ENFORCER E-960-D90GQ Manual

Twin photobeam detectors
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Twin Photobeam Detectors
Model #
E-960-D90GQ
E-960-D190GQ*
E-960-D290GQ*
E-964-D390GQ*
NOTE: All above models are also available in non-ETL compliant version
* Special order only (E-964-D390GQ is a multi-frequency version).
Manual
Outdoor Range
90ft (30m)
190ft (60m)
290ft (90m)
390ft (120m)
®
Conforms to
UL Std. 325
Indoor Range
190ft (60m)
390ft (120m)
590ft (180m)
790ft (240m)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E-960-D90GQ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ENFORCER E-960-D90GQ

Summary of Contents for ENFORCER E-960-D90GQ

  • Page 1 Twin Photobeam Detectors Manual Conforms to UL Std. 325 Model # Outdoor Range Indoor Range E-960-D90GQ 90ft (30m) 190ft (60m) E-960-D190GQ* 190ft (60m) 390ft (120m) E-960-D290GQ* 290ft (90m) 590ft (180m) E-964-D390GQ* 390ft (120m) 790ft (240m) NOTE: All above models are also available in non-ETL compliant version * Special order only (E-964-D390GQ is a multi-frequency version).

  • Page 2: Table Of Contents

    ENFORCER Twin Photobeam Detectors Table of Contents: Important ............2 Beam Frequency Selection Chart ......7 Choosing a Location ......... 3 (E-964-D390GQ Model Only) Typical Installation ..........4 Multiple Sensors Sample Applications ....7-8 Running the Cable ..........4 Adjusting the Alignment ........9 Wiring the Transmitter –...

  • Page 3: Choosing A Location

    ENFORCER Twin Photobeam Detectors Fig. 1: Identifying the Sensors Receiver Transmitter Mounting Plate Terminals Signal LED Frequency selection* Alarm LED switch Frequency selection* switch Power LED Power LED Vertical adjustment Voltage output screw probes Horizontal adjustment Lens View finder Alignment laser...

  • Page 4: Typical Installation

    ENFORCER Twin Photobeam Detectors Typical Installation: The photoelectric beam lens can be adjusted horizontally ±90°, and vertically ±5° (see Fig. 2). This allows much flexibility in terms of how the transmitter and receiver can be mounted (see Fig. 3). Install at a distance of 32" to 39" (80 to 100 cm) above the ground for most situations (see Fig. 3).

  • Page 5: Wiring The Transmitter - Pole Mount

    ENFORCER Twin Photobeam Detectors Wiring the Transmitter – Pole Mount: NOTE: Pole mounting bracket required. plate, connect the wires, and snap on the cover (see Fig. 7). 1. Remove the cover. Remove the screw under Wiring (Fig. 8) the lens unit in order to detach the mounting plate (see Fig.

  • Page 6: Examples Of Ways To Connect Sensors

    ENFORCER Twin Photobeam Detectors Fig. 9: Examples of Possible Ways to Connect One or More Sensors Control panel (12VDC) Example connection 1 – Standard Power Trigger signal ○ ○ ○ ○ ○ ○ Transmitter Receiver Control panel (12VDC) Example connection 2 – Dual Sensors, Separate Channels...

  • Page 7: Selectable 4-Channel Beam Frequency

    ENFORCER Twin Photobeam Detectors Selectable 4 – Channel Beam Frequency (For E-964-D390GQ Model Only): The sensor beam frequency can be set at different levels on-site to avoid interference from other twin photobeam sensors nearby, which is useful during multiple sensor applications as shown below.
  • Page 8 ENFORCER Twin Photobeam Detectors 3. Two layer (double stacked) applications. Sensor #1 Sensor #2 Sensor #3 Sensor #4 Sensor #5 Sensor #6 4. Perimeter security application. 5. Two layer (double stacked) perimeter security application. SECO-LARM U.S.A., Inc.

  • Page 9: Adjusting The Alignment

    ENFORCER Twin Photobeam Detectors Adjusting the Alignment: Fig. 10: The transmitter and receiver sensor units can be adjusted ±5º Horizontal and Vertical vertically and ±90º horizontally once the unit is mounted and Sensor Adjustment power is connected (see Fig. 2 on pg. 3).

  • Page 10: Testing The Unit

    ENFORCER Twin Photobeam Detectors Testing the Unit: 1. Power up the transmitter and receiver. NOTE: The alarm will be triggered only if both the upper and lower beams 2. If the yellow or red LED remains steady are simultaneously interrupted.

  • Page 11: Overview

    ENFORCER Twin Photobeam Detectors Fig. 12: Overview Top View 2.9" (74mm) 43ST Pole size 2.8" (72mm) Rear View Side View Front View Fig. 13 Beam Spread The beam spread (s) can be calculated as s=0.03xd. Distance (d) Beam spread (s) 90ft (30m) 2.7ft (0.8m)
  • Page 12 ENFORCER Twin Photobeam Detectors Table 6: Troubleshooting Situation Possible Solution Solution Transmitter LED does Incorrectly wired and/or insufficient Ensure the power supply to the not light voltage transmitter is 12 to 30V DC/AC, 60Hz Receiver LED never a. Insufficient voltage a.
