NOTE:
While the mini wireless cards are CRUs, the antenna cables are field replaceable only. The cables are contained in
the LCD top cover assembly and are not a separate orderable part. If an antenna cable needs to be replaced for any
reason, you must replace the LCD top cover.
Five antenna leads run from the LCD to the mini card locations. The main (white) and auxiliary (black) wires are for the WLAN
cards, the gray/white and gray/black wires are for the WWAN cards. The fifth lead is for the 802.11n standard when cards
become available.
Cap any unused antenna lead for the WWAN cards to prevent interference with the other cables and the card itself.
Connect the wires for the WWAN cards as follows:
WWAN Card
Dell™ Wireless 5500 (US)
single post
Dell Wireless 5505 (EU)
single post
Dell Wireless 5700
dual post
Printed 2/22/2010 11:17:19 AM
Expires 2/23/2010 11:17:19 AM
https://dcse.dell.com/SelfStudy/Foundations_2007/Foundations_2007_Portables/Portable...
White/Gray Antenna Black/Gray Antenna
Attached Capped
Capped Attached
Attached — Main Attached — Aux
Latitude™ D620
