Sealey TSTPG10.V2 Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS,
WARNINGS & CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT
IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE
WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Check your tyre pressures regularly. An under or over inflated tyre can add to your
‰
fuel consumption and cause additional wear. Both are dangerous.
DO NOT use this product for applications outside of its intended use.
8
Read and follow ALL instructions before use.
9
2. INTRODUCTION
Ergonomically designed lightweight tyre pressure gauge. One-button operation with LCD digital
display and Illuminated nozzle. Read-out available in bar, psi, kg/cm² or kPa. Range: 0-150psi(0-
10.3bar). Auto-power-off feature. Compact, can easily be stored in a glove box. Powered by 1 x
CR2032, 3 x LR44 batteries (supplied).
3. SPECIFICATION
MODEL NO:
Battery:
Operating Temperature:
Pressure Units:
Range:
Resolution:
4. OPERATION
4.1. MEASURING TYRE PRESSURE (FIG.1)
4.1.1. Press the ON/OFF button to turn the tyre pressure gauge on. The gauge will display "0.0" on the LCD screen.
4.1.2. Place the nozzle of the tyre pressure gauge on the tyre valve you wish to measure. Ensure a good seal to prevent air from escaping.
4.1.3. Hold the gauge on the valve until the measurement display locks.
4.1.4. Remove the gauge to easily read the pressure reading.
4.1.5. To change units press the button to change between the four available units (bar, PSI, kg/cm
4.1.6. The tyre pressure gauge will automatically turn off shortly after use. Alternatively, hold the ON/OFF button to turn off.
4.2. CHANGING THE BATTERY (FIG.2)
4.2.1. Remove the back cover using a screwdriver.
4.2.2. Remove the battery and replace with an equivalent. Ensure the battery is placed with the correct polarity.
4.2.3. Replace the back cover and screws.
© Jack Sealey Limited
DIGITAL TYRE PRESSURE GAUGE
TSTPG10.V2
MODEL NO:
TSTPG10.V2
1 x CR2032
3 x LR44 (supplied)
-5°C to 50°C
Bar, psi, kg/cm², kPa
0-10.3bar
0-150psi
0-10.5kg/cm²
0-1034kPa
0.1psi
BATTERY
FIG.2
Original Language Version
ON/OFF
BUTTON
FIG.1
, kPA)
2
TSTPG10.V2 Issue 2 (2) 21/03/24
