Removing And Replacing The Hard Drive - Dell LATITUDE D620 User Manual

Dell - Latitude™ D620 - Printer-Friendly Format
The following table outlines the steps for removing and replacing the hard drive for the Latitude™ D620.

Removing and Replacing the Hard Drive

1. Before removing the hard drive:
Remove the AC power.
Remove the battery.
2. Locate the hard drive.
3. Remove the two screws securing the drive.
4.
Slide the hard drive out of the bay to release it from the system.
https://dcse.dell.com/SelfStudy/Foundations_2007/Foundations_2007_Portables/Portable...
Página 37 de 145
22/02/2010
