gemini
Two Rides ... One Destination
NOVA MODEL 4500BK: GEMINI 2 IN 1 ROLLATOR
TRANSPORT CHAIR COMBO User Guide
Safety and Warning Instructions
• DO NOT exceed 300 lb. weight capacity.
• DO NOT self-propel or scoot around while seated.
• Care should be taken to ensure that all detachable legs, castors, or any other moving
objects are in good working order before operation.
• Periodically check handle and leg push buttons to make sure they are secure.
• Periodically check push buttons on backrest to make sure they are engaged.
• Always contact your physician or therapist before using to determine proper adjustment
and usage.
• Brakes must be in locked position before using the seat. Do not attempt to push yourself
or ambulate in any way.
• Both feet should rest flat on the ground when sitting.
• DO NOT push back on the backrest or extend your body over the backrest. It is not
designed to support the entire weight of the user. Backrest must always be attached
when rollator is in use.
• DO NOT use on stairs, escalators, moving sidewalks, or any uneven surfaces.
• DO NOT attempt to reach for items while seated on the rollator. This motion may cause
a change in weight distribution and cause the rollator to tip or become unstable.
• Items should not hang over the top or front of the basket.
• Make sure rollator frame is fully opened before use.
• DO NOT sit on the rollator on an incline.
• DO NOT support your full body weight on the handles when attempting to sit down.
• DO NOT remove warning sticker.
FAILURE TO FOLLOW THESE INSTRUCTIONS CAN LEAD TO SERIOUS INJURY OR
RESULT IN DEATH.
MISUSE OF THE ROLLATOR MAY VOID WARRANTY.
WARNING
DO NOT REMOVE WARNING LABEL
f
Failure to follow sa ety instructions
may result in serious injury or death
WARNING
!
Do Not Remove Warning Label
Failure to follow safety instructions may
result in injury or death
*Revised January 23, 2024
DO NOT place arms or elbows
on handles to walk or rise from
seated position.
DO NOT use as a wheelchair and do not self propel
Lock handbrakes when sitting and while seated
Backrest must be attached to walker prior to use
DO NOT use on stairs, escalators, or moving walkways
Consult your user manual before operating
www.novajoy.com • 1-800-557-6682
Nova Warning Label
width: 13.5cm
length: 2cm
Advertisement
Related Manuals for Nova GEMINI
Summary of Contents for Nova GEMINI
- Page 1 Two Rides … One Destination NOVA MODEL 4500BK: GEMINI 2 IN 1 ROLLATOR TRANSPORT CHAIR COMBO User Guide Safety and Warning Instructions • DO NOT exceed 300 lb. weight capacity. • DO NOT self-propel or scoot around while seated.
- Page 2 Assembly Instructions WHAT’S INCLUDED c. (1) Footrests a. (1) Main Frame b. (1) Pouch Assembly Instructions To unfold: Push down on the middle of the seat support tubes until they are secured in the frame cradles (see Figure 1). You should hear the seat click when properly engaged (see Figure 2).
- Page 3 To remove/attach the pouch: While the unit is in the folded position, slip the nylon loop over the end of the seat support plug (see Figure 5). Repeat for the other side. Figure 5 To Attach the footrests: Determine the left and right side by folding down the foot plate and placing them in front of the seat.
- Page 4 Operation Instructions To adjust the handle height Turn the knob counter-clockwise to loosen the handlebar (see Figure 9). Figure 9 Set the correct adjustment height for the end user by moving the handle up or down to the appropriate numbered line on the handle bar (see Figure 10).
- Page 5 To use the handbrakes To use: Squeeze handbrake to stop the rollator or control your walking speed. To lock: 1. Squeeze on the black brake lever until you hear an audible click to signify the brakes are engaged (see Figure 12). 2.
- Page 6 How to Properly Fit Your Rollator Rollators are not One Size Fits All, and it is very important to choose a rollator that fits your height. Two things to consider are: 1) handle height for proper walking posture 2) seat height - which should allow you to sit safely and comfortably on the rollator with your back resting on the backrest, your feet flat on the ground and your legs at a 90 degree angle.
- Page 7 To Prevent Tipping Over when Sitting Distribute weight evenly on the seat. DO NOT lean on one side of the rollator. Both feet should rest flat on the ground. DO NOT support your full body weight on the handles when attempting to sit down. Determining the Correct Handle Height Stand upright behind the rollator with your arms hanging at your side and both feet in line with the rear wheels.
- Page 8 How to adjust the brakes The following information is designed to assist you with the adjustment of your NOVA Handbrake System. Note: The braking system on your new NOVA rollator has been preset from the factory. To maintain this preset position, be sure that the tension adjustment screw locking nuts are tight against the housing and the rear wheels.
- Page 9 DO NOT use parts, accessories, or adapters other than those manufactured by NOVA Medical Products, Inc, which are designed specifically for this product. SAFETY INSPECTION - MAINTENANCE Your product is a precision product - proper care will ensure proper function.
- Page 10 ITEM INSPECT ITEM INITIAL WEEKLY MONTHLY 6 MONTHS Transport chair should roll straight, doesn't feel GENERAL "tight" or pull to one side Inspect for loose, missing, or broken hardware in all locations Inspect cane hand grips for wear, looseness, or deterioration FRAME Inspect for bent frame...
-
Page 11: Maintenance
The warranty is void upon any sale or transfer of ownership or use by other person. NOVA warrants its products are free from defects in material and workmanship under NORMAL use for the period commencing upon the date of...
