JA-123E-NFC (JABLOTRON 100+)
Bus outdoor keypad with RFID
The keypad is a component of JABLOTRON system. The keypad with contactless RFID reader is
used to control the alarm system, to activate a PG output and to control access to the building.
The keypad features one control segment, a reading surface and optical signalling. The product
is suitable for indoor and outdoor use and is powered from the control panel bus. The product
is designed for installation by a trained technician with a valid Jablotron certificate.
Always connect the bus when the system is completely powered
off.
1. Remove the locking screw (6) and open the keypad cover.
2. Install the plastic base to a chosen place on a wall so that the tamper contact (5) can
be sufficiently compressed when the installation is complete.
3. Pull the keypad cable through the hole in the plastic base.
reader 13,56 MHz
Type: 1KPAD2318LU
switch to the short version of manual
Installation
www.jablotron.com
Print / Save as PDF
If you want to save to PDF, please select
'Save as PDF' when the print dialog opens.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 100+ Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for jablotron 100+ Series

  • Page 1 The keypad is a component of JABLOTRON system. The keypad with contactless RFID reader is used to control the alarm system, to activate a PG output and to control access to the building.
  • Page 2 4. Connect the bus cable into the terminal blocks according to the colours and markings – red terminal +U, yellow A, green B, black GND. For connection outside the armed area, we recommend using the JA-110T isolator. 5. Follow the instructions stated in the control panel installation manual. Basic procedure: a.
  • Page 3 indicates a fault by permanent light. The asterisk symbol signifies the factory default setting. Segment function (section/PG selection) None / Unsetting / Setting / Section indication / PG Off/On / PG ON / PG OFF / PG indication / PG indicates inversely Options Unsetting/Setting, PG Off/On / PG ON / PG OFF allow you to enable requiring authorization every time you control a segment.
  • Page 4: Backlight Intensity

    is displayed. Backlight intensity May be adjusted with a slider in F-link. Authorised action Authorisation triggers an entrance delay: On/Off*: If the section, in which the reader is assigned, is in an armed state, authorisation by the means of reading a card induces an entry delay.
  • Page 5 MIFARE® is a registered trademark owned by NXP B.V. There is no affiliation between NXP B.V. and Jablotron Alarms a.s. JABLOTRON ALARMS a.s. hereby declares that the product 1KPAD2318LU is in compliance with the relevant Union harmonisation legislation: Directives No: 2014/53/EU, 2014/35/EU, 2014/30/EU, 2011/65/EU. The original of the conformity assessment can be found at www.jablotron.com –...
