ENFORCER E-931-S50RRGQ Installation Manual

50ft Reflective Photoelectric
Beam Sensor
E-931-S50RRGQ
Installation Manual
The ENFORCER E-931-S50RRGQ 50ft Reflective Photoelectric Beam Sensor provides reliable
sensing of objects that enter the space between the sensor and reflector, thus breaking the
infrared beam. It is suitable for various types of such as detection such as sensing approaching
vehicles to open a garage door or outdoor gate, as an entry notification for stores, to assist in
measuring parking distances, or an alarm notification, as well as many other uses.
 Up to 50ft (15m) sensing range
 Weatherproof (IP55) construction
 Anti-condensation housing
 12-30V DC/AC 60Hz, 100mA
IMPORTANT:
The E-931-S50RRGQ conforms to UL Std. 325 for gate operators that use the N.C. or
10kΩ resistor for monitoring.
CAUTION
 This sensor was not designed to prevent bodily injury or loss of life.
 This sensor was not designed for use in environments where explosive gases may be present.
 Use of this sensor in certain security applications may be regulated by local laws or codes. SECO-LARM
is not responsible for compliance with such laws or codes.
 Round, ø3 / " (82mm) reflector
1
4
 Form C relay: 0.5A@30VAC/VDC
 Beam status LED
 N.C. Tamper switch, 500mA@30VAC/VDC
Conforms to
UL Std. 325
