1.1 Advanced menu items for QBiP-1185G7EB ....49 3.3.1.2 Advanced menu items for QBiP-1145G7EB ....49 3.3.2 AMT Configuration ............50 3.3.3 TPM Configuration ............
- Page 13 3.3.4 SATA And RST Configuration ......... 58 3.3.5 CPU Configuration ............59 3.3.5.1 CPU Configuration items for QBiP-1185G7EB....59 3.3.5.2 CPU Configuration items for QBiP-1145G7EB ....60 3.3.6 IT8786 Super IO Configuration ........62 3.3.7 Hardware Monitor ............63 3.3.8 S5 RTC Wake Settings ...........
-
Page 14: Chapter 1 - Product Specifications
Chapter 1 Chapter 1 - Product Specifications www.gigaipc.com... - Page 15 3.18 95.2 101.7 www.gigaipc.com...
-
Page 16: Specifications
Specifications QBiP-1185G7EB QBiP-1145G7EB Motherboard 3.5’’ SBC Form Factor 146W x 101.7D (mm) Intel® Core™ i7-1185G7E Intel® Core™ i5-1145G7E Processor Processor 10nm SuperFin, 4 cores, 10nm SuperFin, 4 cores, 8 threads, up to 4.4 GHz, 8 threads, up to 4.1 GHz,... - Page 17 QBiP-1185G7EB QBiP-1145G7EB Motherboard 1 x 4-pin box power connector (DC in +9V ~ 48VDC) 1 x SATA Power header 1 x CPU fan header 1 x System fan header 1 x Front panel header 1 x Front panel audio header...
-
Page 18: Chapter 2 - Hardware Information
Chapter 2 Chapter 2 – Hardware Information www.gigaipc.com... -
Page 19: Jumpers And Connectors
Jumpers and Connectors www.gigaipc.com... - Page 20 DC IN 1x4 pin power connector SYS_PANEL Front panel header GPIO_CNT General purpose input / ouput header FP_AUDIO Front Audio connector PCIEX1 PCIe Gen3 x1 connector ME Enable jumper SPK_OUT Speaker out connector BKL_CN Backlight Control header LVDS LVDS connector LVDS resolution jumper www.gigaipc.com...
- Page 21 Code Description M.2 Slot, SATA/PCIex2, NGFF 2280 SODIMM1 DDR4 SO-DIMM Slot SODIMM2 Trusted Platform Module connector USB31_1 USB 3.2 Gen 2x1 connector USB31_2 HDMI_21 HDMI connector LAN1, LAN2 LAN connector COM1 Serial Port (RS-232/422/485 & RI/5V/12V) www.gigaipc.com...
-
Page 22: Sys_Fan (System Fan Connector)
2.2.1 SYS_FAN (System fan connector) Pin 1 System fan Connector Connector PN Vendor 85205-0470N ACES A1250WV-S-04PC JOINT-TECH Pin No. Definition Detect Speed control www.gigaipc.com... -
Page 23: Cpu_Fan (Cpu Fan Connector)
2.2.2 CPU_FAN (CPU fan connector) Pin 1 CPU fan Connector Connector PN Vendor 85205-0470N ACES A1250WV-S-04PC JOINT-TECH Pin No. Definition Detect Speed control www.gigaipc.com... -
Page 24: Fusb1, Fusb2 (Usb 2.0 Headers)
2.2.3 FUSB1, FUSB2 (USB 2.0 headers) Pin 1 USB 2.0 Header Connector PN Vendor 210-92-05GB04 PINREX PH10R53BAZ009 HORNGTONG Pin No. Definition No Pin No Connect www.gigaipc.com... -
Page 25: At_Cn (At/Atx Mode Select Jumper)
AT_CN (AT/ATX mode select jumper) Pin 1 AT/ATX mode select jumper Connector PN Vendor 220-96-03GB01 PINREX HORNGTONG PH03N2 7BAN000 Pin No. Definition AT MODE TXD5 ATX MODE Jumper setting 1-2 Close : AT mode. 2-3 Close : ATX mode.(Default setting) www.gigaipc.com... -
Page 26: Jcom1 (Com1 Ri# Pin Ri#/5V/12V Select)
2.2.5 JCOM1 (COM1 RI# pin RI#/5V/12V Select) Pin 1 JCOM1 Jumper Select Connector PN Vendor 220-97-03GB01 PINREX 1-2 Close: 5V (Power COM) PH06N53BAZ000 HORNGTONG 3-4 Close: RI (Stand COM) (Default-Setting) 5-6 Close: 12V (Power COM) www.gigaipc.com... -
Page 27: Sata0 (Sata 6Gb/S Connector)
2.2.6 SATA0 (SATA 6Gb/s connector) SATA Connector Connector PN Vendor WATF-07DBLBA1UW WINWIN Pin No. Definition www.gigaipc.com... -
Page 28: Satapw0 (Sata Power Connector)
2.2.7 SATAPW0 (SATA power connector) Pin 1 Hard Disk Power Connector Connector PN Vendor 743-81-04TW00 PINREX WF04Q2-3BJQ000 HORNGTONG Pin No. Definition www.gigaipc.com... -
Page 29: Com2, Com3, Com4
Serial Port Cable Connector Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH RS-232 RS-422 RS-485 Full Duplex Half Duplex TXD+ TXD- RXD- — RXD+ — — — — — — — — — No Connect — — RI/5V/12V — — www.gigaipc.com... -
Page 30: M2E (M.2 Slot, E-Key, Ngff2230, Wifi & Bluetooth Module)
M.2 E Key Connector WLAN_RXp WLAN_RXn CLK_Dp CLK_Dn SUSCLK Pin No. Definition Pin No. Definition CLK_REQ PCIE_RST PCIE_WAKE BT_Disable# USB_D+ WLAN_ USB_D- DISABLE Pin No. Definition Pin No. Definition Connector PN Vendor APCI0095-P002A LOTES WLAN_TXp 80152-8521 BELLWETHER WLAN_TXn www.gigaipc.com... -
Page 31: Mpcie (Mini Pcie Full Size, Support 3G/4G Module)
Pin No. Definition Pin No. Definition 3.3V PCIE WAKE 3.3V 3.3V PCIE Clock Request SIM PWR SIM DATA PCIE Clock n SIM Clock PCIE Clock p SIM Reset 3.3V UIM VPP3 Connector PN Vendor AS0B221-S99Q-7H FOXCONN WLAN_ DISABLE Reset www.gigaipc.com... -
Page 32: Battery (Battery Cable Connector)
2.2.11 BATTERY (Battery cable Connector) Pin 1 Battery cable Connector Connector PN Vendor 85205-0270L ACES A1250WV-S-02PC JOINT-TECH Pin No. Definition 3.3V www.gigaipc.com... -
Page 33: Dc_In (Dc In 1X4 Pin Power Connector)
2.2.12 DC_IN (DC IN 1x4 pin power connector) Pin 1 DC IN connector Connector PN Vendor 753-81-04TW00 PINREX 1 2 34 Pin No. Definition Power Power www.gigaipc.com... -
Page 34: Sys_Panel (Front Panel Header)
2.2.13 SYS_PANEL (Front panel header) Pin 1 System Panel Header Connector PN Vendor 210-92-05G111 PINREX Pin No. Definition HDD LED+ Power LED+ HDD LED- Power LED- Power Button+ Reset Button Power Button- No Connect No Pin www.gigaipc.com... -
Page 35: Gpio_Cnt (General Purpose Input/Output Header)
2.2.14 GPIO_CNT (General Purpose input/output header) Pin 1 GPIO Connector Pin No. Definition SMBus DATA Connector PN Vendor Pin No. Definition 725-81-12TW00 PINREX GPIO-output_1 A2004WV-2X06P46 JOINT-TECH GPIO-input_1 GPIO-output_2 GPIO-input_2 GPIO-output_3 GPIO-input_3 GPIO-output_4 GPIO-input_4 SMBus Clock www.gigaipc.com... -
Page 36: Fp_Audio (Front Audio Connector)
2.2.15 FP_AUDIO (Front Audio connector) Pin 1 Front Audio Connector Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Definition Pin Definition MIC_L MIC_JD FAUDIO_JD MIC_R No Connect Detect HPOUT_L HPOUT_R www.gigaipc.com... -
Page 37: Pciex1 (Pcie Gen3 X1 Connector)
2.2.16 PCIEX1 (PCIe Gen3 x1 connector) Pin 1 PCIe Gen3 x1 Connector Connector PN Vendor 115B20-100020-G4-R STARCONN Pin No. Definition Pin No. Definition SRC_DP SMDATA SRC_DN CLK_REQ# PLTRST# PEWAKE# SLP_S3# +V12A +V12A SMCLK +V12A www.gigaipc.com... -
Page 38: Me (Me Enable Jumper)
2.2.17 ME (ME Enable jumper) ME Enable Connector Connector PN Vendor 220-96-02GB01 PINREX ME Enable jumper Default Enable www.gigaipc.com... -
Page 39: Spk_Out (Speaker Out Connector)
2.2.18 SPK_OUT (Speaker out connector) Pin 1 Audio Amplifie Connector Connector PN Vendor 721-81-045W00 PINREX A2001WV-04P146 JOINT-TECH Pin No. Definition Speaker Out L+ Speaker Out L- Speaker Out R- Speaker Out R+ www.gigaipc.com... -
Page 40: Bkl_Cn (Backlight Control Header)
2.2.19 BKL_CN (Backlight Control header) Pin 1 Backlight Control connector Connector PN Vendor 721-81-05TW00 PINREX A2001WV-05P146 JOINT-TECH Pin No. Definition Back Light Enable www.gigaipc.com... -
Page 41: Lvds (Lvds Connector)
But below model no need to add. A0~A3 is odd channel 0~3, A4~A7 is even channel. Note: *The LVDS output connector of the unit is only intended to be connected to an UL/IEC/EN CLK2+ approval equipment with fire enclosure. CLK1+ CLK2- www.gigaipc.com... -
Page 42: Lsw (Lvds Resolution Jumper)
1024 x 600 1600 x 900 18bit 24bit 1280 x 800 1680 x 1050 18bit 24bit 1024 x 600 1600 x 1200 18bit 24bit 1280 x 1024 1920 x 1080 24bit 24bit 1366 x 768 1920 x 1200 18bit 24bit www.gigaipc.com... -
Page 43: M2M (M.2 Slot, Sata/Pciex2, Ngff 2280)
Pin No. Definition Pin No. Definition 3.3V SATA_TXn 3.3V SATA_TXp PLT_RST CK_REQ CLK_n PCIE_WAKE# M2_LED CLK_p 3.3V 3.3V Pin No. Definition Pin No. Definition 3.3V SUSCLK 3.3V M2_SSD_ 3.3V Detect 3.3V 3.3V PCIE_RXn Connector PN Vendor PCIE_RXp 2E0BC41-C85CM-LH FOXCONN www.gigaipc.com... -
Page 44: Sodimm1, Sodimm2 (Ddr4 So-Dimm Slot)
2.2.23 SODIMM1, SODIMM2 (DDR4 SO-DIMM Slot) www.gigaipc.com... -
Page 45: Tpm (Trusted Platform Module Connector)
2.2.24 TPM (Trusted Platform Module Connector) Pin 1 TPM Module Connector Connector PN Vendor 87216-1004-06 ACES Pin No. Definition TPM_CLK SPI_CS#2 TPM_SO TPM_RST# TPM_SI +V3.3A www.gigaipc.com... -
Page 46: Chapter 3 - Bios
Chapter 3 Chapter 3 – BIOS www.gigaipc.com... -
Page 47: Introduction
Execute command or enter the submenu Increase the numeric value or make ＋ changes Decrease the numeric value or make – changes General Help Previous Values Load Optimized Defaults Settings Save changes & Exit the BIOS Setup program Exit the BIOS Setup program www.gigaipc.com... -
Page 48: The Main Menu
ME FW version Shows ME firmware version Set the Date for the system System Date (Format : Week - Month - Day - Year) Set the time for the system System Time (Format : Hour - Minute - Second) www.gigaipc.com... -
Page 49: Advanced
The Advanced menu is to configure the functions of hardware settings through submenu. Use arrow keys to move among the items, and press <Enter> to access into the related submenu. 3.3.1.1 Advanced menu items for QBiP-1185G7EB 3.3.1.2 Advanced menu items for QBiP-1145G7EB www.gigaipc.com... -
Page 50: Amt Configuration
AMT Disabled : Disables USB Provisioning of AMT Enabled : Enables USB Provisioning of AMT (Default setting) Disabled : Disables MAC Pass Through function MAC Pass (Default setting) Through Enabled : Enables MAC Pass Through function www.gigaipc.com... - Page 51 CIRA Configuration Item Description Trigger CIRA boot Activate Remote Disabled : Disables TPM feature (Default setting) Assistance Process Enabled : Enables TPM feature www.gigaipc.com...
- Page 52 Disabled : Disables watchdog Timer (Default setting) Enabled : Enables watchdog Timer OS Timer Sets OS Watchdog Timer. BIOS Timer Sets BIOS Timer. ASF Sensors Disabled : Disables ASF Sensors Table (Default setting) Table Enabled : Enables ASF Sensors Table www.gigaipc.com...
- Page 53 Simulated : Performs SE flow without erasing SSD Secure Erase mode (Default setting) Real : Erase SSD Force Secure Erase on next boot. Force Secure Erase Disabled : Disables Force Secure Erase (Default setting) Enabled : Enables Force Secure Erase www.gigaipc.com...
- Page 54 Disabled : Disables MEBx OEM Debug Menu Enable Debug Menu (Default setting) Enable Enabled : Enables MEBx OEM Debug Menu Enable To Un-configure ME without password. Unconfigure ME Disabled : Disables Unconfigure ME (Default setting) Enabled : Enables Unconfigure ME www.gigaipc.com...
- Page 55 Option items : Auto (Default setting), 80x25, 100x31 Resolution for UI text mode. UI Mode Resolution Option items : Auto (Default setting), 80x25, 100x31 Resolution for graphics mode. Graphics Mode Option items : Auto (Default setting), 640x480, 800x600, Resolution 1024x768 www.gigaipc.com...
-
Page 56: Tpm Configuration
3.3.3 TPM Configuration Use TPM Configuration submenu to choose TPM interface. Item Description PTT : Internal TPM (Default setting) TPM Device dTPM : External TPM (When using External TPM module or Selection having TPM chip on MB) www.gigaipc.com... - Page 57 Item Description Security Device Enabled : Enables TPM feature (Default setting) support Disabled : Disables TPM feature Item Description None : No execution will be conducted (Default setting) Pending operation TPM clear : Set to clear data on TPM www.gigaipc.com...
-
Page 58: Sata And Rst Configuration
Intel VMD feature helps you to control and manage NVMe PCIe SSD. / Enable VMD Enabled : Enables Intel VMD feature controller Disabled : Disables Intel VMD feature (Default setting) Serial ATA Port 0 shows 2.5" SATA HDD/SSD information shows M.2 SATA interface SSD information www.gigaipc.com... -
Page 59: Cpu Configuration
3.3.5 CPU Configuration This submenu shows detailed CPU informations. 3.3.5.1 CPU Configuration items for QBiP-1185G7EB Item Description Virtualization enhanced by Intel® Virtualization Technology will allow a platform to run Intel (VMX) multiple operating systems and applications in independent partitions. With virtualization, Virtualization one computer system can function as multiple virtual systems. -
Page 60: 3.3.5.2 Cpu Configuration Items For Qbip-1145G7Eb
When Intel Trusted Execution Technology Enables, this item could be adjusted. When Intel Trusted Execution Technology Disables : Reset AUX Content yes : agree to reset TPM Aux content. no : disagree to reset TPM Aux content. (Default setting) www.gigaipc.com... - Page 61 Disabled : Disables C states To speed up CPU frequency transition time from basic frequency to maximum frequency. Intel(R) Speed Shift Enabled : Enables Intel(R) Speed Shift Technology Interrupt control (Default setting) Technology Disabled : Disables Intel(R) Speed Shift Technology Interrupt control www.gigaipc.com...
-
Page 62: It8786 Super Io Configuration
Disabled : if Disabled, displays no configuration for the serial port Configuration Serial Port 3 Device settings : Configuration Display the specified Serial Port base I/O address and IRQ Serial Port 4 COM Port Mode : Configuration Choose RS-232, RS-422, or RS-485 feature www.gigaipc.com... -
Page 63: Hardware Monitor
Normal : Fan speed set by BIOS default (Default setting) Control Full Speed : Set Fan operates at full speed CPU Temperature Shows current CPU temperature System Temperature Shows current system temperature CPU Fan Speed Shows current CPU fan Speed SYS Fan Speed Shows current System fan Speed www.gigaipc.com... -
Page 64: S5 Rtc Wake Settings
Enable or Disable System to wake on a specific time. Wake system Disabled : Disables system to wake on a specific time (Default setting) from S5 Fixed Time : Enables system to wake on a specific time (Format : hr : min : sec) www.gigaipc.com... -
Page 65: Serial Port Console Redirection
Flow Control : None (Default setting), Hardware RTS/CTS VT-UTF8 Combo Key Support : Disableds, Enabled (Default setting) Recorder Mode : Disabled (Default setting), Enabled Resolution 100x31 : Disabled (Default setting), Enabled Putty KeyPad : VT100 (Default setting), LINUX, XTERMR6, SCO, ESCN, VT400 www.gigaipc.com... - Page 66 Item Description Legacy Console Redirection Settings : Redirection COM Port : COM0 (Default setting), COM1 (Pci, Bus0, Dev0, Legacy Console Func0) (Disabled) Redirection Resolution : 80x24 (Default setting), 80x25 Redirect After POST : Always Enable (Default setting), BootLoader www.gigaipc.com...
- Page 67 Out-of-Band Mgmt Port : COM0 (Default setting), COM1 (Pci, Bus0, Dev0, Emergency Func0) (Disabled) Management Terminal Type EMS : VT100, VT100+, VT-UTF8 (Default setting), ANSI Services (EMS) Bits per second EMS : 9600, 19200, 57600, 115200 (Default setting) Flow Control EMS : None (Default setting), Hardware RTS/CTS, Software Xon/Xoff www.gigaipc.com...
-
Page 68: Intel Txt Information (For Model Qbip-1145G7Eb Only)
3.3.10 Intel TXT Information (For Model QBiP-1145G7EB only) This submenu shows detailed Intel TXT informations. www.gigaipc.com... -
Page 69: Network Stack Configuration
When Network stack is enabled : Ipv4 PXE Support Disabled : Disables Ipv4 PXE Support Enabled : Enables Ipv4 PXE Support When Network stack is enabled : Ipv6 PXE Support Disabled : Disables Ipv6 PXE Support Enabled : Enables Ipv6 PXE Support www.gigaipc.com... -
Page 70: Nvme Configuration
3.3.12 NVMe Configuration NVMe Configuration shows information when your M.2 NVMe PCIe SSD is installed. www.gigaipc.com... -
Page 71: Offboard Sata Controller Configuration
3.3.13 Offboard SATA Controller Configuration www.gigaipc.com... -
Page 72: Digital Io Port Configuration
Enabled : If Digital IO Output value/level is modified in OS, they will be memorized and kept. SOGPO_1 (Pin 1) SOGPI_1 (Pin 2) SOGPO_2 (Pin 3) SOGPI_2 (Pin 4) Configure Digital IO Input or Output values for each pin. SOGPO_3 (Pin 5) SOGPI_3 (Pin 6) SOGPO_4 (Pin 7) SOGPI_4 (Pin 8) www.gigaipc.com... -
Page 73: Chipset
Enable/Disable Watchdog Timer function Watchdog Timer Enabled : Enables Watchdog Timer function Disabled : Disabled Watchdog Timer function (Default setting) Enable/Disable BIOS Lock function BIOS Lock Enabled : Enables BIOS Lock function (Default setting) Disabled : Disabled BIOS Lock funtion www.gigaipc.com... -
Page 74: Security
To set up Administrator's password Administrator Minimum length : 3 Password Maximum length : 20 To set up User's password User Password Minimum length : 3 Maximum length : 20 Secure Boot Press <Enter> to configure the advanced items www.gigaipc.com... - Page 75 No : Cancel to restore factory settings Reset To Setup Yes : Agree to setup mode Mode No : Cancel to setup mode Enables expert users to modify Secure boot policy variables without full Key Management authentication Press <Enter> to configure the advanced items www.gigaipc.com...
- Page 76 Boot mode Signatures Remove 'UEFI CA' To remove 'UEFI CA' from database from DB Restore DB variables to fac tor y Restore DB defaults defaults Yes : Agree to restore DB defaults No : Cancel to restore DB defaults www.gigaipc.com...
-
Page 77: Boot
Enabled : Enables Full screen LOGO Show on POST screen LOGO Show Disabled : Disables Full screen LOGO Show on POST screen (Default setting) Shows the information of the storage that be installed in the system Boot Option #1 Choose/set the boot priority www.gigaipc.com... -
Page 78: Save & Exit
Yes : Agree to load optimized defaults No : Cancel to load optimized defaults Enable/Disable Me FW image re-flash function Me FW Image Enabled : Enables Me FW image re-flash function Re-Flash Disabled : Disables Me FW image re-flash function (Default setting) www.gigaipc.com...
