The following table outlines the steps for removing and replacing the keyboard for the Latitude™ D620.

Removing and Replacing the Keyboard

1. Before removing the keyboard:
Remove the AC power.
Remove the battery.
Remove the hinge cover.
2. Locate the keyboard.
3. Remove the screws holding the keyboard to the chassis.
4.
Lift the keyboard and turn it away from the LCD.
