Murr Elektronik MVP12 Series English Manual

Hide thumbs Also See for MVP12 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
ENGLISH MANUAL
for devices of the MVP12 series
Art.-No. 59728 | 59738 | 59828 | 59838

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MVP12 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Murr Elektronik MVP12 Series

Summary of Contents for Murr Elektronik MVP12 Series

  • Page 1 ENGLISH MANUAL for devices of the MVP12 series Art.-No. 59728 | 59738 | 59828 | 59838...
  • Page 2 This document is valid for the following products: Product designation Art.-No. MVP12-P6 DIO8 DIO8 8xM12A IOLA12 PL4 B0 59728 MVP12-P6 DIO8 DIO8 8xM12A IOLA12 PL4 E0 59828 MVP12-P6 DIO8 DIO8 8xM12A IOLA12 PL5 B0 59738 MVP12-P6 DIO8 DIO8 8xM12A IOLA12 PL5 E0 59838 Document status: Manual number 59728...

  • Page 3: Table Of Contents

    Electrical data 4.1.2 Environmental characteristics 4.1.3 Protection 4.1.4 Mechanical data 4.1.5 Product reliability 4.1.6 Conformity, Approvals Art.-No. 59828 4.2.1 Electrical data 4.2.2 Environmental characteristics ENGLISH MANUAL 3 / 68 for devices of the MVP12 series Art.-No. 59728 | 59738 | 59828 | 59838...
  • Page 4 Art.-No. 59738, 59838 7.2.2 ISDU (Indexed Service Data Unit) 7.2.2.1 Art.-No. 59828, 59838 Diagnostic 7.3.1 Vendor-specific IO-Link events Process data 7.4.1 Port-Based Bitmapping ENGLISH MANUAL 4 / 68 for devices of the MVP12 series Art.-No. 59728 | 59738 | 59828 | 59838...
  • Page 5 7.4.2 Pin-Based Bitmapping Maintenance and cleaning Appendix Accessories Legal notes ENGLISH MANUAL 5 / 68 for devices of the MVP12 series Art.-No. 59728 | 59738 | 59828 | 59838...

  • Page 6: Introduction

    Introduction Introduction Purpose of this This document instructs the technical staff of the machine manufacturer or document machine operator on the safe use of the described devices. It does not include instructions on the safe use of the machine in which the devices are integrated.

  • Page 7: Applicable Documents

    Introduction Applicable documents Document Art.-No. Operating instructions 59728 Product Data 59728 Product Data 59828 Product Data 59738 Product Data 59838 You will find the applicable documents included in the scope of delivery or on- line: shop.murrelektronik.com Environmentally friendly disposal Comply with country- ...

  • Page 8: About This Manual

    Introduction About this manual 1.5.1 Symbols This document includes information and notes that must be observed for your own safety and to avoid injuries and equipment damage. They are marked as follows: DANGER! Immediate danger  Failure to observe this warning involves an imminent risk of death or seri- ous injuries.

  • Page 9: Trademarks

    Introduction 1.5.2 Trademarks Trademarks of the following companies and institutions are used in this docu- mentation: IO-Link c/o PROFIBUS Nutzerorganisation e.V. (PNO) 1.5.3 Specifications Specification Link IO-Link www.io-link.com Version 1.1.2 dated 2013-07 NOTE The features of IO-Link specification version 1.1.3 are also supported. User manual 59728_hdb_en_16 9 / 68...

  • Page 10: For Your Safety

    For your safety For your safety General safety instructions Fachpersonal Nur Fachpersonal der Automatisierungstechnik darf das Gerät montieren, in Betrieb nehmen und betreiben. Fachpersonal sind laut der Norm IEC 600500-195 Personen mit entsprech- ender Ausbildung und Erfahrung, die ihn oder sie befähigt, Gefahren und Risiken, die durch Elektrizität entstehen können, zu meiden.

  • Page 11: Warranty And Liability

    For your safety  must not be used as a safety-related device. It does not meet the relevant standards. Safety functions of the system are not ensured.  should only be used in the respective IP-protected environment.  should only be cleaned with oil-free compressed air and a leather cloth. ...

  • Page 12: Description

    Description Description Art.-No. 59728, 59828  IO-Link hub in 50 mm plastic housing  1 x M12 IO-Link class A  1 x M12L 4-pin external voltage supply  8 x M12 I/O  16 configurable digital inputs/outputs  Galvanically isolated voltage groups Art.-No.

  • Page 13: Product Designation Code

    Description Product Designation Code The product designation provides information on the device function. Art.-No. 59728 MVP12-P6 DIO8 DIO8 8xM12A IOLA12 PL4 B0 Art.-No. 59828 MVP12-P6 DIO8 DIO8 8xM12A IOLA12 PL4 E0 Art.-No. 59738 MVP12-P6 DIO8 DIO8 8xM12A IOLA12 PL5 B0 Art.-No.

  • Page 14: Device Structure

    Description Device structure Fig. 3-1: Device structure and port designations Art.-No. Port designation Explanation 59728, 59738, X0 ... X3 Digital inputs and outputs UL2 59828, 59838 X4 ... X7 Digital inputs and outputs UL1 Power I/O power supply IO-Link class A User manual 59728_hdb_en_16 14 / 68...

  • Page 15: Pin Assignment

    Description PIN assignment 3.3.1 Art.-No. 59728, 59828 I/O power XD1 (M12 male connector) Pin 1 24 V Pin 2 0 V UL2 Pin 3 0 V UL1 Pin 4 24 V Pin 5 n.c. IO-Link Class A XZ1 (M12 male connectors) Pin 1 24 V US (L+)

  • Page 16: Art.-No. 59738, 59838

    Description 3.3.2 Art.-No. 59738, 59838 I/O power XD1 (M12 male connector) Pin 1 24 V Pin 2 0 V UL2 Pin 3 0 V UL1 Pin 4 24 V Pin 5 IO-Link Class A XZ1 (M12 male connectors) Pin 1 24 V US (L+) Pin 2...

  • Page 17: Use In Safety Functions

    Description Use in safety functions With an external two-channel and two-pin shut-off of voltages ULx_24V und ULx_0V, the device can be used in safety functions up to PL d in acc. with EN 13849-1. Ensured by safe separation between the device's actuator end and other volt- ages in the device.

  • Page 18: Safety-Related Switch-Off Ul1 And Ul2

    Description 3.4.1.1 Safety-related switch-off UL1 and UL2 Fig. 3-2: Safety-related switch-off UL1 and UL2 Safety structure  Two-channel UL1 and UL2 MTTFd 529 Jahre *() MVP12P6 - MVP UL1 DCavg. SFn Actuator 1-UL1 Safety relay - SFn Sensor - SFn MTTFd 529 Jahre *() MVP12P6 - MVP UL2...

  • Page 19: Safety-Related Switch-Off Ul1 And/Or Ul2

    Description 3.4.1.2 Safety-related switch-off UL1 and/or UL2 Fig. 3-3: Safety-related switch-off UL1 and/or UL2 Safety structure  Two-channel UL1 and/or UL2 MTTFd 529 Jahre *() Safety relay - SFn Sensor - SFn MVP12P6 - MVP UL1 DCavg. SFn Actuator 1-UL1 MTTFd 529 Jahre *() Safety relay - SFn...

  • Page 20: Safety-Related Switch-Off Ul1 And Ul2 Supplied By Power Supply Unit

    Description 3.4.1.3 Safety-related switch-off UL1 and UL2 supplied by power supply unit Fig. 3-4: Safety-related switch-off UL1 and UL2 supplied by power supply unit Safety structure  Two-channel UL1 and UL2 MTTFd 529 Jahre *() MVP12P6 - MVP UL1 DCavg. SFn Actuator 1-UL1 Safety relay - SFn Sensor - SFn...

  • Page 21: Safety-Related Switch-Off Ul1

    Description 3.4.1.4 Safety-related switch-off UL1 Fig. 3-5: Safety-related switch-off UL1 Safety structure  Single-channel UL1 only MTTFd 529 Jahre *() Safety relay - SFn Sensor - SFn MVP12P6 - MVP UL1 DCavg. SFn Actuator 1-UL1 Legend: 1 | SF = safety functions 2 | n = 1-x 3 | * (MTTFd - SN 29500 at 40 °C and rated data) User manual 59728_hdb_en_16...

  • Page 22: Safety-Related Switch-Off Ul2

    Description 3.4.1.5 Safety-related switch-off UL2 Fig. 3-6: Safety-related switch-off UL2 Safety structure  Single-channel UL2 only MTTFd 529 Jahre *() Safety relay - SFn Sensor - SFn MVP12P6 - MVP UL2 DCavg. SFn Actuator 2-UL2 Legend: 1 | SF = safety functions 2 | n = 1-x 3 | * (MTTFd - SN 29500 at 40 °C and rated data) User manual 59728_hdb_en_16...

  • Page 23: Safety-Related Switch-Off Via The Control

    Description 3.4.1.6 Safety-related switch-off via the control Fig. 3-7: Safety-related switch-off via the control Safety structure  All safety structures, as shown for the use of safety relays, are possible when a safety control is used. The failure rates can be taken from there. User manual 59728_hdb_en_16 23 / 68...
  • Page 24 Description General explanations of the figure „Safe switch-off". Position Description Provide a ballast fuse for safe fault switch-off, see Information on item 1 below the table. Safe cable routing according to DIN EN ISO 13849-2. Consider the table D.4 fault exclusions of lines/ cables! DIO components are only allowed in SELV operation.
  • Page 25 Description Observe safety regulations Only qualified personnel is allowed to carry out mounting, commissioning,  modification, inspection and retrofitting work.  The valid regulations and standards according to the information in the op- erating instructions and the manual must be observed. ...

  • Page 26: Safe Installation

    Description 3.4.2 Safe installation Safely and securely install the cabling of the product in accordance with EN 60204-1: Excerpt (EN 60204-1:2018 Section 13.4.3) Flexible cables of machines shall be so installed or protected as to minimize the possibility ox external damage due to factors that include the following ca- ble use or potential abuse: Being run over by the machine itself.

  • Page 27: Technical Data

    Technical Data Technical Data Art.-No. 59728 4.1.1 Electrical data Device supply Operating voltage UL1 24 V Operating voltage UL2 24 V Operating voltage IO-Link 24 V Range of operating voltage UL1 18 ... 30 V Range of operating voltage UL2 18 ...
  • Page 28 Technical Data Input (DI) Connection/female connector M12, A-coded Cable cross-section ≤0.75 mm² Cable length ≤30 m Input characteristic EN 61131-2 Type 1 + type 3 Input filter 1 ms Output (DO) Connection/female connector M12, A-coded Cable cross section ≤0.75 mm² Cable length ≤30 m Output current...

  • Page 29: Environmental Characteristics

    Technical Data 4.1.2 Environmental characteristics Climatic Operating temperature -25 °C ... +70 °C Storage temperature -40 °C ... +85 °C Installation height Above sea level ≤3000 m Relative humidity ≤95 % Mechanical Vibration test EN 60068 Parts 2-6 5 ... 500 Hz; Const.

  • Page 30: Mechanical Data

    Technical Data 4.1.4 Mechanical data Material data Housing material Valox 553 black Assembly data Weight 200 g Dimensions L x W x H 126 x 50 x 34.5 mm 4.1.5 Product reliability Product reliability MTTF SN 29500 (at 40 °C and rated data) 89 years Other failure rates at higher temperatures upon request.

  • Page 31: Conformity, Approvals

    Technical Data 4.1.6 Conformity, Approvals Conformity, Approvals Product standard EN 61131-2 (IEC 61131-2) Programmable logic controllers, Part 2 EN 61131-9 (IEC 61131-9) Programmable logic controllers, Part 9 2014/30/EU 2011/65/EU UKCA Electromagnetic Compatibility Regulations 2016, The Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equip- ment Regulations 2012 2014/30/EU...

  • Page 32: Art.-No. 59828

    Technical Data Art.-No. 59828 4.2.1 Electrical data Device supply Operating voltage UL1 24 V Operating voltage UL2 24 V Operating voltage IO-Link 24 V Range of operating voltage UL1 18 ... 30 V Range of operating voltage UL2 18 ... 30 V Range of operating voltage IO-Link 18 ...
  • Page 33 Technical Data Input (DI) Connection/female connector M12, A-coded Cable cross-section ≤0.75 mm² Cable length ≤30 m Input characteristic EN 61131-2 Type 1 + type 3 Input filter 1 ... 10 ms, adjustable Output (DO) Connection/female connector M12, A-coded Cable cross section ≤0.75 mm²...

  • Page 34: Environmental Characteristics

    Technical Data 4.2.2 Environmental characteristics Climatic Operating temperature -25 °C ... +70 °C Storage temperature -40 °C ... +85 °C Installation height Above sea level ≤3000 m Relative humidity ≤95 % Mechanical Vibration test EN 60068 Parts 2-6 5 ... 500 Hz; Const.

  • Page 35: Mechanical Data

    Technical Data 4.2.4 Mechanical data Material data Housing material Valox 553 black Assembly data Weight 200 g Dimensions L x W x H 126 x 50 x 34.5 mm 4.2.5 Product reliability Product reliability MTTF SN 29500 (at 40 °C and rated data) 89 years Other failure rates at higher temperatures upon request.

  • Page 36: Conformity, Approvals

    Technical Data 4.2.6 Conformity, Approvals Conformity, Approvals Product standard EN 61131-2 (IEC 61131-2) Programmable logic controllers, Part 2 EN 61131-9 (IEC 61131-9) Programmable logic controllers, Part 9 2014/30/EU 2011/65/EU UKCA Electromagnetic Compatibility Regulations 2016, The Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equip- ment Regulations 2012 2014/30/EU...

  • Page 37: Art.-No. 59738

    Technical Data Art.-No. 59738 4.3.1 Electrical data Device supply Operating voltage UL1 24 V Operating voltage UL2 24 V Operating voltage IO-Link 24 V Range of operating voltage UL1 18 ... 30 V Range of operating voltage UL2 18 ... 30 V Range of operating voltage IO-Link 18 ...
  • Page 38 Technical Data Input (DI) Connection/female connector M12, A-coded Cable cross-section ≤0.75 mm² Cable length ≤30 m Input characteristic EN 61131-2 Type 1 + type 3 Input filter 1 ms Output (DO) Connection/female connector M12, A-coded Cable cross section ≤0.75 mm² Cable length ≤30 m Output current...

  • Page 39: Environmental Characteristics

    Technical Data 4.3.2 Environmental characteristics Climatic Operating temperature -25 °C ... +70 °C Storage temperature -40 °C ... +85 °C Installation height Above sea level ≤3000 m Relative humidity ≤95 % Mechanical Vibration test EN 60068 Parts 2-6 5 ... 500 Hz; Const.

  • Page 40: Mechanical Data

    Technical Data 4.3.4 Mechanical data Material data Housing material Valox 553 black Assembly data Weight 200 g Dimensions L x W x H 126 x 50 x 34.5 mm 4.3.5 Product reliability Product reliability MTTF SN 29500 (at 40 °C and rated data) 89 years Other failure rates at higher temperatures upon request.

  • Page 41: Conformity, Approvals

    Technical Data 4.3.6 Conformity, Approvals Conformity, Approvals Product standard EN 61131-2 (IEC 61131-2) Programmable logic controllers, Part 2 EN 61131-9 (IEC 61131-9) Programmable logic controllers, Part 9 2014/30/EU 2011/65/EU UKCA Electromagnetic Compatibility Regulations 2016, The Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equip- ment Regulations 2012 2014/30/EU...

  • Page 42: Art.-No. 59838

    Technical Data Art.-No. 59838 4.4.1 Electrical data Device supply Operating voltage UL1 24 V Operating voltage UL2 24 V Operating voltage IO-Link 24 V Range of operating voltage UL1 18 ... 30 V Range of operating voltage UL2 18 ... 30 V Range of operating voltage IO-Link 18 ...
  • Page 43 Technical Data Input (DI) Connection/female connector M12, A-coded Cable cross-section ≤0.75 mm² Cable length ≤30 m Input characteristic EN 61131-2 Type 1 + type 3 Input filter 1 ... 10 ms, adjustable Output (DO) Connection/female connector M12, A-coded Cable cross section ≤0.75 mm²...

  • Page 44: Environmental Characteristics

    Technical Data 4.4.2 Environmental characteristics Climatic Operating temperature -25 °C ... +70 °C Storage temperature -40 °C ... +85 °C Installation height Above sea level ≤3000 m Relative humidity ≤95 % Mechanical Vibration test EN 60068 Parts 2-6 5 ... 500 Hz; Const.

  • Page 45: Mechanical Data

    Technical Data 4.4.4 Mechanical data Material data Housing material Valox 553 black Assembly data Weight 200 g Dimensions L x W x H 126 x 50 x 34.5 mm 4.4.5 Product reliability Product reliability MTTF SN 29500 (at 40 °C and rated data) 89 years Other failure rates at higher temperatures upon request.

  • Page 46: Conformity, Approvals

    Technical Data 4.4.6 Conformity, Approvals Conformity, Approvals Product standard EN 61131-2 (IEC 61131-2) Programmable logic controllers, Part 2 EN 61131-9 (IEC 61131-9) Programmable logic controllers, Part 9 2014/30/EU 2011/65/EU UKCA Electromagnetic Compatibility Regulations 2016, The Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equip- ment Regulations 2012 2014/30/EU...

  • Page 47: Mounting

    Mounting Mounting Requirements Prerequisites for mounting: 1 | Even mounting surface to avoid mechanical tension. 2 | Provide proper grounding. 3 | Suitable installation site in terms of vibration and shock load, temperature and humidity (see chap. 4 "Technical Data"). 4 | Protected to avoid tearing off the connecting cables by personnel or de- vice.

  • Page 48: Mounting Distance

    Mounting Mounting distance Fig. 5-2: Distance between the devices a | Straight male connector: 5 mm Angled male connector: 50 mm NOTE  If angled male connectors are used, a minimum distance of 50 mm is re- quired. Functional ground FE connection Fig.

  • Page 49: Mounting The Device

    Mounting Mounting the device NOTICE Material damage due to incorrect installation. The fastening screws and tightening torques depend on the surface of the in- stallation site.  Use fastening screws that are suitable for the mounting surface structure.  Carefully tighten the screws. The indicated tightening torques must be ad- hered to.

  • Page 50: Installation

    Installation Installation WARNING! High electrical voltages. Electric shock may cause life-threatening injuries.  Only qualified personnel may connect the device.  Comply with the five safety rules of electrical engineering. Protective measures  According to IEC 60364 - Protection against electric shock. during connection work WARNING! Life-threatening voltage.

  • Page 51: Ensure Tight Seal

    Installation Ensure tight seal NOTICE Damage to and failure of the device due to ingress of liquids! Potential function impairment hazard, device damage. Degree of protection IP67 is not reached.  Unused ports must be sealed with dummy plugs! Fig. 6-1: Connecting cables Art.-No.

  • Page 52: Operation

    Operation Operation NOTE After writing an application-specific tag in the IO-Link hub, the hub briefly interrupts the IO-Link connection if the text is not the same as the text stored in the hub. LED indication The MVP devices are equipped with the following separate LED indicators: ...

  • Page 53: Led Indication For Inputs And Outputs

    Operation Firmware update LED in- LED state Description dicator Permanently on IO-Link in IDLE status, Firmware update completed success- Green fully Flashing IO-Link in status PREOPERATE/OP- ERATE, 1 Hz Green Update is not yet being performed Permanently on Update failed Flashing IO-Link in status PREOPERATE/OP- ERATE,...

  • Page 54: Led Indicator Ul1 And Ul2

    Operation 7.1.3 LED indicator UL1 and UL2 LED indicator UL1 and LED in- LED state Description dicator Permanently on OK, 17.5 V < UA < 30 V Green Permanently on Undervoltage, 12.5 V < UA < 17 V Flashing Overvoltage UA >...

  • Page 55: Io-Link Object Directory

    Operation IO-Link object directory 7.2.1 DPP (Direct Parameter Page) 7.2.1.1 Art.-No. 59728, 59828 ISDU Object name Length Meaning/default value index index cess in bytes Identification Art.-No. 59728 Art.-No. 59828 0x0000 0x00 MasterCommand 0x01 MasterCycleTime 0x02 MinCycleTime 0x03 M-sequenceCapa- bility 0x04 RevisionID 0x05 ProcessDataIn 0x06 ProcessDataOut 0x07 VendorID 1 (MSB)
  • Page 56 Operation ISDU Object name Length Meaning/default value index index cess in bytes 0x0024 DeviceStatus 0: The device works properly 1: Maintenance necessary 2: Out of specification 3: Functional check 4: Error 5 ... 255: Reserved 0x0025 DetailedDeviceSta- Variable 6 x (octet 1: EventQualifier, octet 2, 3: EventCode) 0x0028 ProcessDataInput...

  • Page 57: Art.-No. 59738, 59838

    Operation 7.2.1.2 Art.-No. 59738, 59838 ISDU Object name Length Meaning/default value index index cess in bytes Identification Art.-No. 59738 Art.-No. 59838 0x0000 0x00 MasterCommand 0x01 MasterCycleTime 0x02 MinCycleTime 0x03 M-sequenceCapa- bility 0x04 RevisionID 0x05 ProcessDataIn 0x06 ProcessDataOut 0x07 VendorID 1 (MSB) 0x012F 0x08 VendorID 2 (MSB) 0x09 DeviceID 1 (octet 2,...
  • Page 58 Operation ISDU Object name Length Meaning/default value index index cess in bytes 0x0024 DeviceStatus 0: The device works properly 1: Maintenance necessary 2: Out of specification 3: Functional check 4: Error 5 ... 255: Reserved 0x0025 DetailedDeviceSta- Variable 6 x (octet 1: EventQualifier, octet 2, 3: EventCode) 0x0028 ProcessDataInput...

  • Page 59: Isdu (Indexed Service Data Unit)

    Operation 7.2.2 ISDU (Indexed Service Data Unit) 7.2.2.1 Art.-No. 59828, 59838 ISDU Object name Length Meaning Default Index cess value bytes 0x0040 Status: Power Supply Sta- Indicates the status of UL1 tus UL1 - 0x00 = OK - 0x01 = undervoltage - 0x02 = overvoltage 0x0041 Status: Power Supply Value...
  • Page 60 Operation ISDU Object name Length Meaning Default Index cess value bytes 0x0081 Inputs: Signal Extension/ Extension of the input pulses in steps of 10 ms. Impulse Stretching - Subindex 1: X0 Pin 4 - Subindex 2: X0 Pin 2 … - Subindex 15: X7 Pin 4 - Subindex 16: X7 Pin 2 Setting per channel (subindex):...

  • Page 61: Diagnostic

    Operation Diagnostic 7.3.1 Vendor-specific IO-Link events NOTE In addition to the vendor-specific IO-Link events listed here, the standard events of the IO-Link specification also apply, version see chapter 1.5.3 "Specifications". Event Event type Description Action code 0x4000 Error Temperature error Overload 0x4210 Warning...
  • Page 62 Operation Event Event type Description Action code 0x8CD5 Error Power pin current overload/ shortcircuit - Port 5 Pin 1 Check installation 0x8CD6 Error Power pin current overload/ shortcircuit - Port 6 Pin 1 Check installation 0x8CD7 Error Power pin current overload/ shortcircuit - Port 7 Pin 1 Check installation Tab.

  • Page 63: Process Data

    Operation Process data 7.4.1 Port-Based Bitmapping Byte 0 inputs X0 ... X3 Contact Pin2_X3 Pin4_X3 Pin2_X2 Pin4_X2 Pin2_X1 Pin4_X1 Pin2_X0 Pin4_X0 Byte 1 inputs X4 ... X7 Contact Pin2_X7 Pin4_X7 Pin2_X6 Pin4_X6 Pin2_X5 Pin4_X5 Pin2_X4 Pin4_X4 NOTE Byte 2 and 3 are supported only by E0 devices. Byte 2 Diagnostic Global status...
  • Page 64 Operation 7.4.2 Pin-Based Bitmapping Process data Digital inputs Byte 0 inputs X0 ... X7 Contact Pin4_X7 Pin4_X6 Pin4_X5 Pin4_X4 Pin4_X3 Pin4_X2 Pin4_X1 Pin4_X0 Byte 1 inputs X0 ... X7 Contact Pin2_X7 Pin2_X6 Pin2_X5 Pin2_X4 Pin2_X3 Pin2_X2 Pin2_X1 Pin2_X0 NOTE Byte 2 and 3 are supported only by E0 devices. Byte 2 Diagnostic Global status...

  • Page 65: Maintenance And Cleaning

    Maintenance and cleaning Maintenance and cleaning NOTE Replace defective or damaged devices.  Device cleaning:  Use only oil-free compressed air or spirit  Use only lint-free materials (e.g. leather cloth) Do not use contact spray  User manual 59728_hdb_en_16 65 / 68...
  • Page 66 Appendix Appendix Accessories Description Art.-No. Screw Plug M12 Metal 996049 Plastic M12 screw plug, VE10 58627 Crimping cable lugs, ring form 10 mm² (M4) (narrow) 4000-71004-0000004 Grounding strap screw-down set M4 4000-71003-0101604 Designation Art.-No. 6-part screwdriver set 7000-98001-0000000 M12 torque wrench set, AF 13 7000-99102-0000000 PRODUCTS AND ACCESSORIES You will find a wide range of products in our catalog or in our Murrelektronik...

  • Page 67: Legal Notes

    Legal notes Legal notes Disclaimer Murrelektronik GmbH has reviewed the contents of this technical documenta- tion for conformity with the described hardware and software. It is possible that certain details may not be correct. For this reason, we make no warranty re- garding the accuracy of this technical documentation, and assume no liability for any errors, in particular full conformity.
  • Page 68 Murrelektronik GmbH | Falkenstraße 3 | 71570 Oppenweiler | GERMANY +49 7191 47-0 | +49 7191 47-491 000 | info@murrelektronik.com www.murrelektronik.com The information in the manual has been compiled with utmost care. Liability for the correctness, completeness and topicality of the information is restricted to gross negligence.
