Milwaukee pH58 User Manual

The meter is also provided with BEPS (Battery Error
Prevention System), which avoids any erroneous
readings due to low battery level by automatically
switching the meter off.
It is recommended to replace the batteries
immediately.
To replace the batteries unscrew the battery
compartment cap and replace all four 1.5V batteries
while paying attention to their polarity. Make sure
the gasket is in place before screwing back the cap.
Batteries should only be replaced in a non-
hazardous area using the battery type specified in
this instruction manual.
ACCESSORIES
MI58P Replaceable electrode for pH58
M10004B pH 4.01 buffer, 20 ml sachet, 25 pcs.
M10007B pH 7.01 buffer, 20 ml sachet, 25 pcs.
M10010B pH 10.01 buffer, 20 ml sachet, 25 pcs.
MA9004 pH 4.01 buffer, 230 ml bottle
MA9006 pH 6.86 buffer, 230 ml bottle
MA9007 pH 7.01 buffer, 230 ml bottle
MA9009 pH 9.18 buffer, 230 ml bottle
MA9010 pH 10.01 buffer, 230 ml bottle
MA9015 Electrode storage solution, 230 ml
MA9016 Electrode cleaning solution, 230 ml
Electrode rinse solution, 20 ml sachet,
M10000B
25 pcs.
CERTIFICATION
Milwaukee Instruments conform to the CE European
Directives.
Disposal of Electrical & Electronic Equipment. Do not
treat this product as household waste. Hand it over to the
appropriate collection point for the recycling of electrical
and electronic equipment.
Disposal of waste batteries. This product contains
batteries. Do not dispose of them with other household
waste. Hand them over to the appropriate collection point
for recycling.
Please note: proper product and battery disposal prevents
potential negative consequences for human health
and the environment. For detailed information, contact
your local household waste disposal service or go to
www.milwaukeeinstruments.com (USA & CAN) or
www.milwaukeeinst.com.
SPECIFICATIONS
RANGE
-5.0 to 60.0°C / 23.0 to 140.0°F
RESOLUTION
ACCURACY (@25°C)
TYPICAL EMC DEVIATION
TEMPERATURE COMPENSATION
pH CALIBRATION Automatic, 1 or 2 points
with 2 sets of memorized buffers
(pH 4.01, 7.01, 10.01 or 4.01, 6.86, 9.18)
ORP CALIBRATION
PROBE Replaceable MI58P
ENVIRONMENT -5 to 50°C; 100% RH max.
BATTERY TYPE 4 x 1.5V; IEC LR44, A76
BATTERY LIFE approx. 250 hours of use
AUTO-OFF after 8 minutes of non-use
DIMENSIONS
WEIGHT
RECOMMENDATION
Before using this product, make sure it is entirely suitable for
your specific application and for the environment in which it is
used. Any modification introduced by the user to the supplied
equipment may compromise the meter's performance. For
your and the meter's safety do not use or store the meter
in hazardous environment. To avoid damage or burn, do not
perform any measurement in microwave ovens.
WARRANTY
This instrument is warranted against defects in materials
and manufacturing for a period of 2 years from the date of
purchase. Probe is warranted for 6 months This warranty
is limited to repair or free of charge replacement if the
instrument cannot be repaired. Damage due to accidents,
misuse, tampering or lack of prescribed maintenance is
not covered by warranty. If service is required, contact
your local Milwaukee Instruments Technical Service. If the
repair is not covered by the warranty, you will be notified of
the charges incurred. When shipping any meter, make sure
it is properly packaged for complete protection.
Milwaukee Instruments reserves the right to make
improvements in design, construction and appearance of
its products without advance notice.
ISTPH58 07/20
USER MANUAL
-2.00 to 16.00 pH;
±1000 mV (ORP);
0.01 pH;
1 mV;
0.1°C / 0.1°F
±0.05 pH;
PRO Waterproof
±2 mV;
±0.5°C / ±1°F
pH/ORP/Temperature
±0.02 pH;
±2 mV;
±0.3°C / ±0.6°F
Automatic,
from -5 to 60°C
Factory calibrated
200 x dia 38 mm
100 g
milwaukeeinstruments.com (USA & CAN)
SATISFACTION
GUARANTEED
pH58
Tester
ON/OFF
CAL
pH58
SET
HOLD
milwaukeeinst.com
