EcoFlow RIVER 2 Pro User Manual

Portable power station

Hide thumbs Also See for RIVER 2 Pro:

Quick start manual (37 pages)

User manual (128 pages)

User manual

page of 14

/ 14
Bookmarks

Quick Links

Download this manual

Contents

Overview

LCD Icons

Power On/Off

Charge Your Devices

AC Output Socket

USB-C/USB-A Output Port

DC Output Socket

Charge Your Power Station

X-Boost

EPS

Care and Maintenance

Specifications

EcoFlow App

What's in the Box

Accessories

FAQ

Safety Instructions

Certification and compliance

FAQ

EcoFlow App

Overview

USB-C port

USB-A port

Power indicator

Main power switch

After-sales

Policy

Powers up devices or charges the product with a

maximum input/output power of 100W

Powers up devices with a rated power ＜12W

Shows the working state of the product. Pulsing in

power-on or standby mode;

Short press to turn on the product, long press for 3

seconds to turn off the product

Community

Need help?

Do you have a question about the RIVER 2 Pro and is the answer not in the manual?

Questions and answers

Summary of Contents for EcoFlow RIVER 2 Pro

Page 1 Contents Overview LCD Icons EcoFlow App After-sales Community Policy Power On/Off Charge Your Devices AC Output Socket Overview USB-C/USB-A Output Port DC Output Socket Charge Your Power Station X-Boost Care and Maintenance Specifications EcoFlow App What's in the Box Accessories...
Page 2 AC output switch Short press once to turn on/off the AC output socket Supports X-Boost feature and powers up devices with AC output socket a rated power ＜800W DC output switch Short press once to turn on/off the DC output socket DC5521 output Powers up devices with a rated power ＜37W port...
Page 3 7 Bluetooth connection status 15 Overload Warning 8 Wi-Fi status Refer to "Troubleshooting" for details. Power On/Off Short press for power-on Press the main power button again to turn off the LCD screen. If the product is not used for 5 minutes, it will enter hibernation and the LCD screen will turn off.
Page 4 AC Output Socket Maximum output power 800W Press the AC output switch once to turn on AC output socket; press again to turn it off. USB-C/USB-A Output Port USB-A Output Port Maximum output power 12W The USB-A output ports are available once the product is turned on. USB-C Input/Output Port Maximum input/output power 100W The USB-C output port is available once the product is turned on.
Page 5 Maximum output power 37W Charge Your Power Station AC Charging Fully charged in 1.17 hours 940W max (low-voltage areas, 100V-120V) / 870W max (high-voltage areas, 220V-240V) Please use the AC charging cable included in the package and plug the cable directly into a wall outlet instead of an extension socket.
Page 6 You can recharge the product through the car power outlet. The product supports 12V/24V car chargers and a maximum charging current of 8A. EcoFlow takes no responsibility for any loss or damage caused by failure to follow instructions. To avoid failure to start due to insufficient car battery, use the car charger after the vehicle is started.
Page 7 ◎The USB-C charging cable (Type-C plug) and adapter are not included. X-Boost The product supports X-Boost. It can power devices rated at up to 1600W without incurring operation failure due to overload protection. Observe the following tips when using the X-Boost feature: 1.
Page 8 <1600W for high voltage areas and 1000W for low voltage areas) at a time and avoid using multiple appliances at the same time to avoid triggering overload protection. EcoFlow takes no responsibility for any device failure or data loss caused by failure to follow instructions.
Page 9 Approximately 8.25 kg (18.2 lbs) 270 × 260 × 226 mm Dimensions (10.6 × 10.2 × 8.9 inches) 768Wh, 40Ah⎓19.2V (RIVER 2 Pro) Capacity 716Wh, 37.3Ah⎓19.2V (RIVER 2 Pro 700) Frequency range: 20M: 2412-2462MHz/40M: 2422-2452MHz (US) 20M: 2412-2472MHz/40M: 2422-2462MHz Wi-Fi (2.4G)
Page 10 -10°C~45°C (optimal: 20°C~30°C) Storage 14°F to 113°F (optimal: 68°F to 86°F) EcoFlow App Control, monitor and customize your EcoFlow product from afar with the EcoFlow App. See how to connect → What's in the Box 1. RIVER 2 Pro/RIVER 2 Pro 700 portable power station 2.
Page 11 1. What devices can the product's AC output socket power? The rated power of the product is 500W and the peak power is 1000W. With the X-Boost feature, the product's AC output sockets can power devices rated at 1000W or below. It's recommended that you confirm the power of devices before use, and ensure that the sum power of all loaded devices is less than the rated power.
Page 12 If the refrigerator stores medicines, vaccines or other high-value items, it is highly recommended that you set the AC output to "Never Turn Off" through the EcoFlow app when connecting the power supply product to ensure a continuous power supply.
Page 13 Your retailer will accept used products and return them to an environmentally-sound recycling facility. Hereby, EcoFlow Inc. declares that the radio equipment type portable power station is in compliance with Directives 2014/53/EU, 2011/65/EU(RoHS), (EU) 2015/863(RoHS). The full...

This manual is also suitable for:

River 2 pro 700 Efr617 Efr620
