Murr Elektronik xtreme DB DP-34005-12 User Manual

Programming kit

Advertisement

Quick Links

xtreme DB Programming Kit
DP-34005-12 User Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the xtreme DB DP-34005-12 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Murr Elektronik xtreme DB DP-34005-12

  • Page 1 xtreme DB Programming Kit DP-34005-12 User Guide...
  • Page 2 | CONTENTS Module Overview Installing the Software Connecting the Universal CAN Gateway Downloading the Firmware...
  • Page 3: Installing The Software

    | INSTALLING THE SOFTWARE 1. Go to murrmsp.com 1. Go to the xtremeDB page 1. Downlaod the DP Loader software 1. Unzip the DP Loader file and save that file in the location of your choice...
  • Page 4 | CONNECTING THE UCG 1.Isolate the xtremeDB module whose firmware you will be updating from the CAN network. 2. Open the xtremeDB Programming Kit 3. Locate the UCG (Universal CAN Gateway) Module 4. Connect the USB cable to the UCG and a USB port on your 5.
  • Page 5 6. Connect the wall pack power supply 2 pin Molex connector to 7. Install the terminating resistor into the other unused CAN the mating connector attached to the Deutsch cable. Plug the port. power suppy into a 120V AC outlet. 8.
  • Page 6: Downloading Firmware

    | DOWNLOADING FIRMWARE 1. Find the DP Loader icon and double click. Depending on 2. The program will open, press the “open” button to find the where you’ve saved the software this location could be different. .hex file to download. 3.
  • Page 7 6. This screen will appear, press the “Yes” button. 5. You will notice the icon has turned red and the lower status bar shows your connected at the corresponding baud rate. Press the “Auto Program” button. 7. The screen will display “Programming” in the lower status bar. 8.
