25m Two Way Wireless Long
Range Corridor PIR Detector
®
KX25LR-WE Specifications
®
Model:
KX25LR-WE
25m Internal detector
Colour:
WHITE
Casing:
3mmABS, 0.4mm HDPE in lens area
Transmission Frequency:
868MHz, FM Transceiver Narrow Band
Tranmission Method:
Fully Encrypted Rolling Code
Transmission Range:
300m Free Space
Detection Method:
Low Noise Pyroelectric Sensor
Sensitivity:
High, Low
Temperature Compensation:
Advanced Automatic
Detection Range:
25m
Detection Zones:
46
Detection Speed:
0.3 - 3.0 m/s
Detection Angle:
90
Battery:
CR123A Lithium Battery
2.5V +/- 5% at 25
°C
Low Battery Threshold:
Battery Life:
Greater than 2 years
Mounting Height:
2.4m
Tamper Switch:
Front and RearTamper
Storage Temperature:
-20°C to 50°C
Certified Operating Temp:
-10°C to 40°C
Nominal Working Temp:
-10°C to 50°C
Accessories:
Wall and ceiling mounting brackets optional
Emissions / Immunity:
EN55022 Class B / EN50130-4
Coverage Pattern
HORIZONTAL COVERAGE
90
O
46 zones
18m
17m
6 planes
16m
15m
14m
13m
12m
11m
10m
9m
8m
7m
6m
5m
4m
3m
2m
1m
0m
1m
2m
3m
4m
5m
6m
7m
8m
9m
10m
11m
12m
13m
14m
15m
16m
17m
18m
1m
5m
15m
10m
20m
VERTICAL COVERAGE
2.4m
KX25LR-WE
®
This product is approved for use in the Residential,
Commercial and Light Industrial Environment.
EN50131-2-2:2008
2
EN50131-5-3:2005+A1:2008
Security Grade 2
Environmental Class II
Suitable for use in systems installed
to conform to PD6662:2010
NOTE: Only the KX25LRHT-WE has
been certified by IMQ.
Customer Support Line : +44(0)845 6434 999
or telephone +44(0)1709 535225
E-mail: customer.support@pyronix.com
website: www.pyronix.com
Pyronix Limited, Secure House, Braithwell Way,
Hellaby, Rotherham, S66 8QY. UK
WARRANTY
This product is sold subject to our standard warranty
conditions and is warranted against defects in
workmanship for a period of two years
excluded)
25m
In the interest of continuing improvement of quality,
customer care and design, Pyronix Ltd reserves the
right to amend specifications, without giving prior
notice.
25m
.
(batteries
RINS1594-2
