ENGLISH MANUAL

for devices of the MVP12 series

Art.-No. 59840 | 59841

Table of Contents

Need help?

Do you have a question about the MVP12 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Murr Elektronik MVP12 Series

Page 1 ENGLISH MANUAL for devices of the MVP12 series Art.-No. 59840 | 59841...
Page 2 This document is valid for the following products: Product designation Art.-No. MVP12-P3 AI-MULT4 4xM12A IOLA12 E0 59840 MVP12-P3 AI-RTD4 4xM12A IOLA12 E0 59841 Document status: Manual number 59840 Language Version Date 2024-05 Murrelektronik GmbH Falkenstraße 3 71570 Oppenweiler GERMANY Phone +49 7191 47-0 Fax +49 7191 47-491000 info@murrelektronik.com NOTE...
Page 3: Table Of Contents
4.2.2 Measuring ranges 4.2.3 Environmental characteristics 4.2.4 Protection 4.2.5 Mechanical data 4.2.6 Product reliability 4.2.7 Conformity, Approvals Mounting Requirements Dimensions Mounting distance Functional ground Mounting the device ENGLISH MANUAL 3 / 50 for devices of the MVP12 series Art.-No. 59840 | 59841...
Page 4 Measured values for Art.-No. 59840 7.4.1.2 Measured values for Art.-No. 59841 7.4.2 Output data 7.4.2.1 Art.-No. 59840 7.4.2.2 Art.-No. 59841 Maintenance and cleaning Appendix Accessories Legal notes ENGLISH MANUAL 4 / 50 for devices of the MVP12 series Art.-No. 59840 | 59841...
Page 5: Introduction
Introduction Introduction Purpose of this This document instructs the technical staff of the machine manufacturer or document machine operator on the safe use of the described devices. It does not include instructions on the safe use of the machine in which the devices are integrated.
Page 6: Applicable Documents
Introduction Applicable documents Document Art.-No. Operating instructions 59840 Product data 59840 Product data 59841 The other applicable documents are included in the scope of delivery or can be downloaded from: shop.murrelektronik.com Environmentally friendly disposal Comply with country-  Always dispose of scrap devices in compliance with the applicable coun- specific waste disposal try-specific regulations on waste disposal regulations!
Page 7: About This Manual
Introduction About this manual 1.5.1 Symbols This document includes information and notes that must be observed for your own safety and to avoid injuries and equipment damage. They are marked as follows: DANGER! Immediate danger  Failure to observe this warning involves an imminent risk of death or seri- ous injuries.
Page 8: Trademarks
Introduction 1.5.2 Trademarks Trademarks of the following companies and institutions are used in this docu- mentation: IO-Link c/o PROFIBUS Nutzerorganisation e.V. (PNO) 1.5.3 Specifications Specification Link IO-Link www.io-link.com Version 1.1.2 dated 2013-07 User manual 59840_hdb_en_12 8 / 50...
Page 9: For Your Safety
For your safety For your safety General safety instructions Qualified personnel Only qualified and safety-trained personnel may assemble, commission and operate the device. Target group This document is intended for specialists in automation technology. Five safety rules of When working on electrical systems, always observe the five safety rules of electrical engineering electrical engineering: Disconnect from the mains.
Page 10: Warranty And Liability
For your safety 2.2.2 Warranty and liability Warranty and liability claims cannot be made if:  the product is not used according to its designated use, damage is caused due to non-observance of the  operating instructions,  the personnel was/is not qualified. User manual 59840_hdb_en_12 10 / 50...
Page 11: Description
Description Description Art.-No. 59840  IO-Link hub for voltage and current measurement  30 mm plastic housing  1 x M12 IO-Link class A  4 x M12 AI multi (U/I) Art.-No. 59841  IO-Link hub for resistance temperature devices (RTD) ...
Page 12: Product Designation Code
Description Product Designation Code The product designation provides information on the device function. Art.-No. 59840 MVP12-P3 AI-MULT4 4xM12A IOLA12 E0 MVP12-P3 Product family + module size  AI-MULT A = analog  I = input  MULT = multifunctional 4xM12A Number, size, and coding of the slots ...
Page 13: Device Structure
Description Device structure Fig. 3-1: Device structure and port designations Art.-No. Port designation Explanation 59840 X0 ... X3 Analog U/I inputs Device supply, IO-Link class A 59841 X0 ... X3 Analog inputs RTD Device supply, IO-Link class A User manual 59840_hdb_en_12 13 / 50...
Page 14: Pin Assignment
Description PIN assignment Art.-No. 59840 IO-Link XZ1 (M12 male connectors) Pin 1 24 V US (L+) Pin 2 n.c. Pin 3 0 V US (L-) Pin 4 C/Q IO-Link Pin 5 n.c. AI (U/I) X0 ... X3 (M12 female connec- tors) Pin 1 24 V...
Page 15: Technical Data
Technical Data Technical Data Art.-No. 59840 4.1.1 Electrical data Device supply Operating voltage US 24 V Operating voltage range US 18 ... 30 V Power consumption when idling ≤50 mA Galvanic isolation IO-Link Communication speed COM3 Transfer rate 230,400 bit/s Bus protocol IO-Link V1.1.2, compati- ble with IO-Link V1.1.3...
Page 16: Measuring Ranges
Technical Data 4.1.2 Measuring ranges Rated measuring range 0 … 10 V Override range -1.76 … 11.76 V Resolution 361.69 µV Measurement accuracy At 25 °C (full scale) <0.3 % Drift 30 ppm/K Rated measuring range -10 … 10 V Override range -11.76 …...
Page 17: Environmental Characteristics
Technical Data 4.1.3 Environmental characteristics Climatic Operating temperature -25 °C ... +70 °C Storage temperature -40 °C ... +85°C Installation height Above sea level ≤3000 m Relative humidity ≤95 % Mechanical Vibration test EN 60068 Parts 2-6 5 ... 500 Hz; Const.
Page 18: Mechanical Data
Technical Data 4.1.5 Mechanical data Material data Housing material Valox 553 black Flame resistance IEC 60695-2-1 Assembly data Weight 150 g Dimensions L x W x H 126 x 29.78 x 34.3 mm 4.1.6 Product reliability Product reliability MTTF SN 29500 (at 40 °C and rated data) 216 years 4.1.7 Conformity, Approvals...
Page 19: Art.-No. 59841
Technical Data Art.-No. 59841 4.2.1 Electrical data Device supply Operating voltage US 24 V Operating voltage range US 18 ... 30 V Power consumption when idling ≤50 mA Galvanic isolation IO-Link Communication speed COM3 Transfer rate 230,400 bit/s Bus protocol IO-Link V1.1.2, compati- ble with IO-Link V1.1.3 IO-Link cycle time...
Page 20: Measuring Ranges
Technical Data 4.2.2 Measuring ranges PT100, PT200, PT500, PT1000 Rated measuring range -200 °C ... +850 °C Override range -220 °C... +1000 °C Resolution 0.1 °C Measurement accuracy At 25 °C (full scale) <0.15 % Drift 40 ppm/K PT100 climate Rated measuring range -120 °C ...
Page 21: Environmental Characteristics
Technical Data 4.2.3 Environmental characteristics Climatic Operating temperature -25 °C ... +70 °C Storage temperature -40 °C ... +85°C Installation height Above sea level ≤3000 m Relative humidity ≤95 % Mechanical Vibration test EN 60068 Parts 2-6 5 ... 500 Hz; Const.
Page 22: Mechanical Data
Technical Data 4.2.5 Mechanical data Material data Housing material Valox 553 black Flame resistance IEC 60695-2-1 Assembly data Weight 150 g Dimensions L x W x H 126 x 29.78 x 34.3 mm 4.2.6 Product reliability Product reliability MTTF SN 29500 (at 40 °C and rated data) 216 years 4.2.7 Conformity, Approvals...
Page 23: Mounting
Mounting Mounting Requirements  Prerequisites for mounting:  Even mounting surface to avoid mechanical tension.  Provide proper grounding. Suitable installation site in terms of vibration and shock load, temperature  and humidity (see chap. 4 "Technical Data").  Protected to avoid tearing off the connecting cables by personnel or de- vice.
Page 24: Dimensions
Mounting Dimensions Fig. 5-1: Dimensions in mm Mounting distance Fig. 5-2: Distance between the devices a | Male connector straight: 5 mm Male connector angled: 50 mm NOTE If angled male connectors are used, a minimum distance of 50 mm is re- ...
Page 25: Functional Ground
Mounting Functional ground The use of the ring cable lug is necessary for EMC compliance. The shield connection of the input and output female connectors is made via the ring cable lug. Fig. 5-3: Ring cable lug fastening Art.-No. 2 Nm 7000-98001-0000000 Mounting the device...
Page 26 Mounting Fig. 5-4: Fastening, dimensions in mm Art.-No. 2 Nm 7000-98001-0000000 Mounting Align housing. Fasten the ring cable lug with a conductive screw (see chap. 5.4 "Func- tional ground"). Slightly tighten an M4 bolt. Slightly tighten the second M4 bolt. Carefully tighten both M4 bolts according to tightening torque.
Page 27: Installation
Installation Installation WARNING! High electrical voltages. Electric shock may cause life-threatening injuries.  Only qualified personnel may connect the device.  Comply with the five safety rules of electrical engineering. Protective measures  According to IEC 60364 - Protection against electric shock. during connection work CAUTION! Hot surface...
Page 28: Ensure Tight Seal
Installation Ensure tight seal NOTICE Damage to and failure of the device due to ingress of liquids. The degree of protection IP65/67/68 is only guaranteed if all connections are sealed with plug connectors, screw plugs, or sealing caps.  Seal unused male and female connectors. Fig.
Page 29: Operation
Operation Operation NOTE After writing an application-specific tag in the IO-Link hub, the hub briefly interrupts the IO-Link connection if the text is not the same as the text stored in the hub. LED indication The MVP devices are equipped with the following separate LED indicators: ...
Page 30: Led Indication For Inputs
Operation Firmware update LED in- LED state Description dication Permanently on IO-Link in IDLE status, Firmware update completed success- Green fully Flashing IO-Link in status PREOPERATE/OP- ERATE, 1 Hz Green update is not yet performed Permanently on Update failed Flashing IO-Link in status PREOPERATE/OP- ERATE, 2 Hz...
Page 31: Io-Link Object Directory
Operation IO-Link object directory 7.2.1 DPP (Direct Parameter Page) ISDU Object name Length Meaning/default value index cess in bytes Identification 59840 59841 0x0000 MasterCommand 0x01 MasterCycleTime 0x02 MinCycleTime 0x03 M-SequenceCapability 0x04 RevisionID 0x05 ProcessDataIn 0x06 ProcessDataOut 0x07 VendorID 1 (MSB) 0x012F 0x08 VendorID 2 (MSB)
Page 32 Operation ISDU In- ISDU SubIn- Object name Length Meaning/default value cess in bytes 0x0025 DetailedDeviceStatus R Octet 1: EventQualifier, Octet2, 3: EventCode Octet 1: EventQualifier, Octet2, 3: EventCode DetailedDeviceStatus R Octet 1: EventQualifier, Octet2, 3: EventCode Gesamtlänge in Byte NOTE Refer to IO-Link specification for structural specification, refer to 7.3.1 "Ven- dor-specific IO-Link events".
Page 33: Isdu (Indexed Service Data Unit)
Operation 7.2.2 ISDU (Indexed Service Data Unit) 7.2.2.1 Art.-No. 59840 Diagnostic ISDU ISDU Object name Access Length Meaning Index Subindex in bytes 0x0024 DeviceStatus 0: Device is operating properly 1: Maintenance Required 2: Out of Specification 3: Functional Check 4: Failure 5 ...
Page 34 Operation ISDU ISDU Object name Access Length Meaning Default Index Subindex in bytes value 0x0077 1 IO-Link Event Code transmission to master R/W Configurable analog 0x01 mode: US - Diagnostic undervoltage 0x00 = deactivated US - Diagnostic overvoltage 0x01 = 0 ... 10 V US - LED status 0x02 = -10 ...
Page 35: Art.-No. 59841
Operation 7.2.2.2 Art.-No. 59841 ISDU Object name Access Length Meaning Default index value bytes 0x0040 Status: Power supply status Indicates the status of US - 0x00 = OK - 0x01 = undervoltage - 0x02 = overvoltage 0x0041 Status: Power supply value Indicates the measured voltage value of US in steps of 0.1 V.
Page 36 Operation ISDU ISDU Object name Access Length Meaning Default Index Subindex in bytes value 0x0077 1 IO-Link Event Code transmission to master R/W Configurable values: 0x01 US - Diagnostic undervoltage 0x00 = deactivat- ed0x01 = Pt100Cli- US - Diagnostic overvoltage ma0x02 = Pt1000x03 US - LED status = Pt2000x04 =...
Page 37: Diagnostic
Operation Diagnostic 7.3.1 Vendor-specific IO-Link events NOTE In addition to the vendor-specific IO-Link-Events listed here, the standard events of the IO-Link specification also apply, version see chapter 1.5.3 "Specifications". Art.-No. 59840 Event Event type Description Action code 0x0000 Notification No malfunction 0x1000 Error General malfunction...
Page 38 Operation Event Event type Description Action code 0x8D41 Warning Upper user-defined warning threshold overrun - Port 1 Check application 0x8D42 Warning Upper user-defined warning threshold overrun - Port 2 Check application 0x8D43 Warning Upper user-defined warning threshold overrun - Port 3 Check application Tab.
Page 39: Process Data
Operation Process data 7.4.1 Input data Byte 0, 1 Measured value Byte 2, 3 Measured value Byte 4, 5 Measured value Byte 6, 7 Measured value Byte 8 Diagnostic Global status Diagnose Parameter Channel MSB Channel Middle Bit Write Byte 8 Diagnostic Channel LSB Error or warning on in-...
Page 40: Measured Values For Art.-No. 59840
Operation 7.4.1.1 Measured values for Art.-No. 59840 Analog input Digits in Measured Area Diagnosis Diagnosis value type U 0 ...10 V Dez. Hex. 0 ... 10 V 32511 7EFF >11.7589 V Overflow Error 28512 6F60 <10.3087 V Override range Warning 27649 6C01 10 V...
Page 41 Operation Analog input Digits in Measured Area Diagnosis Diagnosis value type U -5 ... 5 V Dez. Hex. -5 ... 5 V 32511 7EFF >5.8795 V Overflow Error 28512 6F60 <5.1543 V Override range Warning 27649 6C01 None None +180.85 μV 27648 6C00 5.0000 V...
Page 42 Operation Digits in Measured Area Diagnosis Diagnosis value type Dez. Hex. 4 ... 20 mA 28512 6F60 <20.6190 Override range Warning 27649 6C01 0.0000 mA None None +578.7 nA 27648 6C00 20.0000 mA 20736 5100 16.0000 mA 13824 3600 12.0000 mA Nominal range 0001 4 mA...
Page 43: Measured Values For Art.-No. 59841
Operation 7.4.1.2 Measured values for Art.-No. 59841 Temperature PT100, PT200, PT500, PT1000 Values Measured value Area Dec. Hex. Temperature in °C 32767 7FFF >1000.0 Overflow 10000 2710 1000.0 Override range 8501 2135 850.1 8500 2134 850.0 0001 Nominal range 0000 -2000 F830 -200.0...
Page 44: Output Data
Operation 7.4.2 Output data 7.4.2.1 Art.-No. 59840 Alternatively to chap. 7.2 "IO-Link object directory", sensor type, connection type and conversion time can be parameterized via the output process data. Byte 0 7, 6 5, 4 3 ... 0 Description Conversion time for X0, X1, Reserved Sensor type X0 X2 and X3...
Page 45: Art.-No. 59841
Operation 7.4.2.2 Art.-No. 59841 Byte 0 7, 6 5, 4 3 ... 0 Description Conversion time for X0 and Wire mode X0 Sensor type X0 Values 0b00 – 12 ms 0b00 – 2 wire 0b0000 – deactivated 0b01 – 50 ms 0b01 –...
Page 46 Operation Byte 4 Beschreibung Process data command 0xFC: „Parameter write“ User manual 59840_hdb_en_12 46 / 50...
Page 47: Maintenance And Cleaning
Maintenance and cleaning Maintenance and cleaning NOTE Replace defective or damaged devices.  Device cleaning:  Use only oil-free compressed air or spirit  Use only lint-free materials (e.g. leather cloth) Do not use contact spray  User manual 59840_hdb_en_12 47 / 50...
Page 48: Appendix
Appendix Appendix Accessories Description Art.-No. Screw Plug M12 Metal 996049 Plastic M12 screw plug, VE10 58627 Ground strap 4 mm 100 mm for M4 4000-71001-0410004 Grounding strap screw-down set M4 4000-71003-0101604 Designation Art.-No. 6-part screwdriver set 7000-98001-0000000 M12 torque wrench set, AF 13 7000-99102-0000000 PRODUCTS AND ACCESSORIES You will find a wide range of products in our catalog or in our Murrelektronik...
Page 49: Legal Notes
Legal notes Legal notes Disclaimer Murrelektronik GmbH has reviewed the contents of this technical documenta- tion for conformity with the described hardware and software. It is possible that certain details may not be correct. For this reason, we make no warranty re- garding the accuracy of this technical documentation, and assume no liability for any errors, in particular full conformity.
Page 50 Murrelektronik GmbH | Falkenstraße 3 | 71570 Oppenweiler | GERMANY +49 7191 47-0 | +49 7191 47-491 000 | info@murrelektronik.com www.murrelektronik.com The information in the manual has been compiled with utmost care. Liability for the correctness, completeness and topicality of the information is restricted to gross negligence.
