Grizzly GROWLTECH G0995 Owner's Manual

Grizzly GROWLTECH G0995 Owner's Manual

24-1/2" heavy-duty wood lathe
Hide thumbs

Advertisement

Quick Links

Download this manual
MODEL G0995
24-1/2" GROWLTECH
HEAVY-DUTY WOOD LATHE
OWNER'S MANUAL
(For models manufactured since 11/24)
COPYRIGHT © NOVEMBER, 2024 BY GRIZZLY INDUSTRIAL, INC.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
#KS23343 PRINTED IN CHINA
V1.11.24
***Keep for Future Reference***

Advertisement

loading
Need help?

Need help?

Do you have a question about the GROWLTECH G0995 and is the answer not in the manual?

Questions and answers

Related Manuals for Grizzly GROWLTECH G0995

Summary of Contents for Grizzly GROWLTECH G0995

  • Page 1 (For models manufactured since 11/24) COPYRIGHT © NOVEMBER, 2024 BY GRIZZLY INDUSTRIAL, INC. WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC. #KS23343 PRINTED IN CHINA V1.11.24...
  • Page 2 This manual provides critical safety instructions on the proper setup, operation, maintenance, and service of this machine/tool. Save this document, refer to it often, and use it to instruct other operators. Failure to read, understand and follow the instructions in this manual may result in fire or serious personal injury—including amputation, electrocution, or death.

  • Page 3: Table Of Contents

    Table of Contents INTRODUCTION ..........2 SECTION 5: ACCESSORIES ......52 Contact Info ........... 2 SECTION 6: MAINTENANCE ......55 Manual Accuracy ........... 2 Schedule ............55 Identification ........... 3 Cleaning & Protecting ........55 Controls & Components ......... 4 Lubrication ...........

  • Page 4: Introduction

    ID label. This will help us help you faster. tions, specifications, drawings, and photographs in this manual. Sometimes we make mistakes, but Grizzly Technical Support our policy of continuous improvement also means 1815 W. Battlefield that sometimes the machine you receive is Springfield, MO 65807 slightly different than shown in the manual.

  • Page 5: Identification

    Identification Become familiar with the names and locations of the controls and features shown below to better understand the instructions in this manual. Spindle Lock Pin Chuck Guard Dust Hood Tool Rest Control Panel Tailstock Quill Spindle Handwheel Tool Holder Spindle Headstock Lock Arm...

  • Page 6: Controls & Components

    Controls & D. Control Panel: Controls machine operat- ing functions and indicates spindle speed in Components revolutions per minute (RPM). See Control Panel on Page 6 for detailed control descriptions, and Command Tree on Page 70 for programming functions. E. Chuck Guard: Protects operator from flying objects ejected during turning operations.

  • Page 7: Mounting Arms

    Tool Rest Swing-Away Bed & Bed Extension Figure 3. Tool rest controls. Tool Rest: Provides stable platform for cut- Figure 5. Swing-away bed and bed extension. ting tools. R. Swing-Away Bed: Swings around side of K. Tool Rest Lock Handle: Secures tool rest in bed to store tailstock during outboard turning position.

  • Page 8: Control Panel

    Control Panel Menu Figure 7. Control panel overview. A. F1–F4 Function Buttons: Programmable D. OFF Button: Turns motor OFF. buttons that provide shortcuts to spindle con- trols. By default, pressing buttons changes E. Menu Button: Displays menu and functions spindle speed according to the table below: as "Cancel/Back"...

  • Page 9: Machine Data Sheet

    MACHINE DATA SHEET Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901 MODEL G0995 24-1/2" GROWLTECH HEAVY-DUTY WOOD MODEL G0995 24-1/2" GROWLTECH LATHE HEAVY-DUTY WOOD LATHE Product Dimensions: Weight................................617 lbs. Width (side-to-side) x Depth (front-to-back) x Height................81 x 41 x 59 in. Footprint (Length x Width)........................
  • Page 10 Spindle Information Spindle Taper............................MT#2 Spindle Thread Size........................1-1/4" x 8 TPI Spindle Thread Direction........................Right Hand Spindle Bore............................11/16 in. Type of Included Spindle Center......................... Spur Indexed Spindle Increments........................15 deg. No of Indexes..............................24 Tool Rest Information Tool Rest Width............................14 in. Tool Rest Post Diameter..........................

  • Page 11: Section 1: Safety

    SECTION 1: SAFETY For Your Own Safety, Read Instruction Manual Before Operating This Machine The purpose of safety symbols is to attract your attention to possible hazardous conditions. This manual uses a series of symbols and signal words intended to convey the level of impor- tance of the safety messages.
  • Page 12 WEARING PROPER APPAREL. Do not wear FORCING MACHINERY. Do not force machine. loose clothing, gloves, neckties, or jewelry that It will do the job safer and better at the rate for can become entangled in moving parts. Always tie which it was designed. back or cover long hair.

  • Page 13: Additional Safety For Wood Lathes

    Additional Safety for Wood Lathes Serious injury or death can occur from getting entangled in, crushed between, or struck by rotating parts on a lathe! Rotating workpieces can come loose and strike operator or bystanders with deadly force if they are improperly secured, rotated too fast, or are not strong enough for the rotational forces required for turning.

  • Page 14: Section 2: Power Supply

    SECTION 2: POWER SUPPLY Availability Circuit Information Before installing the machine, consider the avail- A power supply circuit includes all electrical ability and proximity of the required power supply equipment between the breaker box or fuse panel circuit. If an existing circuit does not meet the in the building and the machine.

  • Page 15: Grounding Requirements

    Grounding Requirements This machine MUST be grounded. In the event of certain malfunctions or breakdowns, grounding Serious injury could occur if you connect reduces the risk of electric shock by providing a machine to power before completing setup path of least resistance for electric current. process.

  • Page 16: Section 3: Setup

    IMPORTANT: Save all packaging materials until you are completely satisfied with the machine and have resolved any issues between Grizzly or the shipping agent. You MUST have the original pack- aging to file a freight claim. It is also extremely helpful if you need to return your machine later.

  • Page 17: Inventory

    Inventory The following is a list of items shipped with your machine. Before beginning setup, lay these items out and inventory them. If any non-proprietary parts are missing (e.g. a nut or a washer), we will gladly replace them; or for the sake of expediency, replacements can be obtained at your local hardware store.

  • Page 18: Hardware Recognition Chart

    Hardware Recognition Chart USE THIS CHART TO MATCH UP HARDWARE DURING THE INVENTORY AND ASSEMBLY PROCESS. Flat Head Screw -16- Model G0995 (Mfd. Since 11/24)

  • Page 19: Cleanup

    Coat the rust preventative with a liberal amount of cleaner/degreaser, then let it soak for 5–10 minutes. Order online at www.grizzly.com Wipe off the surfaces. If your cleaner/degreas- er is effective, the rust preventative will wipe Call 1-800-523-4777 off easily. If you have a plastic paint scraper, scrape off as much as you can first, then wipe off the rest with the rag.

  • Page 20: Site Considerations

    Site Considerations Weight Load Physical Environment Refer to the Machine Data Sheet for the weight The physical environment where the machine is of your machine. Make sure that the surface upon operated is important for safe operation and lon- which the machine is placed will bear the weight gevity of machine components.

  • Page 21: Anchoring To Floor

    Anchoring to Floor Lifting & Placing Number of Mounting Holes ......4 Diameter of Mounting Hardware ....⁄ " HEAVY LIFT! Anchoring machinery to the floor prevents tipping Straining or crushing injury or shifting and reduces vibration that may occur may occur from improperly during operation, resulting in a machine that runs lifting machine or some of...
  • Page 22 Loosen tool rest base lock lever and remove tool rest base from bed. Loosen tailstock lock lever and remove tailstock from bed. Move headstock to center of bed (see Adjusting Headstock on Page 30), then lock it in place (see Figure 14). ⁄...

  • Page 23: Assembly

    Assembly — If anchoring machine to floor, remove lifting equipment, then anchor machine as shown in Anchoring to Floor on Page 19. Proceed to Assembly once machine is anchored. — If installing adjustable feet, proceed to HEAVY LIFT! Step 12. Straining or crushing injury may occur from improperly 12.
  • Page 24 Loosen tailstock lock lever (see Adjusting Remove lower lock lever and flat washer, Tailstock on Page 32). loosen upper lock lever, then insert chuck guard through headstock mounting arm (see Install tailstock on bed by aligning clamp Figure 22). plate with bedway. Verify tailstock slides smoothly along bedway, then tighten lock Install lower lock lever and flat washer (see lever to secure (see Figure 20).
  • Page 25 11. Fully loosen hose clamp and insert through 16. Loosen tailstock mounting arm lock lever and clamp mount, then tighten hose clamp a few install extension rod with thin end towards turns to reconnect (see Figure 24). headstock, then tighten lock lever to secure (see Figure 26).
  • Page 26 20. Loosen swing-away bed wing knob (see 23. Hand thread (4) M10-1.5 x 30 cap screws Figure 28) to unlock and release swing-away halfway in bed extension mounting holes on bed. left stand leg (see Figure 30). Note: Holes on bed extension are elongated and provide enough clearance to install exten- sion without having to completely remove cap screws in mounting holes.

  • Page 27: Installing Storage Shelves

    Installing Storage Shelves Plywood Board The leg castings on the Model G0995 feature mounting brackets that provide support for a vari- ety of shelving options. 2x4 (1 of 2) Shelving Option One Figure 33. Boards installed and secured. Items Needed 2x6s 51"...

  • Page 28: Test Run

    Test Run Connect machine to power by inserting power cord plug into a matching receptacle. Place foot switch in an easily accessible area Once assembly is complete, test run the machine near control panel. to ensure it is properly connected to power and safety components are functioning correctly.

  • Page 29: Ready To Run

    Press any control panel button to clear 10. Verify spindle speed dial is operating cor- BRAKING ENABLED warning. rectly by slowly turning dial clockwise and counterclockwise. — Display will show home screen, as shown — Rotate spindle speed dial clockwise to in Figure 37.
  • Page 30 — If motor does not start, safety feature of 14. Press ON button again to confirm direction change, then press and hold foot switch foot switch control is working correctly. down to turn spindle motor ON and begin Proceed to Step 17. spindle rotation.

  • Page 31: Section 4: Operations

    Read books/magazines or get formal training before beginning any proj- ects. Regardless of the content in this sec- tion, Grizzly Industrial will not be held liable for accidents caused by lack of training. -29- Model G0995 (Mfd. Since 11/24)

  • Page 32: Workpiece Inspection

    Workpiece Inspection Adjusting Headstock Some workpieces are not safe to turn or may The headstock on this lathe is equipped with a require modification before they are safe to turn. cam-action clamping system to secure it to the lathe bed. When the lever is tightened, a locking Before turning, inspect all workpieces for the plate lifts up underneath the bed and secures following:...
  • Page 33 Slide headstock to desired location on bed, and turn headstock lock bar clockwise to secure headstock in position. DO NOT place hands or fingers between bedways Note: Large clamping lock nut underneath when rotating headstock. headstock will require occasional adjusting Pinching or crushing inju- to ensure proper clamping pressure of the ries could occur.

  • Page 34: Adjusting Tailstock

    Adjusting Tailstock To adjust tailstock: Loosen tailstock lock lever and move tailstock to desired position (see Figure 47). The Model G0995 tailstock is equipped with a cam-action clamping system to secure it to the Note: For tailstock adjustments on swing- lathe bed.

  • Page 35: Using Tailstock Swing-Away Bed

    Using Tailstock Close and secure swing-away bed, then place a straightedge across both bedways Swing-Away Bed to check if they are flush. Adjust swing-away bed as needed. Note: This is a process of trial-and-error. Be The swing-away bed allows the tailstock to be patient and take your time when adjusting quickly moved away from the main bed.

  • Page 36: Adjusting Tool Rest

    Adjusting Tool Rest Improperly supported or positioned cutting tools can "catch" on workpiece, ejecting The tool rest assembly consists of two compo- tool from your hands with great force. To nents: the tool rest base (or banjo) and the tool reduce this risk, always ensure tool rest is rest.
  • Page 37 Rotate tool rest base lock lever until it feels Adjusting Tool Rest Height tight to secure tool rest base on bed. A tool rest collar is included to provide adjustment support when the tool rest base is installed on the Note: Large clamping plate and lock nut bed extension in the center mounting position.
  • Page 38 Loosen set screw on tool rest collar and Loosen set screw on tool rest extension and install over tool rest stem (see Figure 54). install extension stem, then tighten set screw to secure (see Figure 55). Loosen tool rest extension lock handle (see Figure 55).

  • Page 39: Installing/Removing Headstock Center

    Installing/Removing Make sure center is securely installed by attempting to pull it out by hand—a properly Headstock Center installed center will not pull out easily. Removing Headstock Center DISCONNECT MACHINE FROM POWER! The included spur center installs in the headstock spindle with an MT#2 tapered fit.

  • Page 40: Installing/Removing Tailstock Center

    Installing/Removing Firmly insert tapered end of center into tailstock quill (see Figure 60). Tailstock Center Verify quill set screw is aligned with quill key- way to ensure tailstock center and quill will not freely rotate under load (see Figure 60). Tailstock quill must always be locked in Quill Keyway place during lathe operation.

  • Page 41: Installing/Removing Faceplate

    Installing/Removing Rotate faceplate counterclockwise until it is removed. Faceplate Note: If spur center is installed, it will remain in place during this process. These instructions cover removing and installing Disengage spindle lock pin before resuming the faceplate. To mount a workpiece to your face- operations.

  • Page 42: Indexing

    Indexing Locking Index DISCONNECT MACHINE FROM POWER! Lift spindle lock pin until support pin sepa- rates from support hole (see Figure 64). Do not start spindle rotation with spindle lock pin in LOCKED position, or machine Support damage could occur. Hole Indexing on a lathe is typically used for workpiece Recessed...

  • Page 43: Adjusting Spindle Speed

    Adjusting Refer to the chart in Figure 67 to choose an appropriate RPM for your operation. Spindle Speed IMPORTANT: Recommended speeds should only be used as a guide and may not reflect variables required for safe operation. Turning Roughing Cutting Finishing Always use correct spindle speed for your Diameter...

  • Page 44: Spindle Turning

    Spindle Turning Press spindle speed dial to enter Select Cut Type submenu (see Figure 69). — Finish/Shape Cut: Setting for workpieces Spindle turning is the operation performed when that have already been rough cut and a workpiece is mounted between centers in the require shaping.
  • Page 45 Drive spur center into end center mark of To set up a spindle turning operation: workpiece with wood mallet to embed cen- Find center point of both ends of your ter at least ⁄ " into workpiece, as shown in workpiece by drawing diagonal lines from Figure 75.

  • Page 46: Spindle Turning Tips

    11. Properly adjust tool rest to workpiece (see Mounting Bed Extension for Spindle Adjusting Tool Rest on Page 34). Turning The Model G0995 includes a bed extension to 12. Rotate workpiece by hand to ensure there is extend spindle turning capacity of the main bed to safe clearance on all sides.

  • Page 47: Installing Comparator Kit

    Installing With help from an additional person, mount bed extension on (4) cap screws installed in Comparator Kit Step 2, then fully tighten cap screws. Place a straightedge across both bedways to check if they are flush and adjust bed exten- The Model G0995 comparator kit enables you to sion as needed.
  • Page 48 Remove chuck guard and set aside (see Insert (1) fixed center in tailstock mounting Figure 78 on Page 45). arm with pointed end facing headstock (see Figure 81). Note: Chuck guard cannot be used when comparator kit is installed. Mounting Arm Insert (1) fixed center in headstock mounting Lock Lever arm with pointed end facing tailstock (see...

  • Page 49: Faceplate Turning

    Faceplate Turning Faceplate turning is when a workpiece is mounted to the faceplate, which is then mounted to the headstock spindle, as shown in Figure 83. This type of turning is usually done with open-faced workpieces like bowls or plates. Figure 84.

  • Page 50: Outboard Turning

    Outboard Turning Mounting Workpiece on Backing Block Items Needed Piece of Scrap Wood......... 1 Precision Ruler ..........1 Power Drill ............1 ALWAYS use a tool rest on bed extension Drill Bit ⁄ " ............1 or a floor-mounted tool rest, and keep tool Glue ...........
  • Page 51 Remove (2) hex nuts, lock washers, and flat With help from an additional person, mount washers securing center mount cover, then bed extension on (4) cap screws installed in remove cover (see Figure 86). Step 3, then fully tighten cap screws. Remove bed stop on bed extension and install tool rest base, then re-install bed stop (see Figure 88).

  • Page 52: Sanding/Finishing

    Sanding/Finishing Removing Bed Extension DISCONNECT MACHINE FROM POWER! Loosen (4) M10-1.5 x 30 cap screws securing After the turning operations are complete, the bed extension (see Figure 89). Do not fully workpiece can be sanded and finished before remove cap screws at this time. removing it from the lathe (see Figure 90).

  • Page 53: Selecting Turning Tools

    Selecting Turning • Scrapers—Typically used where access for other tools is limited, such as hollowing oper- Tools ations. This is a flat, double-ground tool that comes in a variety of profiles (round nose, spear point, square nose, etc.) to match many different contours.

  • Page 54: Section 5: Accessories

    To reduce this risk, only install accessories for bowls, spindles, and hard-to-hold projects. recommended for this machine by Grizzly. T10810 Chuck diameter is 4 ⁄ " and includes an NOTICE indexed backplate with 24 positions.
  • Page 55 HP Portable Dust Collector This woodturning tool set is part of an exten- Designed to capture dust and wood chips from sive line of Grizzly PRO® turning tools, offering woodworking machines. The air drawn in by the cryogenically hardened steel blades, ergonomic dust collector is filtered by a 2.5 micron upper...
  • Page 56 T24515—8" Woodworking Caliper Set This stainless-steel tool rest set is part of an The double-ended calipers of the T24515 8" extensive line of Grizzly PRO® turning tools, Woodworking Caliper Set are necessary for gaug- offering durability and strength for smoother, more ing the wall thickness of turned bowls and mea- precise woodturning results.

  • Page 57: Section 6: Maintenance

    SECTION 6: MAINTENANCE Cleaning & Protecting To reduce risk of shock or accidental startup, always disconnect machine from power before adjustments, Cleaning the Model G0995 is relatively easy. maintenance, or service. Vacuum excess wood chips and sawdust, and wipe off the remaining dust with a dry cloth. If any resin has built up, use a resin dissolving cleaner Schedule to remove it.

  • Page 58: Lubrication

    Lubrication Preparing Machine for Storage Disconnect all power sources to machine. Thoroughly clean all unpainted, bare metal Since all bearings on the Model G0995 are sealed surfaces, then coat them with a lightweight and permanently lubricated, simply leave them grease or rust preventative. Take care to alone until they need to be replaced.

  • Page 59: Section 7: Service

    SECTION 7: SERVICE Review the troubleshooting procedures in this section if a problem develops with your machine. If you need replacement parts or additional help with a procedure, call our Technical Support. Note: Please gather the serial number and manufacture date of your machine before calling. Troubleshooting Motor &...
  • Page 60 Operations Symptom Possible Cause Possible Solution Poor surface 1. Dull tooling or wrong tool used for task. 1. Sharpen tooling, select correct tool for operation. finish quality. 2. Tool height is not correctly adjusted to ⁄ " 2. Adjust tool rest so tool is ⁄...

  • Page 61: Section 8: Wiring

    Technical Support at (570) 546-9663. The photos and diagrams included in this section are best viewed in color. You can view these pages in color at www.grizzly.com. -59- Model G0995 (Mfd. Since 11/24)

  • Page 62: Wiring Diagram

    Wiring Diagram CONTROL PANEL 6-20 Plug Circuit Board TTI 55446 Ground WARNING! SHOCK HAZARD! Disconnect power before working on wiring. EMERGENCY STOP JINHONG F16-A11 HEADSTOCK ACCESS PANEL HEADSTOCK MOTOR 220V Spindle Speed Sensor TTI 55020 Overload Protector L2 Series 15A ON/OFF Fuse Fuse...

  • Page 63: Section 9: Parts

    SECTION 9: PARTS We do our best to stock replacement parts when possible, but we cannot guarantee that all parts shown are available for purchase. Call (800) 523-4777 or visit www.grizzly.com/parts to check for availability. Main 36 37 77 78...

  • Page 64: Main Parts List

    PHLP HD SCR M4-.7 X 12 P0995108 FOOT SWITCH TTI KW3-0T P0995054 HEADSTOCK PIVOT PIN P0995109 HEADSTOCK FILTER P0995055 HEADSTOCK CLAMP BOLT P0995110 KNOCKOUT TOOL -62- BUY PARTS ONLINE AT GRIZZLY.COM! Model G0995 (Mfd. Since 11/24) Scan QR code to visit our Parts Store.
  • Page 65 LOCK BUSHING 16ID X 32OD X 30L P0995133 STRAIN RELIEF M20-1.5 P0995122 HOOD EXTENSION ROD P0995134 KEY W/HOLE 6 X 6 X 12 -63- BUY PARTS ONLINE AT GRIZZLY.COM! Model G0995 (Mfd. Since 11/24) Scan QR code to visit our Parts Store.

  • Page 66: Labels & Cosmetics

    Safety labels help reduce the risk of serious injury caused by machine hazards. If any label comes off or becomes unreadable, the owner of this machine MUST replace it in the original location before resuming operations. For replacements, contact (800) 523-4777 or www.grizzly.com. -64- BUY PARTS ONLINE AT GRIZZLY.COM!

  • Page 67: Section 10: Appendix

    SECTION 10: APPENDIX Advanced Machine Assisted Braking Operation The Model G0995 features power-assisted brak- Functions ing to help stop the spindle when operating with heavy or unbalanced workpieces. The Model G0995 has many customized machine To change assisted braking operation: functions that are easily accessed through the Press Menu button and use spindle speed control panel.
  • Page 68 Scroll down to Brake Pwr setting (see Figure Profile Settings 110) and press spindle speed dial to enter This lathe features performance settings tuned for Braking Power submenu (see Figure 111). different woodturning profiles. These settings are customized to accommodate the different operat- ing requirements of small, normal, extra-large, or Braking Power unbalanced workpieces.
  • Page 69 Finish Drying Mode Vibration Sensor Setting The Model G0995 includes a finish drying timer The vibration sensor automatically turns the spin- that will run the lathe at 50 RPM for an extended dle motor OFF when a potentially dangerous duration to help dry finished workpieces. vibration is detected.
  • Page 70 Press spindle speed dial and rotate to cycle Automatic Idle Shutdown Function through vibration sensor threshold settings, The automatic idle shutdown function will auto- as shown in Figure 119. matically turn the spindle motor OFF after four minutes of inactivity. —...

  • Page 71: New Password

    Password Lock Factory Reset The Model G0995 can be password protected to Perform a factory reset to return all digital lathe help prevent unauthorized use by untrained users. settings to default values. Note: The password setting can be cleared by IMPORTANT: Performing a factory reset will clear performing a factory reset of the machine.

  • Page 72: Command Tree

    This section is an overview of the menus and features used to control this machine. For instructions on navigating the interface and the basics of operation, refer to Controls & Components on Page 4. Since software changes can affect the user interface, check www.grizzly.com for an up-to-date command tree if this one seems out of date.
  • Page 73 Command Tree (Cont.) Menu To Page Lathe Settings Machine settings and parameters. Toggle display size between Large and Display Size Normal. Assisted Brake E-Stop Brake Enable or disable Brake Pwr power-assisted Vibr. Sensor braking feature. Idle=AutoStop Automatically turns lathe OFF when Vibr.

  • Page 75: Warranty & Returns

    WARRANTY & RETURNS Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of maintenance.
