- Page 1 PYROMETER CellaTemp ® PK(L) 6x BF, PKF 66/67 BF Ident no.: 1127764 12/2024...
-
Page 3: Explanation Of Symbols
This quick guide gives you the minimum information to properly install the pyrometers of the PK series. For detailed information please refer to the user guide CellaTemp PK. You can download it under the following link: https://www.keller.de/en/its/mediacenter/manuals.htm Explanation of symbols Important safety-related references in this manual are marked with a symbol. -
Page 4: Electrical Connection
Quick Start Guide CellaTemp PK(L) 6x BF, PKF 66 / 67 BF • The two-colour pyrometer should be installed at 90 ° to the measurement object, if possible. The angle should not be less than 45 ° from the vertical. •... - Page 5 The IODDs required for configuring the IO-Link device as well as detailed information on process data set-up, diagnostic functions and parameter addresses are available in the download area at www.keller.de/en/its/mediacenter. A 3-wire cable port Class A (Type A) must be used for IO-Link operation.
- Page 6 These devices can be returned for disposal to the manufacturer or they must be disposed properly by the user. For the improper disposal of the device by the user, the company KELLER is not responsible. is a registered trademark of the IO-Link corporate community.
- Page 8 Copyright prohibits the reproduction or distribution of this instruction manual, in- cluding text, photographs or images contained herein, in whole or in part, for any purpose whatsoever, without prior consent of the author. This applies to any form of mechanical or electronic reproduction as well as to electronic transmission in any form through any medium.
