ENGLISH MANUAL
for devices of the MVP12 series
Art.-No. 59712 | 59812

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MVP12 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Murr Elektronik MVP12 Series

  • Page 1 ENGLISH MANUAL for devices of the MVP12 series Art.-No. 59712 | 59812...
  • Page 2 This document is valid for the following products: Product designation Art.-No. MVP12-P6 DIO16CGND 8xM12A IOL_12 B0 59712 MVP12-P6 DIO16CGND 8xM12A IOL_12 E0 59812 Document status: Manual number 59712 Language Version Date 2023-08 Murrelektronik GmbH Falkenstraße 3 71570 Oppenweiler GERMANY Phone +49 7191 47-0 Fax +49 7191 47-491000 info@murrelektronik.com NOTE...
  • Page 3: Table Of Contents

    4.2.1 Electrical data 4.2.2 Environmental characteristics 4.2.3 Protection 4.2.4 Mechanical data 4.2.5 Product reliability 4.2.6 Conformity, Approvals Mounting Requirements Dimensions Mounting distance Functional ground Mounting the device ENGLISH MANUAL 3 / 39 for devices of the MVP12 series Art.-No. 59712 | 59812...
  • Page 4 Process data 7.4.1 Port-Based Bitmapping 7.4.1.1 Input data 7.4.1.2 Output data 7.4.2 Pin-Based Bitmapping 7.4.2.1 Input data 7.4.2.2 Output data Maintenance and cleaning Appendix Accessories Legal notes ENGLISH MANUAL 4 / 39 for devices of the MVP12 series Art.-No. 59712 | 59812...
  • Page 5: Introduction

    Introduction Introduction Purpose of this This document instructs the technical staff of the machine manufacturer or document machine operator on the safe use of the described devices. It does not include instructions on the safe use of the machine in which the devices are integrated.
  • Page 6: Applicable Documents

    Introduction Applicable documents Document Art.-No. Operating instructions 59712 Product data 59712 Product data 59812 You will find the applicable documents included in the scope of delivery or on- line: shop.murrelektronik.com Environmentally friendly disposal Comply with country- Always dispose of scrap devices in compliance with the applicable coun- ...
  • Page 7: About This Manual

    Introduction About this manual 1.5.1 Symbols This document includes information and notes that must be observed for your own safety and to avoid injuries and equipment damage. They are marked as follows: DANGER! Immediate danger.  Failure to observe this warning involves an imminent risk of death or seri- ous injuries.
  • Page 8: Trademarks

    Introduction 1.5.2 Trademarks Trademarks of the following companies and institutions are used in this docu- mentation: IO-Link c/o PROFIBUS Nutzerorganisation e.V. (PNO) 1.5.3 Specifications Specification Link IO-Link www.io-link.com Version 1.1 dated 2018-03 User manual 59712_hdb_en_11 8 / 39...
  • Page 9: For Your Safety

    For your safety For your safety General safety instructions Qualified personnel Only qualified and safety-trained personnel may assemble, commission and operate the device. Target group This document is intended for specialists in automation technology. Five safety rules of When working on electrical systems, always observe the five safety rules of electrical engineering electrical engineering: Disconnect from the mains.
  • Page 10: Warranty And Liability

    For your safety 2.2.2 Warranty and liability Warranty and liability claims cannot be made if:  the product is not used according to its designated use, damage is caused due to non-observance of the  operating instructions,  the personnel was/is not qualified. User manual 59712_hdb_en_11 10 / 39...
  • Page 11: Description

    Description Description  IO-Link hub in 50 mm plastic housing  1 x M12 IO-Link (common GND)  8 x M12 I/O  16 configurable digital inputs/outputs User manual 59712_hdb_en_11 11 / 39...
  • Page 12: Product Designation Code

    Description Product Designation Code The product designation provides information on the device function. Art.-No. 59712 MVP12-P6 DIO16CGND 8xM12A IOL_12 B0 MVP12-P6 Product family + module size  D = digital  I = input  O = output 8xM12A Number, size, and coding of the slots ...
  • Page 13: Device Structure

    Description Device structure Fig. 3-1: Device structure and port designations Art.-No. Port designation Explanation 59712, 59812 X0 ... X7 Digital inputs and outputs Device supply, IO-Link User manual 59712_hdb_en_11 13 / 39...
  • Page 14: Pin Assignment

    Description PIN assignment IO-Link XZ1 (M12 male connectors) Pin 1 24 V US (L+) Pin 2 24 V UA (P24) Pin 3 Pin 4 C/Q IO-Link Pin 5 X0 ... X7 (M12 female connec- tors) Pin 1 24 V US (L+) Pin 2 Pin 3 Pin 4...
  • Page 15: Technical Data

    Technical Data Technical Data Art.-No. 59712 4.1.1 Electrical data Device supply Operating voltage US/UA 24 V Operating voltage range US/UA 18 ... 30 V Total current US ≤50 °C (see derating) ≤4 A Total current UA ≤50 °C (see derating) ≤4 A Power consumption when idling ≤50 mA...
  • Page 16: Environmental Characteristics

    Technical Data Output (DO) Connection/female connector M12 A-coded Cable cross-section ≤0.75 mm² Cable length ≤30 m Output current Per pin ≤2 A Switching frequency Resistive load ≤25 Hz 4.1.2 Environmental characteristics Climatic Operating temperature -25 °C ... +70 °C Storage temperature -40 °C ...
  • Page 17: Mechanical Data

    Technical Data 4.1.4 Mechanical data Material data Housing material Valox 553 black Flame resistance IEC 60695-2-1 Assembly data Weight 200 g Dimensions L x W x H 126 x 50 x 34.5 mm 4.1.5 Product reliability Product reliability MTTF SN 29500 (at 40 °C and rated data) 216 years 4.1.6 Conformity, Approvals...
  • Page 18: Art.-No. 59812

    Technical Data Art.-No. 59812 4.2.1 Electrical data Device supply Operating voltage US/UA 24 V Operating voltage range US/UA 18 ... 30 V Total current US ≤50 °C (see derating) ≤4 A Total current UA ≤50 °C (see derating) ≤4 A Power consumption when idling ≤50 mA Galvanic isolation...
  • Page 19: Environmental Characteristics

    Technical Data Output (DO) Connection/female connector M12 A-coded Cable cross-section ≤0.75 mm² Cable length ≤30 m Output current Per pin ≤2 A Switching frequency Resistive load ≤25 Hz 4.2.2 Environmental characteristics Climatic Operating temperature -25 °C ... +70 °C Storage temperature -40 °C ...
  • Page 20: Mechanical Data

    Technical Data 4.2.4 Mechanical data Material data Housing material Valox 553 black Flame resistance IEC 60695-2-1 Assembly data Weight 200 g Dimensions L x W x H 126 x 50 x 34.5 mm 4.2.5 Product reliability Product reliability MTTF SN 29500 (at 40 °C and rated data) 216 years 4.2.6 Conformity, Approvals...
  • Page 21: Mounting

    Mounting Mounting Requirements  Prerequisites for mounting:  Even mounting surface to avoid mechanical tension.  Provide proper grounding. Suitable installation site in terms of vibration and shock load, temperature  and humidity (see chap. 4 "Technical Data").  Protected to avoid tearing off the connecting cables by personnel or de- vice.
  • Page 22: Mounting Distance

    Mounting Mounting distance Fig. 5-2: Abstand zwischen Geräten a | Stecker gerade: 5 mm Stecker gewinkelt: 50 mm NOTE  If angled male connectors are used, a minimum distance of 50 mm is re- quired. Functional ground FE connection Fig. 5-3: Ring cable lug fastening Art.-No.
  • Page 23: Mounting The Device

    Mounting Mounting the device NOTICE Material damage due to incorrect installation. The fastening screws and tightening torques depend on the surface of the in- stallation site.  Use fastening screws that are suitable for the mounting surface structure.  Carefully tighten the screws. The indicated tightening torques must be ad- hered to.
  • Page 24: Installation

    Installation Installation WARNING! High electrical voltages. Electric shock may cause life-threatening injuries.  Only qualified personnel are allowed to connect the device.  Observe the five safety rules of electrical engineering. Protective measures  According to IEC 60364 - Protection against electric shock. during connection work CAUTION! Hot surface...
  • Page 25: Ensure Tight Seal

    Installation Ensure tight seal NOTICE Damage to and failure of the device due to ingress of liquids. The degree of protection Variable "<Schutzart>" not defined. is only guaran- teed if all connections are sealed with plug connectors, screw plugs, or sealing caps.
  • Page 26: Operation

    Operation Operation NOTE After writing an application-specific tag in the IO-Link hub, the hub briefly interrupts the IO-Link connection if the text is not the same as the text stored in the hub. LED indication The MVP devices are equipped with the following separate LED indicators: ...
  • Page 27: Led Indication Ua

    Operation Firmware update LED in- LED state Description dication Permanently on IO-Link in IDLE status, Firmware update completed success- Green fully Flashing IO-Link in status PREOPERATE/OP- ERATE, 1 Hz Green update is not yet performed Permanently on Update failed Flashing IO-Link in status PREOPERATE/OP- ERATE, 2 Hz...
  • Page 28: Led Indication For Inputs And Outputs

    Operation 7.1.3 LED indication for inputs and outputs LED indication LED in- LED state Voltage at in- Description Logical digital inputs/outputs dication value Permanently on 24 V Channel on Yellow Permanently on Short-circuit or over- load DO Device off or firmware update is being per- formed Tab.
  • Page 29: Io-Link Object Directory

    Operation IO-Link object directory 7.2.1 DPP (Direct Parameter Page) ISDU Object name Length Meaning/default value index index cess in bytes Identification Art.-No. 59712 Art.-No. 59812 0x0000 0x00 MasterCommand 0x01 MasterCycleTime 0x02 MinCycleTime 0x03 M-sequenceCapa- bility 0x04 RevisionID 0x05 ProcessDataIn 0x06 ProcessDataOut 0x07 VendorID 1 (MSB) 0x012F 0x08 VendorID 2 (MSB)
  • Page 30 Operation ISDU Object name Length Meaning/default value index index cess in bytes 0x0024 DeviceStatus 0: Device is operating properly 1: Maintenance Required 2: Out of Specification 3: Functional Check 4: Failure 5 ... 255: Reserved 0x0025 DetailedDeviceSta- Variable 6 x (Octet 1: EventQualifier, Octet 2, 3: EventCode) 0x0028 ProcessDataInput...
  • Page 31: Isdu (Indexed Service Data Unit)

    Operation 7.2.2 ISDU (Indexed Service Data Unit) Art.-No. 59812 ISDU Object name Length Meaning Default index cess value bytes 0x0040 Status: Power Supply Sta- Indicates the status of US tus US - 0x00 = OK - 0x01 = undervoltage - 0x02 = overvoltage 0x0041 Status: Power Supply Value Indicates the measured voltage value of US in...
  • Page 32 Operation ISDU Object name Length Meaning Default index cess value bytes 0x0081 Inputs: Signal Extension/ Extension of the input pulses in steps of 10 ms. Impulse Stretching - Subindex 1: X0 Pin 4 - Subindex 2: X0 Pin 2 … - Subindex 15: X7 Pin 4 - Subindex 16: X7 Pin 2 Setting per channel (subindex):...
  • Page 33: Diagnostic

    Operation Diagnostic 7.3.1 Vendor-specific IO-Link events NOTE In addition to the vendor-specific IO-Link events listed here, the standard events of the IO-Link specification also apply, version see chapter 1.5.3 "Specifications". Event Event type Description Action code 0x4000 Error Temperature error Overload 0x4210 Warning...
  • Page 34: Process Data

    Operation Process data 7.4.1 Port-Based Bitmapping 7.4.1.1 Input data Byte 0 inputs X0 ... X3 Contact Pin2_X3 Pin4_X3 Pin2_X2 Pin4_X2 Pin2_X1 Pin4_X1 Pin2_X0 Pin4_X0 Byte 1 inputs X4 ... X7 Contact Pin2_X7 Pin4_X7 Pin2_X6 Pin4_X6 Pin2_X5 Pin4_X5 Pin2_X4 Pin4_X4 NOTE Byte 2 and 3 are supported only by E0 devices.
  • Page 35: Pin-Based Bitmapping

    Operation 7.4.2 Pin-Based Bitmapping 7.4.2.1 Input data Process data Digital inputs Byte 0 inputs X0 ... X7 Contact Pin4_X7 Pin4_X6 Pin4_X5 Pin4_X4 Pin4_X3 Pin4_X2 Pin4_X1 Pin4_X0 Byte 1 inputs X0 ... X7 Contact Pin2_X7 Pin2_X6 Pin2_X5 Pin2_X4 Pin2_X3 Pin2_X2 Pin2_X1 Pin2_X0 NOTE Byte 2 and 3 are supported only by E0 devices.
  • Page 36: Maintenance And Cleaning

    Maintenance and cleaning Maintenance and cleaning NOTE Replace defective or damaged devices.  Device cleaning:  Use only oil-free compressed air or spirit  Use only lint-free materials (e.g. leather cloth) Do not use contact spray  User manual 59712_hdb_en_11 36 / 39...
  • Page 37: Appendix

    Appendix Appendix Accessories Description Art.-No. Screw Plug M12 Metal 996049 Plastic M12 screw plug, VE10 58627 Crimping cable lugs, ring form 10 mm² (M4) (narrow) 4000-71004-0000004 Grounding strap screw-down set M4 4000-71003-0101604 Designation Art.-No. 6-part screwdriver set 7000-98001-0000000 M12 torque wrench set, AF 13 7000-99102-0000000 PRODUCTS AND ACCESSORIES You will find a wide range of products in our catalog or in our Murrelektronik...
  • Page 38: Legal Notes

    Legal notes Legal notes Disclaimer Murrelektronik GmbH has reviewed the contents of this technical documenta- tion for conformity with the described hardware and software. It is possible that certain details may not be correct. For this reason, we make no warranty re- garding the accuracy of this technical documentation, and assume no liability for any errors, in particular full conformity.
  • Page 39 Murrelektronik GmbH | Falkenstraße 3 | 71570 Oppenweiler | GERMANY +49 7191 47-0 | +49 7191 47-491 000 | info@murrelektronik.com www.murrelektronik.com The information in the manual has been compiled with utmost care. Liability for the correctness, completeness and topicality of the information is restricted to gross negligence.
