The following table outlines the steps for removing and replacing the hinge cover.

Removing and Replacing the Hinge Cover

1. Remove the AC power.
Remove the battery.
2. Locate the hinge cover.
3. Insert a scribe into the hinge cover slot.
4. Pry up on the notch on the right side of the hinge cover.
5.
Lift and remove the hinge cover from the chassis.
