E-Z UP ECLIPSE Instructions page 2

TAKEDOWN
FOR 10' X 20' (3.0m x 6.0m) MODEL ONLY:
Depress the toggle button on one of the middle legs to slide the lower/inner leg section into the upper/outer leg, then
proceed with the instructions below.
Collapse Shelter Legs
1. With a partner, slightly lift two adjacent corner legs simultaneously.
2. Depress the Toggle and slide lower/inner legs into upper/outer legs, making sure to do two legs at a time on the
same side. (Fig A)
3. Repeat on remaining legs.
Note: Keep the Toggle depressed while retracting leg.
Release Auto-Slider Pull Pin
®
4. With one hand, slightly push up on the truss near the Auto-Slider
5. With the other hand, release the Auto-Slider
6. Repeat on remaining legs.
Closing Shelter
7. Grasp the Frame on the top of the diamond-shaped area of Center Trusses on the opposite sides near the "CLOSE HERE"
sticker. (Fig C)
8. Lift the shelter up slightly, and shake it while stepping toward your partner until the shelter is approximately 3/4 closed.
Be careful not to pinch fingers!
9. Grasp the two outer legs, and push the frame together until it is fully closed.
10. Store the shelter in the cover bag provided.
Note: Hug your shelter before placing it in the cover bag.
CARE AND MAINTENANCE
For long lasting durability and the best possible protection for your E-Z UP® Instant Shelter® products,
follow these E-Z care and maintenance instructions:
• Use a mild soap (not detergent) and plenty of water for the top cleaning.
• Let the E-Z UP® top and frame dry completely before closing or storing to avoid mildew.
• Frame will operate and look better if occasionally treated with silicone spray, especially before and
after use in damp conditions. Remove excess silicone residue before applying top.
• Use a seam sealer (available at most sporting goods and hardware stores) if top leaks or drips water.
• Slightly tighten bolts if frame becomes loose.
REPLACEMENT PARTS
800-45-SHADE ezup.com/parts
WARRANTY INFORMATION
www.ezup.com/warranties
CONDITIONS
This warranty shall be void as to any product that has been altered or modified in any manner. This
warranty does not apply to damages caused by wind, rain, or other forces of nature, not to accidental
or deliberate damage of the product, nor to the use of the product that does not conform with the
product instructions. This warranty is provided in lieu of all other warranties, expressed or implied.
INTERNATIONAL E-Z UP, INC.
1900 Second St., Norco, California 92860
800-45-SHADE
Pull Pin to relieve pressure. (Fig B)
®
Pull Pin by pulling the ring.
®
INSTRUCTIONS FOR
Fig. A
Fig. C
Lift fabric top to locate "CLOSE HERE"
stickers on the Center Trusses.
IMPORTANT INFORMATION
Read this information before proceeding. It is the user's responsibility to take the following
precautions at all times.
• Always stake or weigh down your E-Z UP® Instant Shelter® product with genuine E-Z UP®
accessories. See ezup.com for products and guidelines. Do not use in any potentially windy or rainy
weather.
• Wind and rain can damage the E-Z UP® Instant Shelter® product and also may result in injury to you
or others. Therefore, do not rely on your shelter for protection in heavy or prolonged rain storms.
• The E-Z UP® Instant Shelter® product is designed as a temporary shelter. Do not leave up for
extended periods.
• Use caution when handling the E-Z UP® folding frame.
• Avoid pinching hands or fingers as frame opens or closes.
• Do not use shelter in a lightning storm.
• Do not leave your E-Z UP® Instant Shelter® product unattended.
• Do not build fires within shelter enclosure.
WARNING:
Keep all flame and heat sources away from all Instant Shelter® fabrics and accessories. These fabrics
meet the flammability requirements of CPAI-84. The fabric may burn if left in continuous contact with
any flame source. The application of any foreign substance to the fabric may render the flame-resistant
properties ineffective.
CAN/ULC-S109 NATIONAL STANDARD OF CANADA, FLAME TESTS OF FLAME-RESISTANT FABRICS AND FILMS
© Copyright 2024 International E-Z UP, Inc. USA. All rights reserved.
The #1 Instant Shelter
Fig. B
Auto-Slider Pull Pin
®
Brand in the World
®
ezup.com
