EcoFlow River 600 User Manual

Extra battery
Hide thumbs Also See for River 600:

Advertisement

Quick Links

Download this manual
Contact us:
support@ecoflow.com
www.ecoflow.com
User Guide
Extra Battery
WARNING
1. Please keep the product dry, do not expose it to high heat. Pay
attention to the safety when carrying the product.
2. Never disassemble, puncture, shock, crash, or incinerate the
product or the accessories.
3. After removing the package, the Max Module must be installed
with RIVER 600 in time. Please pay attention to static electricity
during the installation process.
4. Recycle and dispose of RIVER 600 in accordance with local
regulation.
5. People with disabilities or children should use the machine under
the protection of the supervisor.

Advertisement

loading

Related Manuals for EcoFlow River 600

Summary of Contents for EcoFlow River 600

  • Page 1 2. Never disassemble, puncture, shock, crash, or incinerate the product or the accessories. 3. After removing the package, the Max Module must be installed with RIVER 600 in time. Please pay attention to static electricity during the installation process. Contact us: WARNING 4.
  • Page 2 Failure to operate the product correctly may result in damage to the product or personal property and cause serious injury. EcoFlow will not assume any legal responsibility. DO NOT use the product with incompatible components or alter the product in any way without following the instructions provided by EcoFlow.
  • Page 3 3. Never install or remove other modules from the RIVER 600 when it is turned on. Do not plug or un- plug other modules when the power of the product is turned on, otherwise the power interface may be damaged.
  • Page 4 Product Charging 1. Always use EcoFlow approved charge cables. EcoFlow does not response to any damage caused by using non-EcoFlow charging cable. 2. When charging, please place the product on the ground with no flammable or combustible materials around. To prevent accidents, never leave the battery unattended during charging.

  • Page 5: Table Of Contents

    CONTENTS RIVER 600 Extra Battery Use Care and Safety Guide RIVER 600 Extra Battery Module Installation Instructions Ambient Light Area Technical Specifications What’s in the Box...

  • Page 6: River 600 Extra Battery Use Care And Safety Guide

    Make sure to turn off the RIVER 600 before install the expansion battery. You need to press and hold the ON/OFF power button to ensure that the power is off. You must not turn the RIVER 600 on be- fore installing the bottom cover to avoid the poor battery contact.

  • Page 7: River 600 Extra Battery Module Installation Instructions

    Ambient light and signal indication 1. Female Battery Socket And Installation Instructions 1. Please make sure that the RIVER 600 is turned off. Take out the screwdriver from the extra battery module kit and locate the four screws on the bottom cover.
  • Page 8 Male battery socket Short screws 2. Please unscrew the 4 screws according to the figure and remove the bottom cover. You can see the male battery socket. The extra battery module should be positioned as shown in the figure. (Please note that only the bottom cover needs to be remove. Do not remove the top cover.) power a free life...
  • Page 9 Long screws 3. Align the male and female battery sockets and connect them. Close the botton cov- er. Take the four long screws from the kit and screw them on the screw mouth. power a free life...
  • Page 10 4. Put the RIVER 600 upright and turn it on. The extra battery module’s ambient light will turn blue. If the extra battery module indicator light is shown on the RIVER 600’s display, the extra battery module is activated successfully. Please make sure the machine is fully charged before use.

  • Page 11: Ambient Light Area

    *Ambient Light Area 1. Status Signals Powering up: The blue light will move from the middle to the sides Powering down: The blue light will move from the sides to the middle. Charging: The blue light will move from left to right repeatedly. 2.

  • Page 12: Technical Specifications

    Technical Specifications General Specs Net Weight * 5.5lbs (2.5kg) Dimensions * 11.2 x 7 x 2.3in (28.5 x 18 x 5.9cm) Capacity 288Wh (28.8V) Testing and certification UL Standard, CE, FCC, RoHS Battery Cell Chemistry Lithium-ion Discharge Temperature -4 to 140°F +/-5°F(-20 to 60°C +/-3°C) Charge Temperature 32 to 113°F +/-5°F(0 to 45°C +/-3°C) Shelf Life...
